Securely Enabling Intermediary-based Transport Services

1
Securely Enabling Intermediary-based Transport
Services
U. Blumenthal, I. Faynberg, S. Kasera,
S.Mizikovsky, G. Sundaram and T. Woo

Presented by Thomas Woo Bell Labs, Lucent
Technologies
2
Summary

• We provide motivations and problem statement of
  securely enabling intermediary-based transport
  services
• We present several concrete examples to highlight
  the problem
• We invite discussions on further defining the
  problem, and possible solutions

3
Motivation

• Access links mostly refer to wireless links
• 3G (UMTS, CDMA 2000)
• 802.11
• Satellitebut applies also to wireline links
  such as dialup and even cable
• These links exhibit many problems that affect
  end-to-end transport-level performance
• High loss up to 10-2
• High latency and variability of latency up to
  100s of ms
• Low bandwidth
• Variable bandwidth adaptive multi-rate
• Intermittent connectivity temporal signal lull
  due to mobility

4
Motivation (contd)

• Intermediary-based transport services can help
  mitigate many transport-level problems of access
  links
• Examples
• TCP PEPs (RFC 3135)
• Triggers for Transport

Server
Mobile User
Wireless Access Link
Wired Network
Transport Service Intermediary
TCP Connection
5
Problem Statement

• To perform its function, an intermediary may need
  to
• Signal to the end points
• Inspect or even modify the traffic sent between
  the end points
• Threats
• An attacker can send bogus signals to end points
• Existing end-to-end security may be compromised
• An attacker can gain unauthorized access to end
  to end traffic
• Need to securely enable intermediary-based
  transport services while minimizing impact on
  end-to-end security
• Solicitation and configuration of services
• Security relationships between end-points,
  intermediary

6
Solicitation and Configuration of Service

• Service discovery
• Especially important for mobile users
• Service consent
• End-points must consent to service offered
• Service configuration
• End-points, intermediary exchange parameters for
  configuring services
• Transfer of state
• Transfer service related state from one
  intermediary to another in the event of impending
  failure, load-balancing, or due to user mobility

7
Security Relationships betweenEnd-points,
Intermediary

• Signaling aspect
• Establish security relationship between
  end-points and intermediary
• Authenticate and authorize trusted intermediary
• One-to-one vs one-to-many
• Securely exchange control information
• Data aspect
• Securely reveal selected packet information to
  authorized intermediaries for processing
  (inspection and/or modification as authorized)

8
Example 1 TCP Enhancements

• Problem Large wireless link delay variance
  causes degradation in TCP throughput
• Solution TCP PEP RFC3135
• Example Ack Regulator Mobicom 2002
• regulate acks from mobile user at intermediary to
  account for downlink delay variance

9
Example 1 TCP Enhancements (contd)

• Requirement AR mechanism relies on TCP header
  information
• TCP port numbers for flow identification
• TCP sequence number for ACK pacing

How do we securely enable TCP PEP service such as
AR?
10
Example 2 Header Compression

• Problem Access link bandwidth tends to be
  limited
• Solution Header compression/decompression close
  to access link with the help of an intermediary
  could be used RFC 1144, RFC 2507, RFC 3095,
  SRTP
• An end-to-end IPsec tunnel between the two
  end-points would prevent header compression at an
  intermediate node

Can we support header compression and have good
security at the same time?
11
Example 3 Network-based Packet Filtering

• Problem Spoofed IPsec packets to VPN client can
  consume valuable transport resources, especially
  in bandwidth-limited wireless links
• Solution Network-based packet filtering
• Issue Client mobility requires dynamic
  configuration, invocation and revocation of
  network-based filters

Attacker sends address-spoofed, IPSec encrypted
packets to mobile user
Attacker
Enterprise VPN Gateway
VPN Client
Wireless Access Network
Packet Filter
Internet
End-to-End IPSec Tunnel
12
Example 4 Triggers for Transport

• Problem An access link can go up, go down and
  change rate
• Solution TrigTran intermediary to notify
  transport end systems of such events
• Issue Such notifications should be performed in
  a secure manner

See next presentation
13
Issues to Explore in Architecture

• Characteristics of intermediary-based transport
  services
• Their need for packet processing and signaling
• Support for multiple intermediaries in an
  end-to-end path?
• One-to-one vs one-to-many security relationship
• Association of intermediary with access links
• How to minimize the impact on end-to-end
  security?
• Protocol Functions
• How to reliably and securely configure, invoke
  and revoke intermediary-based transport services
  from the end systems?
• How does the intermediary obtain the information
  needed to offer services?
• Applicability of existing mechanisms, e.g., IKE
  for key exchange?

14
Conclusion

• Our draft
• Describes the problem of securely enabling
  intermediary-based transport services
• Identifies example scenarios

15
BackUps
16
TCP Enhancements

• Problem Large wireless link delay variance
  causes degradation in TCP throughput

17
TCP Enhancements (contd)

• AR improves throughput significantly over Reno,
  Sack (up to 50)
• Higher proportional improvement at smaller buffer
  size
• AR throughput improvement robust against buffer
  size

18
Intuition

• TCP's window-based congestion control functions
  by estimating the available bandwidth-delay
  product. A loss happens when the congestion
  window exceeds the available bandwidth-delay
  product (BDP)
• Large delay and/or rate variation causes the
  available BDP to vary as well. Thus, TCP's
  window-based congestion control may trigger a
  loss even when the congestion window is
  significantly below the "average" BDP but larger
  than the instantaneous BDP
• If the instantaneous BDP shrinks by sufficiently
  large amount, multiple packets can be lost at the
  same time, causing further window backoff and
  even timeouts

19
Multimedia Packet Differentiation

• Example Differentiated packet treatment based on
  network congestion condition using multimedia
  transport header Keller et al (Infocom 2000)

Video Server
Video Receiver
Packet Filter
Congested Link
Drop Lower Priority Layers
Multi-layer Video Unicast
20
Multimedia Packet Differentiation (contd)
No Differentiated Packet Treatment plain queuing
High frequency subbands
Low frequency subbands
Differentiated Packet Treatment dropping low
priority layers

• Grey level shows amountof data received in 5
  frames
• white nothing received
• black everything received

time
Dramatic improvement in video quality
slide is taken from Keller et. al.s INFOCOM
2000 presentation
21
Multimedia Packet Differentiation (contd)
Plain No differentiated packet filtering Active
Differentiated dropping of low priority
layers Burst Congestion burst
22
Header Compression Benefits

• TCP/IP headers reduced from 40 octets to 4 octets
  (RFC 2507)
• 6 savings for 576 octet packets but 90 savings
  for ACK only packets
• RTP/UDP/IP headers reduced from 40 bytes to 1
  octet under steady state (RFC 3095)
• 65 savings for 60 octet speech packets
