The Linux PCI Interface

1
The Linux PCI Interface

• An introduction to the PCI configuration space
  registers

2
Some background on PCI

• ISA Industry Standard Architecture (1981)
• PCI Peripheral Component Interconnect
• An Intel-backed industry initiative (1992-9)
• Main goals
• Improve data-xfers to/from peripheral devices
• Eliminate (or reduce) platform dependencies
• Simplify adding/removing peripheral devices
• Lower total consumption of electrical power

3
Features for driver-writers

• Support for auto-detection of devices
• Device configuration is programmable
• Introduces PCI Configuration Space
• A nonvolatile data-structure of device info
• A standard header layout 64 longwords
• Linux provides some interface functions
• include ltlinux/pci.hgt

4
pci_dev_struct

• Linux extracts info from PCI Config. Space
• Stores the info in linked-lists of structures
• Examples
• Name of the devices manufacturer
• Name and release version of the product
• Hardware resources provided by the product
• System resources allocated to the product
• (Linux provides search-and-extract routines)

5
The lspci command

• Linux scans PCI Configuration Space
• It builds a list of pci_dev_struct objects
• It exports partial info using a /proc file
• You can view this info using a command
  /sbin/lspci
• Or you can directly view the /proc/pci file
• cat /proc/pci

6
An illustrative example vram.c

• Lets write another character device-driver
• It will allow read/write access to video ram
• Very analogous to our prior ram.c driver
• Some differences
• Devices memory resides on PCI the bus
• Can safely allow writing as well as reading
• Hardware uses memory in nonstandard ways
• We really need vendors programmer manual

7
init_module()

• Drivers first job is device detection
• PCI devices are identified by numbers
• Device classes also have ID-numbers
• VGA device-class 0x030000
• 03 means a display device
• 00 means VGA compatible
• 00 means revision-number

8
pci_find_class()

• Define the manifest constant
• define VGA_CLASS 0x030000
• Declare a null-pointer
• struct pci_dev_struct devp NULL
• Call pci_find_class() function
• devp pci_find_class( VGA_CLASS, devp )
• Check for device-not-found
• if ( devp NULL ) return ENODEV

9
Locate the VGA frame buffer

• In PCI Configuration Space
• offset 0x10 base_address0
• offset 0x14 base_address1
• offset 0x18 base_address2
• . . . etc. . . .
• (complete layout on page 475 in textbook)
• A convenient Linux extraction-function
• fb_base pci_resource_start( devp, 0 )

10
How big is the frame buffer?

• Size of video memory varies with product
• Driver needs to determine memory-size
• PCI a standard way to determine size
• (But product might provide support for larger
  vram than is currently installed)
• Two-step size-detection method
• First determine maximum supported size
• Then check for redundant addressing

11
Maximum memory-size

• Some bits in base_address0 are wired
• But other bit-values are programmable
• Bits 0..3 have some special meanings
• So we will need to examing bits 4..31
• Find least significant programmable bit
• It tells the maximum supported memory

12
Programming algorithm

• Get configuration longword at offset 0x10
• Save it (so that we can restore it later)
• Write a new value all bits set to 1s
• Read back the longword just written
• The hard-wired bits will still be 0s
• We will scan for first bit thats 1
• Be sure to restore the original longword

13
Loop to find the lowest 1

• Implementing the PCI size-test
• pci_write_config_dword( devp, 0x10, 0 )
• pci_read_config_dword( devp, 0x10, val)
• int i
• for (i 4 i lt 32 i)
• if ( val ( 1 ltlt i ) ) break
• fb_maxsize ( 1 ltlt i )

14
Checking for memory wrap

• Do vram bytes have multiple addresses?
• We use a quick-and-dirty check
• write to one address, read from another
• If what we read didnt change no wrap!
• Some assumptions we make
• Memory-size will be a power of 2
• If two bytes differ, all between them do, too
• (Should we question these assumptions?)

15
Device-memory read and write

• The CPU understands virtual addresses
• They must be mapped to bus addresses
• The kernel must setup page-table entries
• Linux kernel provides functions
• vaddr ioremap( physaddr, memsize )
• iounmap( vaddr )
• Alternative can use ioremap_nocache()

16
For copying ram to/from vram

• Linux provides special memcpy functions
• memcpy_fromio( ram, vram, nbytes )
• memcpy_toio( vram, ram, nbytes )

17
Our vram.c driver

• We imitate the code in our ram.c driver
• We use temporary mappings (one page)
• Our read() and write() are very similar
• One notable difference
• read() is supposed to return 0 in case
• the files pointer is at the end-of-file
• (This defect should be corrected in ram.c)

18
Warning about Red Hat 9.0

• Red Hat 9.0 is now available in stores
• It advertises kernel version 2.4.20
• But its not identical to 2.4.20 in our class
• Our demo modules do not always work
• Changes were made to kernel structures
• (e.g., task_struct)
• Changes were made to exported symbols
• (e.g., sys_call_table)

19
Need a work-around

• Our vram.c doesnt create its device-node
• Requires users to create a node manually
• We hard-coded the device major number
• So decisions differ from our past practice

20
Exercises

• Get vram.c from our class website
• Compile and install the vram.c driver
• Create the device special file /dev/vram
• Change file-attributes (to allow writing)
• Try copying video frame-buffer to a file
• Use dump.cpp to view that binary file
• Try using fileview.cpp to view video ram
