HCI and Groupware

1
HCI and Groupware

• Storyboards

2
Prototyping

• A means of developing the front end of an
  application and seeking user approval for it
• One method is to produce a working version
  using a prototyping tool
• access
• vb
• case tools

3
working version

• Ranges from
• Just the screens
• One function, fully working
• All the functions, but no error checking
• Coded as quickly as possible
• Recommended to throw the prototype away

4
Storyboard

• Just the screen layout
• or
• a graphical depiction of the outward appearance
  of the intended system without the accompanying
  system functionality
• Dix et al - HCI

5
Advantages

• Can be paper based
• Application independent
• little or no skills required !
• Apart from the ability to draw
• and think
• and design
• etc.

6
Disadvantages

• Requires the designer to draw !
• Does not provide a realistic front end (paper
  based)
• Takes little account of what might be possible.
• Does not provide functionality

7
Origins

• Film industry
• series of panel, roughly depicting snapshots

8
Reasons why

• Evaluating customer / user impressions of
  proposed system
• Gauge what is needed
• and what is missing
• NB all the above are reasons for prototyping
  generally rather than specifically storyboarding.
