Clive Butler

1
Single-pass Cache Optimization
Clive Butler and Ruofan Yang

• Clive Butler

2
Introduction of Problem

• Embedded system execute a single application or a
  class of applications repeatedly
• Emerging methodology of designing embedded system
  utilizes configurable processors
• Size, associativity, and line size.
• Energy model and an execution time model are
  developed to find the best cache configuration
  for the given embedded application.
• Current processor design methodologies rely on
  reserving large enough chip area for caches while
  conforming with area, performance, and energy
  cost constraints.
• Customized cache allows designers to meet tighter
  energy consumption, performance, and cost
  constraints.

3
Introduction of Problem

• In existing low power processors, cache memory is
  known to consume a large portion of the on-chip
  energy
• Cache consumes up to 43 to 50 of the total
  system power of a processor.
• In embedded systems where a single application or
  a class of applications are repeatedly executed
  on a processor, the memory hierarchy could be
  customized such that an optimal configuration is
  achieved.
• The right choice of cache configuration for a
  given application could have a significant impact
  on overall performance and energy consumption.

4
Introduction of Problem

• Estimating the hit and miss rates is fairly easy
  using tools such as Dinero.
• Can be enormously time consuming to do so for
  various cache sizes, associativities and line
  sizes.
• To use Dinero to estimate cache miss rate for a
  number of cache configurations means that a large
  program trace needs to be repeatedly read and
  evaluated which is time consuming.
• Very time consuming.

5
Dinero

• Dinero is a trace-driven cache simulator
• Simulations are repeatable
• One can simulate either a unified cache (mixed,
  data and instructions cached together) or
  separate instruction and data caches.
• Cheaper (Hardware)

6
Dinero

• A din record is two- tuple label address.
• Cache parameters are set by command line options
• 0 read data, 1 write data, 2 instruction fetch. 3
  escape record, 4 escape record (causes cache
  flush).
• Dinero uses the priority stack method of memory
  hierarchy simulation to increase flexibility and
  improve simulator performance in highly
  associative caches.

7
Introduction Method 1
Introduction Tree-base Method

• Presents a methodology to rapidly and accurately
  explore the cache design space
• Done by estimating cache miss rates for many
  different cache configurations simultaneously
  and investigate the effect of different cache
  configurations on the energy and performance of a
  system.
• Simultaneous evaluation can be rapidly performed
  by taking advantage of the high correlation
  between cache behavior of different cache
  configurations.

8
ASP-DAC paper
General Simulation Process
m(max)..m(min)..0
Cache addr.
tag
Array (stores tree addresses)
Tree
Step 1 index
Step 3 Find node and go link list
Cache Miss Table
Step 2 Go to tree addr. and traverse the list
Link List
L N A of cache miss







Step 4 Look for match
9
ASP-DAC paper
Tree example
1010
101(0)
101(1)
Cache Size 2
10(10)
10(00)
10(11)
Cache Size 4
10(01)
Cache Size 8
1(010)
1(011)
1(101)
1(001)
1(110)
1(000)
1(100)
1(111)
Cache addr.
tag
1010
Assume each forest has fix line size
Bits are use find path (k)
10
ASP-DAC paper
Link list set associative
Assoc. 1
Assoc. 4
Assoc. 2
Hit
Hit
Hit
Miss
Most recent element used
Least recently used element
Table for Miss Count
of Cache Miss
N
L
A
1 4 1 0
1 4 1 1
Rest of address is use as tag
11
ASP-DAC paper
Link List LRU update
Assoc. 1
Assoc. 4
Assoc. 2
Most recent element used
Least recently used element
Table for Miss Count
of Cache Miss
N
L
A
1 4 1 0
1 4 1 1
12
Detail Trace Example
Example Specifications

• Cache Size (N) will vary from 32 bits max to 2
  bits min
• Associatively (A) will vary from 4 max to 1 min
• Cache Set Size (M) will vary from 8 max to 1 min

• Assume fix line size (L)

13
Detail Trace Example
Instruction Trace k m 1. 000000 gt 0 2.
001000 gt 8 3. 010000 gt 16 4. 000000 gt 0 5.
001000 gt 8 6. 000000 gt 0 7. 010000 gt 16
Assoc. 1
L N M Miss Count
1 8 8 3
1 4 4 3
1 2 2 5
1 1 1 7
1
2
3
1
2
3
M1
0
8
16
0
8
0
16
1
2
3
4
5
1
2
3
4
5
6
7
M2
0
1
0
8
16
0
8
0
16
M4
00
11
10
01
16
8
0
0
8
0
16
M8
000
001
010
011
100
101
110
111
16
8
0
0
8
0
16
14
Detail Trace Example
Instruction Trace k m 1. 000000 gt 0 2.
001000 gt 8 3. 010000 gt 16 4. 000000 gt 0 5.
001000 gt 8 6. 000000 gt 0 7. 010000 gt 16
Assoc. 2
L N M Miss Count
1 16 8 3
1 8 4 3
1 4 2 3
1 2 1 6
M1
0
8
0
16
8
0
16
8
0
0
8
16
0
1
2
3
4
5
6
M2
0
1
M4
00
11
10
01
M8
000
001
010
011
100
101
110
111
15
ASP-DAC Results

• Using benchmarks from Mediabench
• This method is on average 45 times faster to
  explore the design space.
• compared to Dinero IV
• Still having 100 accuracy.

16
Introduction Table-based Method

• Two cache evaluation techniques include
  analytical modeling and execution-based
  evaluation to evaluate the design space
• SPCE present a simplified, yet efficient way to
  extract locality properties for an entire cache
  configuration design space in just one
  single-pass
• Includes related work, overview of SPCE,
  properties for addressing behavior analysis to
  estimate the cache miss rate, experiment and the
  results

17
Related Work

• Much research exist in this area need multiple
  passes to explore all configurable parameters or
  employ large and complex data structures, which
  restricting their applicability
• Algorithms for single-pass cache simulation exams
  concurrently a set of caches. Mattson Hill and
  Smith Sugumar and Abaham Cascaval and Padua
• Janapsatya et al. present a technique to evaluate
  all different cache parameters simultaneously,
  but not designed with a hardware implementation
  in mind
• This papers methodology use simple array
  structures which are more amenable to a
  light-weight hardware implementation

18
SPCE Overview
19
Definitions

• Time ordered sequence of referenced addresses --
  Tt (t is a positive integer),length T, such
  that Tt is the t(th) address referenced
• If Tti b Tti d b, then the
  addresses Tti and Tti d, are references to
  the same cache block of 2b words
• Define d as the delay or the number of unique
  cache references occurring between any two
  references where Tti
• b Tti d b

20
Definitions

• Evaluate the locality in the sequence of
  addresses Tti of a running application ai by
  counting the occurrences where Tti
• b Ttid b and registering it in
  the cell L(b, d) of the locality table.(2b is
  block size , d is delay)

21
Fully-Associative

• A fully-associative cache configuration is
  defined by the notation cj (b, n), where b
  defines the line size in terms of words, and n
  the total number of lines in the cache
• The locality table L(b, d) composes an efficient
  way to estimate the cache miss rate of
  fully-associative caches

22
Fully-Associative Example
Locality table for the trace T
T
t0 0
t1 8
t2 16
t3 0
t4 8
t5 0
t6 16
T b0
t0 0
t1 1
t2 2
t3 0
t4 1
t5 0
t6 2
d3
d b0
1 0
2 1
3 3
4 0
T b
d2
A sequence of addresses
23
Set-Associative

• Most real-world cache devices are built as
  direct-map or set-associative structures
• Since conflicts, L cannot be used to estimate
  misses , so define s as the number of sets
  independent of the associativity, for
  direct-mapped, set size1, sn
• To analyze the cache conflicts, we build conflict
  table Ka (b is block size, s is set size), which
  in composed of a layers, one for each
  associativity explored

24
Set-Associative
25
Set-Associative

• The value stored in each element of the table
  Ka(b, s) indicates how many times the same block
  (size 2b) is repeatedly referenced and results
  in a hit.
• A given cache configuration with level of
  associativity w is capable of overcoming no more
  than w - 1 mapping conflicts.
• The number of cache hits is determined by summing
  up the cache hits from layer a 1 up to its
  respective layer a w, where w refers to the
  associativity.

26
Algorithm Implementation
27
Experiment Setup

• Implement SPCE as a standalone C program to
  process an instruction address trace file,
  gathered instruction address traces for 9
  arbitrarily chosen from Motorolas Power Stone
  benchmark suite using Simple Scalar
• Since 64 bytes is the largest block size in the
  design space utilized, bmax3 smax is defined by
  configuration with the maximum number of sets in
  the design space
• Exam performance for our suite of benchmarks with
  SPCE and also with a very popular trace-driven
  cache simulator (DineroIV)

28
Results

• Compare performance of SPCE and DineroIV for the
  45 cache configurations.

29
Conclusion

• Both Tree-based method and Table-based method
  (SPCE) facilitate in ease of cache miss rate
  estimation and also in reduction in simulation
  time.
• Compared to DineroIV method, the average speedup
  is around 30 times.
• Our future work includes extending the design
  space exploration by considering of a second
  level of cache.
