Distributed File Systems Andrew file system

1
Distributed File SystemsAndrew file system
2
The Andrew File System

• uses normal Unix file primitives
• AFS servers hold local user files but server
  filing systems are NFS based.
• primary design factor was scalability which is
  accomplished by
• whole file serving unlike NFS
• whole file caching on the client computer

3
Performance of the Andrew File System

• design was based on a number of assumptions
• locally cached copies of shared files that are
  infrequently updated ( eg. system ) or a single
  users files are likely to remain valid for long
  periods.
• local cache is sufficiently large ( gt100 M ) to
  establish a working set of files for a user.
• common file characteristics
• small lt 10 K
• reads are six times more common than writes
• read/writes by one user only one user modifies
• files are referenced in bursts
• not suitable for distributed databases ( large
  number of users can modify )

4
Distribution of processes in the Andrew File
System
5
File name space seen by clients of AFS
6
System call interception in AFS
7
Implementation of file system calls in AFS
8
The main components of the Vice service interface
9
Cache consistency

• maintained by the use of callbacks
• if server updates a file it sends a callback
  request to all of the clients holding a copy of
  that file. This causes the client to set the
  callback to cancelled.
• when accessing a cached copy of a file, a client
  check the callback. If it is cancelled a new
  copy of the file must be fetched from the server.

10
Cache consistency

• upon reboot, a client checks all of its file
  callbacks as some callbacks may have been missed.
• for all valid callbacks it finds it sends a
  validation request with a file timestamp
• if server agrees with the timestamp, the callback
  is valid. If not the callback is cancelled ( ie.
  next time a new copy of file must be fetched ).
• callbacks must be renewed before a open if a time
  T ( typically a few minutes ) has elapsed since
  the file was cached if no communication with
  server

11
Cache consistency

• callbacks work better than just using timestamps
  ( every open would require a check with the
  server )
• callbacks require that Vice servers retain some
  state on behalf of the Venus clients even when a
  reboot is required
• callback promise mechanism maintains a
  well-defined approximation to one-copy semantics
  that are not practical in large systems

12
Other aspects of AFS worth noting

• UNIX kernel in AFS hosts is modified to allow
  Vice to perform file operations in terms of file
  handles can remain stateless
• each server contains a fully replicated location
  database giving a mapping of volume names to
  servers. If a volume os moved, forwarding
  information is left behind
• Vice and Venus make use of a non-pre-emptive
  thread package so that reuests can be processed
  concurrently at both the server and the client.
  Cache content maps are stored in the common
  memory that is shared between Venus threads

13
Other aspects of AFS worth noting

• read-only replicas can be used for infrequently
  updated files
• large bulk transfers in large packets reduce
  latency
• AFS-3 allows for partial file caching in 64k
  chunks
• load on AFS servers is reduced considerably from
  NFS
• allows for wide-area support with multiple
  administrative cells

14
Recent advances in file services

• NFS enhancements
• WebNFS - NFS server implements a web-like service
  on a well-known port. Requests use a 'public file
  handle' and a pathname-capable variant of
  lookup(). Enables applications to access NFS
  servers directly, e.g. to read a portion of a
  large file.
• One-copy update semantics (Spritely NFS, NQNFS) -
  Include an open() operation and maintain tables
  of open files at servers, which are used to
  prevent multiple writers and to generate
  callbacks to clients notifying them of updates.
  Performance was improved by reduction in
  gettattr() traffic.

15
Recent advances in file services

• Improvements in disk storage organisation
• RAID - improves performance and reliability by
  striping data redundantly across several disk
  drives
• Log-structured file storage - updated pages are
  stored contiguously in memory and committed to
  disk in large contiguous blocks ( 1 Mbyte). File
  maps are modified whenever an update occurs.
  Garbage collection to recover disk space.

16
New design Approaches

• Distribute file data across several servers
• Exploits high-speed networks (ATM, Gigabit
  Ethernet)
• Layered approach, lowest level is like a
  'distributed virtual disk'
• Achieves scalability even for a single
  heavily-used file
• 'Serverless' architecture
• Exploits processing and disk resources in all
  available network nodes
• Service is distributed at the level of individual
  files
• Examples
• xFS (section 8.5) Experimental implementation
  demonstrated a substantial performance gain over
  NFS and AFS
• Frangipani (section 8.5) Performance similar to
  local UNIX file access
• Tiger Video File System (see Chapter 15)
• Peer-to-peer systems Napster, OceanStore (UCB),
  Farsite (MSR), Publius (ATT research) - see web
  for documentation on these recent systems

17
New design approaches

• Replicated read-write files
• High availability
• Disconnected working
• re-integration after disconnection is a major
  problem if conflicting updates have occurred
• Examples
• Bayou system (Section 14.4.2)
• Coda system (Section 14.4.3)

18
Summary

• Sun NFS is an excellent example of a distributed
  service designed to meet many important design
  requirements
• Effective client caching can produce file service
  performance equal to or better than local file
  systems
• Consistency versus update semantics versus fault
  tolerance remains an issue
• Most client and server failures can be masked
• Superior scalability can be achieved with
  whole-file serving (Andrew FS) or the distributed
  virtual disk approach

• Future requirements
• support for mobile users, disconnected operation,
  automatic re-integration (Cf. Coda file system,
  Chapter 14)
• support for data streaming and quality of service
  (Cf. Tiger file system, Chapter 15)
