3D Geometric Transformations

1
3D Geometric Transformations
2
Kinds of Transformations

• Translation
• Rotation
• Reflection
• Scaling
• Shearing

NOTES

• These transformations are an important component
  of computer graphics programming
• Each transformation type can be expressed in a (4
  x 4) matrix, called the Transformation Matrix

3
Translation
Moving the object from one position to another
4
Rotation

• Rotating the object about an axis

5
Reflection
Mirroring an object about a plane
6
Scaling
Reducing or enlarging the object
7
Shearing
Moving selected vertices of an object linearly
along an axis
8
AutoCAD Transformation Commands
9
Rotations Positive and Negative
10
Rotations Positive about x,y,z
11
Multiple Rotations
12
3D Transformations

• The End
