Title: What is RaID?


1
What is RaID?
  • Christopher J Dutra
  • Seton Hall University

2
What is RAID?
  • RAID stands for a redundant array of inexpensive
    disks. (sometimes inexpensive is replaced with
    independent).
  • RAID is a storage scheme in which many hard disks
    are bundled together in an array to act as one
    disk.
  • Developed by UC-Berkley scientists in 1987.

3
Benefits
  • Higher Data Security
  • Fault Tolerance
  • Improved Availability
  • Increased Storage Capacity with Integrated Disks
  • Improved Performance

4
Higher Data Security
  • A RAID can still operate if a single disk inside
    the RAID fails.
  • Also would not require any data to be restored
    from a backup disk.
  • Primary reason why people purchase RAIDs.

5
Tradeoffs
  • There are three components to RAID servers to
    consider when purchasing
  • Speed overall performance, capacity
  • Reliability amount of fault tolerance expected
  • Cost amount you are willing to spend.
  • General rule of thumb is pick two.
  • Also, for complex raid servers, hours of setup
    and maintenance is expected.

6
RAID Limitations
  • RAID wont protect data loss against
  • viruses
  • power surges
  • multiple hardware failures (sometimes)
  • sabotage
  • IMPORTANT MAINTAIN CURRENT BACKUPS.

7
RAID LEVELS
  • RAID 0 Files are broken into stripes of a
    user-defined size of the array, and stripes are
    sent to each disk in the array.
  • It has worse reliability than a hard disk, used
    for greater performance. Cheap to implement, but
    not very reliable. Must maintain current backups
    should RAID 0 fail.

8
Example of RAID 0
This is a four-disk, 16 KB
stripe size RAID 0 array.
Source www.pcguide.com
9
RAID 1
  • RAID 1 has its data duplicated on another hard
    disk. That way, should one of the hard drives
    fail, the other is operable until the faulty
    drive is replaced.
  • Also, a technique called duplexing provides fault
    tolerance against either hard drive or the RAID
    controller.
  • Performance is compromised slightly.

10
RAID 5
  • RAID level 5one of the most popular RAID
    configurations, RAID 5 stripes both data and
    parity information across three or more drives.
  • Fault tolerance is maintained by ensuring that
    the parity information for any given block of
    data is placed on a drive separate from those
    used to store the data itself. (pcguide.com)

11
Example of RAID 5
This is a four-disk, 16 KB stripe size RAID 5
array.
Source www.pcguide.com
12
Why buy RAID?
  • Business servers provides data protection
    (especially good for when loss of data could
    cripple a business)
  • Workstations for graphical design, video
    editing, a RAID system would improve the
    performance of high-overhead programs (such as
    3dStudio Max).
  • Regular PCs do not necessarily need RAID, could
    help in the future though (as video games and
    other applications become more costly in
    resources).
