SVD

1
SVD LSI

• ML Reading Group
• Jan-24-2006
• Presenter Zheng Zhao

2
SVD (Singular value decomposition)

• Vector Norm
• Matrix Norm
• Singular value decomposition
• The application of SVD

3
vector norm

• A vector norm has the following properties.
• 1. x ? 0 (non-negative)
• 2. x 0 implies that all elements xi 0
• 3. ?x ? x
• 4. x1 x2 ? x1 x2
  (triangular inequality)
• Equivalence of norms

4
vector norm (cont.)
5
matrix (operator) norm

• A matrix (operator) norm has the following
  properties.
• 1. A ? 0 (non-negative)
• 2. A 0 implies that all elements xi 0
• 3. ?A ? A
• 4. A1 A2 ? A1 A2
  (triangular inequality)
• 5. AB ? A B (multiplicative
  property)

An induced norm is defined as the following, for
z Ax
measures how much A stretches x
6
matrix (operator) norm (cont.)
7
SVD

• SVD- Singular value decomposition
• http//en.wikipedia.org/wiki/Singular_value_decomp
  osition

8
Some Properties of SVD
9
Some Properties of SVD

• That is, Ak is the optimal approximation in terms
  of the approximation error measured by the
  Frobenius norm, among all matrices of rank k
• Forms the basics of LSI (Latent Semantic
  Indexing) in informational retrieval

10
Application of SVD

• Pseudoinverse
• Range, null space and rank
• Matrix approximation
• Other examples
• http//en.wikipedia.org/wiki/Singular_value_decomp
  osition

11
LSI (Latent Semantic Indexing)

• Problem Introduction
• Latent Semantic Indexing
• LSI
• Query
• Updating
• An example
• Some comments

12
Problem Introduction

• Traditional term-matching method doesnt work
  well in information retrieval
• We want to capture the concepts instead of words.
  Concepts are reflected in the words. However,
• One term may have multiple meaning
• Different terms may have the same meaning.

13
LSI (Latent Semantic Indexing)

• LSI approach tries to overcome the deficiencies
  of term-matching retrieval by treating the
  unreliability of observed term-document
  association data as a statistical problem.
• The goal is to find effective models to represent
  the relationship between terms and documents.
  Hence a set of terms, which is by itself
  incomplete and unreliable, will be replaced by
  some set of entities which are more reliable
  indicants.

14
LSI, the Method

• Document-Term M
• Decompose M by SVD.
• Approximating M using truncated SVD

15
LSI, the Method (cont.)
Each row and column of A gets mapped into the
k-dimensional LSI space, by the SVD.
16
Fundamental Comparison Quantities from the SVD
Model

• Comparing Two Terms the dot product between two
  row vectors of reflects the extent to which
  two terms have a similar pattern of occurrence
  across the set of document.
• Comparing Two Documents dot product between two
  column vectors of
• Comparing a Term and a Document

17
Query

• A query q is also mapped into this space, by
• Compare the similarity in the new space
• Intuition Dimension reduction through LSI brings
  together related axes in the vector space.

18
Updating

• Recomposing
• Expensive
• Fold in Method

New terms and documents have no effect on the
representation of the preexisting terms and
documents
19
Example
20
Example (cont.)
21
Example (cont. Mapping)
22
Example (cont. Query)
Query Application and Theory
23
Example (cont. Query)
24
Example (cont. fold in)
25
Example (cont. recomposing)
26
Choosing a value for k

• LSI is useful only if k ltlt n.
• If k is too large, it doesn't capture the
  underlying latent semantic space if k is too
  small, too much is lost.
• No principled way of determining the best k need
  to experiment.

27
How well does LSI work?

• Effectiveness of LSI compared to regular
  term-matching depends on nature of documents.
• Typical improvement 0 to 30 better precision.
• Advantage greater for texts in which synonymy and
  ambiguity are more prevalent.
• Best when recall is high.
• Costs of LSI might outweigh improvement.
• SVD is computationally expensive limited use for
  really large document collections
• Inverted index not possible
