Title: CMC/CC A Visual Communication


1
CMC/CC AVisual Communication
  • Master IK, CIW, MMI
  • L.M. Bosveld-de Smet
  • Mon. 27/11/06 16.00-18.00

2
Outline
  • Varieties of visualizations
  • Visual communication in general
  • Obvious advantages of pictures
  • Important general concepts

3
Carbon Cycle
4
Elastic Collision
5
Weather Map
6
Alzheimers Disease Brains
7
Visits Respiratory Disease
8
Differences
9
Good and Bad Pictures
  • Bertin, 1967
  • Combien de dessins admirablement exécutés et
    richement reproduits ne communiquent quune
    information dérisoire et inutile? Que de papier
    et de couleurs perdus. Tandis que des croquis
    malhabiles mais correctement construits
    deviennent les meilleurs instruments de la
    découverte et de la pédagogie
  • Tufte, 1983
  • Graphical excellence
  • consists of complex ideas communicated with
    clarity, precision, and efficiency
  • is that which gives the viewer the greatest
    number of ideas in the shortest time with the
    least ink in the smallest space
  • requires telling the truth about the data

10
Visual Communication simplified
11
Natural vs. Unnatural Link
c
c
b
a
b
a
12
Misleading Link
Gregory
Charles
Bill
13
Visual Communication more complex
Data Tables
Visual Structures
Raw Data
Views
Data Transformations
Visual Mappings
View Transformations
14
Monk Puzzle (Winn, 1987)
  • A monk went to the temple at the top of a holy
    mountain to meditate and pray. He started out
    early one morning along the path that led up to
    the temple. Because he was an old man, and the
    way was steep and arduous, he frequently slowed
    his pace, and even sat and rested a while beside
    the path. Toward evening, he came to the temple
    at the top.
  • After several days of meditation and prayer, it
    was time for him to leave. Early in the morning,
    he set off back down the path. Again, he
    frequently changed his pace and rested by the
    way. He arrived back at the bottom in the
    evening.
  • Show that there is one single point on the path
    up the mountain where the monk will be at
    precisely the same time both when he goes up and
    when he comes down.

15
Advantages Visualization
16
Shimojima (2004)
  • Inferential and Expressive Capacities of
    Graphical Representations Survey and Some
    Generalizations
  • Crucial traits of varieties of visual
    representations
  • Free ride properties
  • Auto-consistency
  • Over-specificity
  • Meaning derivation properties

17
A toy example
Suppose
  • Piet, Jan, Wim, Anna, Mieke join in a running
    competition.
  • They run the race for themselves and finish each
    in a different time (no ties).

18
Comparison of different modalities
  • We can use different representations for the
    information that Jans score is better than Piets

19
  • Formula first-order logic (FOL)
  • 2-place predicate
  • DEFEAT
  • with 2 arguments
  • jan and piet

20
Position diagram (PD) Horizontal relation of
names indicates order of arrival of participants.
21
English well-formed sentence meaning that Jan
defeated Piet, i.e. that Jan ran the race faster
than Piet did.
22
PD more in detail
  • Syntactic rules
  • Two or more of the names Jan, Piet, Wim,
    Anna, and Mieke appear in a horizontal row.
  • The same name appears at most once.
  • Semantic rules
  • If the name X appears to the left of the name Y,
    the bearer of X defeated the bearer of Y.

23
1. Free Ride
24
Difference 1
  • Represent the following information
  • Jan 16.34 Piet 20.80 Mieke 25.40

ENGL.
Jan defeated Piet and Mieke was beaten by Piet.
25
The PD adds information for free that is not
available in FOL nor in English
26
  • In PD, expressing certain sets of information
    results in the expression of additional,
    consequential information.

Free rides

27
Other exampleVenn diagrams
  • Represent All As are Bs No Bs are Cs.

Expressing certain sets of information results in
the expression of additional, consequential
information No As are Cs
28
Other exampleEuler circles
  • Express
  • A ? B
  • C n B Ø

Free ride C n A Ø
29
Another example maps
  • Express
  • Bs house is in front of Fs house on the other
    side of the river.

30
Barwise Etchemendy (1990)
Diagrams are physical situations.As such, they
obey their own set of constraintsBy choosing a
representational scheme appropriately, so that
the constraints on the diagrams have a good match
with the constraints on the described situation,
the diagram can generate a lot of information
that the user never need infer. Rather, the user
can simply read off facts from the diagram as
needed.
31
Assumption
A representation X expresses information about
the represented object Y by having a property
that indicates the corresponding property of Y.
Property a
Represented object Y
indicates
Representation X
Property a
32
Example of PDs
Jan defeated Piet
A particular competition
indicates
A specific PD
name Jan appears to the left of name Piet
Jan Piet
33
Example Euler circles
A ? B
A specific group of circles
indicates
A specific Euler diagram
circle A appears inside circle B
34
Condition for Free Ride in PD system
Jan defeated Mieke.
The name Jan appears to the left of Mieke.
The name Mieke appears to the right of the name
Piet
The name Jan appears to the left of the name
Piet
35
Free Ride Euler Diagram
C n B ø
C n A ø
A ? B
A circle C and circle B do not overlap.
A circle A appears inside another circle B.
Circle C and circle A do not overlap.
36
Condition for Free Ride General
(Shimojima 1996a, 1996b)
constraint


constraint
Constraints on representations themselves track
constraints in the represented domain.
37
Thus
A system with a free-ride property supports
deductive inference through physical manipulation
of representations on an external display, not in
the head.
A (paradigm) case of distributed cognition
38
Recognition Problem
Free rides only guarantee the expression of
consequential information in the representation,
not its recognition by the user.
  • Cheap rides (Gurr, Lee, and Stenning 1998, Gurr
    1999)
  • Expertise in diagram construction to facilitate
    the recognition of useful consequences (Novak
    1995)

39
2. Over-Specificity
40
Difference 2
  • Express
  • Jan defeated Piet.
  • Mieke defeated Piet.

PD
?
?
Jan Mieke Piet
Mieke Jan Piet
English
Jan defeated Piet and Mieke defeated Piet.
41
  • Druk uit
  • Jan defeated Piet.
  • Mieke defeated Piet.

PD system cant express the info without
additional infowhile FOL and English can!
PD
?
?
Jan Mieke Piet
Mieke Jan Piet
42
  • In PD, certain sets of information cannot be
    expressed without expressing additional,
    non-warranted information.

Over-specificity

43
Another example Euler circles
  • Express
  • A ? B
  • C n B ? ø

Where to draw circle C?
A
A
B
B
44
Another example Maps
  • Express
  • Ks house is located between As house and Bs
    house.

Where to put this house?
45
Lawson (1997)
, there are some ways in which a picture can
often carry too much information or indicate a
degree of precision which may be
inappropriate.It would be difficult to construct
a drawing which did not suggest other features of
the form of the finished product which might
restrict a future designer. (p. 242.)
46
Analysis of over-specificity in PD
47
Analysis of over-specificity General
(Shimojima 1996b)
constraint
constraint
48
3. Derived Meaning
49
Difference 3
  • Express
  • Jan defeated Piet.
  • Anna defeated Jan.
  • Piet defeated Mieke.
  • Mieke defeated Wim

Jan defeated Piet, Piet defeated Mieke, Anna
defeated Jan and Mieke defeated Wim.
English
50
Express Jan defeated Piet. Anna defeated
Jan. Piet defeated Mieke. Mieke defeated Wim
You can count the names to find out the number of
participants satisfying a certain condition
51
  • In PD, some additional meaning relation holds
    that does not hold in FOL and English.
  • Moreover, that relation is derivative in that it
    is not written in basic semantic rules.

Derivative Meaning

52
Another example Table
Anna Jan Piet Mieke Wim
Jan Mieke Wim Anna Piet
Jan O O O
Mieke O
Wim
Anna O O O O
Piet O O
Number of circles in a column means the number of
participants that are not defeated
Number of circles in a row means the number of
participants that are defeated
Extra meaning relation
53
Analysis of derived meaning in PDs
(1) is valid
(1) at least 2 participants defeated Mieke

constraint
(1) at least 2 names are at the left of the name
Mieke

constraint
(1) is valid
54
Another example Scatter plots
From Tufte (1983)
  • The shape formed by dots means a general fact
    about the distribution
  • Existence of correlation,
  • Its strength,
  • Existence of an exceptional instance, etc.

Additional meaning relation
55
Kosslyn (1994)
Scatter plots...employ point symbols (such
as dots, small triangles, or squares) as content
elements. The height of each point symbol
indicates an amount. These displays typically
include so many points that they form a cloud
information is conveyed by the shape and the
density of the cloud. (p. 46.)
56
Thus
A representation system with a meaning derivation
property allows the simultaneous presentation of
local information and global information implied
by the local information.
57
Lowe (1989)
Indeed, the central purpose of many scientific
diagrams is to depict relationships and
interactions.If students are to understand such
diagrams, they need to be able to do more than
just decode the symbols used. They must also be
able to uncover and assimilate salient
relationships between the symbols that constitute
a diagram and appreciate how these relationships
map onto the real-world situation being
represented. (p. 28.)
58
Influencing Factors
  • Context (educational, professional, )
  • Nature of task (recall, recognition, problem
    solving, )
  • User s prior knowledge, skills, preferences,
    experiences,
