Level 1 Muon TriggerAlgorithms and Simulation
Pete Johnson University of Arizona for the L1
Muon Group
2
tsim_l1muo Status
Inputs

• Switch inputs from MuoDigi chunk to Raw or
  UnpData chunk
• Waiting for MF utilities (available but not
  tested?)
• Conform to changes in L1CFT
• Done but must eventually switch to l2io classes
• Parsing trigger information from CoorMgr messages
• Done but must be tested (with Amber)

3
tsim_l1muo Status
Algorithms

• Update MTM mapping so that hardware/documentation/
  simulator agree
• Code done but not completely tested
• Optimize 05 and 10 algorithms
• In progress
• Some code reorganization and bug fixes
• In progress

4
tsim_l1muo Status
Outputs

• Implement DataFlow mechanism for communication
  with L1TF, L2, and L3
• Code written and somewhat tested
• L2 and L3 raw data defined
• Need feedback (or simple OK) to define the
  classes
• Aside, do we just drop all unpacked data code?

5
tsim_l1muo Goals

• Finish work on previous slides.
• 2-3 weeks
• Reproduce summer L1MU trigger efficiency and rate
  results
• 2-3 weeks
• Integrate with D0sim
• 3-4 weeks
• It would be sooner but we have a DOE site visit
  at the end of September
• Automate trigger result comparision using
  hardware and simulator
