Bypassing Intrusion Detection Systems

1
Bypassing Intrusion Detection Systems

• Ron Gula, Founder
• Network Security Wizards

2
Ron Gula

• Wrote the Dragon IDS
• Tested, deployed and operated NIDS for major
  Internet company
• Designed a DOD network honeypot
• Technical expert for major IW exercises
• Penetration tested many networks
• Still learning ...

3
Why this talk?

• IDS solutions are not perfect
• IDS administrators are not perfect
• Security is a process!
• Not a person!
• Not a product!
• Intrusion detection is part of security !!!

4
Topics

• NIDS, HIDS, FW and HP Technology
• Technical Bypass Techniques
• Practical Bypass Techniques
• Conclusions

5
Network IDS

• Searches for patterns in packets
• Searches for patterns of packets
• Searches for packets that shouldn't be there
• May understand a protocol for effective pattern
  searching and anomaly detection
• May passively log, alert with SMTP/SNMP or have
  real-time GUI

6
Network IDS Limitations

• Obtaining packets - topology encryption
• Number of signatures
• Quality of signatures
• Performance
• Network session integrity
• Understanding the observed protocol
• Disk storage

7
Jane used the PHF attack!
/cgi-bin/phf
8
Jane did a port sweep!
NMAP
9
Host Based IDS

• Signature log analysis
• application and system
• File integrity checking
• MD5 checksums
• Enhanced Kernel Security
• API access control
• Stack security
• Network Monitoring Hybrids

10
Host Based IDS Limitations

• Places load on system
• Disabling system logging
• Kernel modifications to avoid file integrity
  checking (and other stuff)
• Management overhead
• Network IDS Limitations

11
messages
xfer
access_log
secure
sendmail
12
messages
xfer
One Security Log
access_log
secure
sendmail
13
Firewalls as an IDS

• Excellent source of network probe, attack and
  misuse information
• Detect policy deviations based on access control
  lists
• Some have NIDS capabilities

14
Network Honeypots

• Sacrificial system(s) or sophisticated
  simulations
• Any traffic to the honeypot is considered
  suspicious
• If a scanner bypassed the NIDS, HIDS and
  firewalls, they still may not know that a
  Honeypot has been deployed

15
Firewall
honeypot
HTTP
DNS
16
Technical Bypass Techniques

• NIDS
• fragmentation
• TCP un-sync
• Low TTL
• Max MTU
• HTTP Protocol
• Telnet Protocol

• HIDS
• Kernel Hacks
• Bypassing stack protection
• Library Hacks
• HTTP Logging

insertion techniques
17
IP 1
Session 1
IP 2
Session 2
IP 3
Session 3
FRAGMENT QUEUE
SESSION QUEUE
NIDS
18
IP 1
Session 1
IP 2
Session 2
IP 3
Session 3
FRAGMENT QUEUE
SESSION QUEUE
NIDS
19
Bypassing NIDS - Fragmentation

• NIDS must reconstruct fragments
• Maintain state drain on resources
• Must overwrite correctly more drain on
  resources
• Target server correctly de-frags
• Attack 1 - just fragment
• Attack 2 - frag with overwrite
• Attack 3 - start an attack, follow with many
  false attacks, finish the first attack

20
Bypassing NIDS - TCP un-sync

• Inject a packet with a bad TCP checksum
• fake FIN packet
• Inject a packet with a weird TCP sequence number
• step up
• wrapping numbers

21
Bypassing NIDS - Low TTL
NIDS
WWW
1
2
3
22
Bypassing NIDS - Max MTU
Segment with MTU 1300
NIDS
WWW
1350 byte packet with DF 1
23
Bypassing NIDS - HTTP Proto

• / padding /cgi-bin///phf
• Self referencing directories /cgi- bin/./phf
• URL Encoding 2fcgi-bin/phf
• Reverse Traversal /cgi-bin/here/../phf
• TAB instead of spaces removal
• DOS/Win syntax /cgi-bin\phf
• Null method GET00/cgi-bin/phf

24
Bypassing NIDS - Telnet Proto

• Strip out Telnet codes
• Automatic proxies which add random characters
  followed by backspace
• su Xbackspaceroot

25
Bypassing NIDS - Resources

• Tools
• Whisker - Rain Forest Puppy http//www.wiretrip.ne
  t/rfp/p/doc.asp?id21iface2
• Fragrouter - Dug Song http//www.anzen.com/researc
  h/nidsbench/
• Congestant - horizon, Phrack 54
• Papers
• Insertion, Evasion and Denial of Service
  Eluding Network Intrusion Detection, Tom Ptacek,
  Timothy Newsham http//secinf.net/info/ids/idspape
  r/idspaper.html
• Bro information ftp//ftp.ee.lbl.gov/papers/bro-C
  N99.ps.gz

26
Bypassing HIDS - Kernel Hacks

• Windows NT
• 4 byte patch that removes all security
  restrictions from objects within the NT domain.
• Could use access to disable or manipulate HIDS
• Linux - itfs.c - kernel module

- not in /proc/modules - hides a sniffer - hides
files - hides processes
- redirects execve() - socket backdoor - magic
setuid gets root
27
Bypassing HIDS - Stack Protection

• Stackguard
• A canary is placed next to return address
• Program halts and logs if canary is altered
• Canary can be random or terminating
• Bypass overwrite return address without touching
  canary
• Fix XOR the return address and the canary
• Point Yet another example of an arms race

28
Bypassing HIDS - Library Hacks

• Environment variables which redirect shared
  library locations
• Library has a wrapper run by a privileged
  program
• Two choices
• Provide certain APIs with original copies of
  Trojan files
• Redirect certain APIs to completely different
  files

29
Bypassing HIDS - HTTP Logging

• The anti-NIDS HTTP techniques also may work for
  host based IDS tools which do log analysis

30
Bypassing HIDS - Resources

• Phrack 51
• Shared Library Redirection Techniques,halflife,lt
  halflife_at_infonexus.comgt
• Bypassing Integrity Checking Systems,halflife,lth
  alflife_at_infonexus.comgt
• Phrack 52
• Weakening the Linux Kernel, plaguez
  ltdube0866_at_eurobretagne.frgt
• Phrack 55
• A real NT Rootkit, patching the NT Kernel, Greg
  Hoglund lthoglund_at_ieway.comgt
• Phrack 56
• Shared Library Call Redirection via ELF PLT
  Infection, Silvio Cesare
• Backdooring Binary Objects, ltklog_at_promisc.orggt
• Bypassing Stackguard and Stackshield, Bulba
  Kil3r ltlam3rz_at_hert.orggt
• Stackguard - http//www.immunix.org/documentation.
  html

31
Practical Bypass Techniques

• NIDS
• identifying
• avoiding
• overwhelming
• slow roll
• distributed scanning

• HIDS
• identifying
• log deletion
• log modification
• Generic
• Social
• DOS

32
NIDS - Identifying

• Is it in DNS?
• Does it shoot down connections?
• Is the sniffing interface detectable?
• Is it running on a big red box labeled IDS?
• Can the alert messages be observed?

33
NIDS - Identifying

• Any open ports that match a known IDS?
• Has the target posted to an IDS saying, We use
  product XYZ?
• Do they have a This site protected by XYZ
  message on their web site?

34
NIDS - Avoiding

• Are there other routes into the network?
• Is there an encrypted path?
• Modem dial in?
• Alternate transport layer? (GRE ???)
• Is there an attack not detected by the IDS?
• Is there a technical bypass technique that is not
  detected by the IDS?

35
NIDS - Overwhelming

• Send as many false attacks as possible while
  still doing the real attack
• May overload console
• May drop packets
• Admins may not believe there is a threat
• Send packets that cost the NIDS CPU cycles to
  process
• Fragmented, overlapping, de-synchronized web
  attacks with the occasional bad checksum

36
NIDS - Slow Roll

• Port scans and sweeps
• Obvious incremental destination ports
• Trivial randomized ports
• Sweep one port and many addresses
• Stealthy random ports and addresses over time

37
Plotting all destination ports from one source
IP to a target network
P o r t s
Port scan
Port sweep
IP addresses
38
random
Simple port walk
Still maps out a network with one IP address
P o r t s
IP addresses
39
MASTER
SLAVES
SLAVES
Target sees traffic from many addresses
40
HIDS - Identifying

• Almost always after on a system ...
• Is there anything in the system logs?
• What ports are open?
• What is running out of CRON?
• What is in the NT registry?
• What programs are running?

41
HIDS - Logs

• Simple log deletion may be possible
• Simple log altering may also be possible
• replace IP addresses to mislead
• delete key logs
• Logging may be disabled or intercepted
• Removing syslog from services

42
Generic - Social

• Physical access
• Obtaining official access
• Getting others to hack/scan site for you
• IRC chat groups
• Hacker challengers
• Run the IDS

43
Generic - DOS

• Find the main server
• Kill it
• IP Bomb
• Port bomb
• IDS DOS
• Find the clients

44
Contact Information

• rgula_at_securitywizards.com
• http//www.securitywizards.com
