Veiligheidsintroductie BASF Antwerpen

1
Welcome to
BASF Antwerp
2
Foreword

• Your and our safety are very important. That is
  why a chemical company has procedures you need to
  know. This presentation discusses the most
  important regulations.

• Also, always request your superior, experienced
  colleagues or client for detailed information.
  There is no such thing as a silly question!
• Working safely demands that you recognise the
  dangers and safeguard yourself and your
  colleagues.
• In any case we hope you have a safe and
  successful stay in our company!

W. De Geest Managing Director
3
Safety charter

• All accidents can be avoided! This is possible
  through a far-reaching prevention policy and a
  safety culture that is respected by EVERYONE.
• Everyone is responsible for their own safety and
  that of their colleagues.
• Anyone who works for us needs to work safely and
  will be assessed on this as well as appreciated
  for it.
• We are entitled to monitor any activities,
  prohibit the use of unsafe equipment, tools
  and/or work methods and to stop the work.
• This applies to everyone!

4
1. HAZARDOUS PRODUCTS
5
Presence of hazardous products

• Our installations contain many hazardous
  products.
• Hazardous products are indicated with symbols.

6
Presence of hazardous products and protection

• Special personal protective equipment needs to be
  worn AT ALL TIMES
• when you work with hazardous products.
• when you work in or at a production installation.

7
Hazardous products health danger
8
Hazardous products fire, explosion and
environmental danger
9
Use of emergency and eye showers

• With EVERY contact of the product with skin or
  eyes the emergency or eye shower needs to be
  used.
• Before starting work find out where the closest
  emergency and eye shower is located.
• Emergency and eye showers have been indicated
  with the following pictograms

10
Operation of emergency and eye showers

• Proceed as follows

1. Press the RED handle.
2. Press the alarm panel with your knee. This
will notify the control room.
3. Remove any covered clothing.
4. Rinse at least 15 minutes.
11
Product contact after care

• EVERY contact with a product (however minimal) as
  well as any injury needs to be looked after by
  the BASF medical facilities (building B 520).
• An injury can have serious consequences!
• The medical facilities are manned every day,
  24/7.
• In case of an accident call 777 (internal
  emergency number).

12
2. PERSONAL PROTECTIVE EQUIPMENT (PPE)
13
Personal protective equipment (PPE)

• PPE, provided by your employer, need to protect
  you against any other risks.
• Everyone in the installation IS OBLIGED to wear
  the following personal protective equipment at
  all times

14
Personal protective equipment (PPE matrix)

• Specific PPE is laid down per plant in the PPE
  matrix.

15
3. PROHIBITION SIGNS
16
Prohibited on our site
17
Prohibited on our site
General GSM prohibition in all production
installations.

• Explosion safe GSM allowed in production
  installations provided
• approval by BASF-service
• ALWAYS with fluorescent yellow
• cover

EX-GSM also prohibited in areas with this
pictogram.
18
Prohibited on our site
19
4. WARNING - PICTOGRAMS
20
(No Transcript)
21
5. ACCESS REGISTER TRAFFIC
22
Register in the companies

• If you pass the access test, you will receive a
  PERSONAL badge that you must carry on your person
  at all times.
• Anyone entering a production installation,
  building or workshop needs to register via an
  M-reader.
• Hold your badge in front of IN to badge in
• Hold your badge in front of UIT to badge out

• Don't forget to badge out when leaving
• the production installation, building or
• workshop!

23
Traffic guidlines

• The train, the intervention service and the
  ambulance always have right of way. Pay attention
  at unguarded level crossings!

• Max. 30 km / hour

• Seatbelts are compulsory in vehicles

• Only HANDS-FREE use of GSM

• Do not park in front of fire hydrants,
• under pipe bridges and near the track!

24
Traffic Rules - cyclists

• It is MANDATORY for all cyclists to wear a
  fluorescent vest on the BASF site !
• For pedestrians it is recommended to wear
  a
  fluorescent vest !
• Exception
• Not mandatory in case of commuter traffic

  to and from the gate, but then

  a bicycle light is
  mandatory !

25
6. PERMITS
26
Permits

• A permit can only be obtained by people with
  special training.
• Every permit needs to be on-site with the person
  executing the works.
• The permits need to be shown at the simple
  request of a BASF employee.
• We will discuss the different permits

27
A-permit (work permit)

• The A-permit is necessary for any work carried
  out on the site!

28
A-permit (work permit)

• The measures you need to take on top of the
  standard measures are indicated on the permit.
• The regulations on the permits need to be
  explained by your superior.
• The permit needs to be signed overleaf by any
  person working on the site by way of acceptance
  of the regulations.

29
B-permit (access permit)

• A B-permit allows you to access tanks, columns or
  other enclosed spaces.
• The measures you need to take on top of the
  standard measures are indicated on the permit.
• A safety supervisor needs to be present at all
  times.

• UNDER NO CONDITION may these areas be entered,
  not even briefly or partly, without a B-permit!

30
V-permit (fire permit)

• The A-permit combined with a V-permit allows you
  to make fire or sparks but not to smoke!

• Within a safety zone (Ex-zone), marked with
  red-white poles and chains there is a high fire-
  and explosion hazard. To use non-explosion safe
  devices in this zone a V-permit is required (e.g.
  for vehicles).

31
V-permit for welding and grinding work

• A fire extinguisher needs to be on hand in case
  of welding and grinding work.

• Welding equipment needs to be certified by BASF
  (see label)!

32
G-permit

• A G-permit is necessary for all underground
  activities!

33
7. INSTALLATIONS - MACHINES
34
Electrical machines and cables

• Machines with damaged cables constitute a major
  electrocution hazard and may never be used.
  Electrical machines and cables need to be in
  perfect condition.

• Keep cables away from passages and stairs as much
  as possible. Preferably use S-hooks to hang up
  cables.

35
Demarcations

• If you carry out work that is hazardous for
  others (e.g. assembly work, sandblasting,
  hoisting), the risk area needs to be demarcated
  (e.g. with signalisation ribbon).

• Newly-built platforms, holes, need to have a
  solid barrier (in wood or metal).

36
Scaffolding

• Scaffolding may only be used when a valid
  S-permit is present.

• No changes (not even temporarily moving a plank)
  are allowed to be made by unauthorised people.
• Order and cleanliness, also on scaffolding!

37
Fall protection

• In case of activities at height, fall protection
  is necessary.
• Collective personal protective equipment is
  preferred. If this is not possible fall
  protection harnass needs to be worn.
• Wearing and securing fall protection is
  compulsory in a cherry picker.

38
Order and cleanliness

• After the work the work site needs to be cleaned
  up always and everywhere! This is the sign of a
  real professional.

39
8. ALARM PLAN
40
Reporting an accident

• In case of
• an accident,
• a gas leak,
• a fire
• Call the internal emergency number

777

• If necessary an alarm signal will be activated.
  There are 3 different alarm signals.

41
Alarm signal WARNING ALARM

• Siren

• Meaning
• Hazard OUTSIDE the plant
• Actions to be taken
• stop all work
• shut windows and doors
• go to the alarm reader ( A-reader) in the plant
  where you are located

42
Alarm signal EVACUATION ALARM

• Siren

• Meaning
• Hazard IN the immediate vicinity
• Move away from the wind AT A RIGHT ANGLE
• Actions to be taken
• stop all work, shut windows and doors
• go to the nearest plant indicated on the alarm
  card
• go to the alarm reader in the designated safety
  oasis (see alarm card)

43
How to recognize a plant in alarm

• When there is an alarm in a plant, the orange
  flash bulb on top of the IN-reader is on.
• Go immediately to the A-reader of the indicated
  meeting point.

44
Alarm signal END OF ALARM

• Siren

• All permits fall due at the end of the alarm
  and need to be issued again.
• At the end of the alarm after evacuation you need
  to re-register (badge) at the plant that you
  left.
• Test alarm every 1st Thursday of the month at
  12.00. This test alarm starts with an end of
  alarm. Do not react to these alarms.

45
Indication A-reader

• The alarm reader ( A-reader) is indicated as
  follows

46
STOP ALARM poles on the site

• When the red rotating light on an alarm pole is
  on and the text STOP ALARM appears
• Stop your vehicle and wait.
• Or you can turn around and take another, safer
  route.
• If you hear sirens in the vicinity
• - park your car, turn off your engine
• AND
• - go to the nearest meeting point
  (A-reader)

47
Alarm cards

• Every plant issues ALARM cards with assembly
  points in case of a warning and evacuation.
  Please ask! (available in Dutch, German, English
  and French).

48
9. WELCOMEBROCHURE TEST
49
Welcoming brochure Test

• We hope you understood these instructions.
• You need to pass the test to receive your
  personal BASF badge.
• You can read all these safety instructions again
  in the welcome brochure that you will receive at
  reception.
• Good luck and work safely!
