PLC Integration

1
PLC Integration

• Franck Di Maio
• AB/CO/FC

2
Outline

• Hardware architecture
• Software
• FESA vs GM
• Target for 2004

3
FEC Hardware

• Front-end computers are
• VME-based, PPC CPU (from CES), LynxOS, Timing
  Receiver (CTRP in 2004).General purpose.
• PC-based (3U rack), Intel CPU, LynxOS (Linux
  later), Timing Receiver (CTRP also)Only for
  Gateways (FIP).
• cPCI-based, Intel CPU, LinuxOnly for OASIS
  (analog signals)
• Any Linux system running front-end software

4
IP Gateways

• For IP gateways (as for PLC), 2 possibilities
• FEC local LynxOS system with timing
  reception, preferably on the same Ethernet
  Switch. If synchronization with timing is
  required (ex Linac RF).
• Server central Linux system on Technical
  network (later with timing reception).

5
Front-end Software, Components
Infrastructure
Communications
Equipment access read, write, monitor (logging)
General Control Services
Equipment Software
Timing interface System monitoring Alarms
reporting Post-mortem transmission
Hardware Interface
Drivers I/O libraries for embedded boards and
field-buses
(from LHC Review)
6
Front-end Software for PLC
Java Application
Requests get/set/subscribe on device property
( cycleSel)
CMW
Front-end Software (C/C)
(timing)
IEPLC
Data mapping
PLC Software
7
Data Mapping
Class XX
dev1
dev2
FEC
CMD
CFG
AQN
CMD
AQN
PLC
CFG
8
Requests Handling
(timing)
Write CMD
Data
Set PropX
Java App.
PLC
CCV
Read AQN
Update PropY
AQN
(timing)

• 2 types of Request
• Simple/generic interfacing a data variable with
  generic treatment (for specialist)
• Specific code (for operation)

9
FESA

• The Dark Age
• BISCoTO _at_ SL/BDI (and AB/BDI)
• GM _at_ PS/CO (and AB/CO/FC) ? PLC integration
• The FESA era
• BISCOTO -gt FESA 1.0 (from Nov 03)
• GM -gt FESA 2.0 (from June 04)
• GM-gtFESA impact
• Composite property (ex CMD) for Java Application
• Productive C development environment for FE
  software.
• Same for CO and BDI.

10
Nodal
11
Data Module
12
SL-Equip
13
2004

• With
• Data defined in PLC
• Specs of the properties for application (in
  modern SL language, please!)
• We can make FESA classes before the shutdown
• We will maintain only generic pieces
• We wont provide backward compatibility for
  Nodal/Data-module/SL-Equip
