Case Discussion

1

A 54-Day-old Premature Girl with Respiratory
Distress and Persistent Pulmonary Infiltrates

• Case Discussion
• FAU Erlangen 13.12.2002

Wolfgang Freisinger
2
Chief Complaint

• A 54-day-old girl was admitted to the hospital
  because of recurrent respiratory distress and
  failure to gain weight

3
SH - Mother

• 38-year old woman ( gravida 2, para 0 )
• Group B, Rhesus positive blood
• Immune to rubella, negative serologic test for
  syphilis
• Smoking during pregnancy
• Less than 1 pack a day
• Respiratory tract infection several weeks before
  delivery
• Treatment with erythromycine was successfull

4
PMH - Child

• Delayed fetal growth
• Born at 35 ½ weeks gestation by urgent cesarean
  section, performed after detection of meconium on
  amniocentesis and increased fetal heart rate
• Birth weight was 1520g
• Is she a high-risk-infant ?
• Yes, because of underweight, premature birth,
  mother smoking, meconium stained fluid
• APGAR 7 after one minute, 8 at five minutes, no
  resuscitation was required

5
PMH - Child (2)

• Stable during and after brief administration of
  supplemental oxygen
• No evidence of meconium aspiration
• Placenta was small and showed a small, healed
  infarct
• Tests for CMV and toxoplasmosis were negative

6

• 9.400 34.00054-623-5
• 25-333-71-30-0,75
• 1,500-3,000/mm³84,000-478,00048-69

7
HPI 4th day of life

• child was transferred elsewhere for feeding and
  growth

8
HPI 8th day of life

• Development of a diaper rash
• No response to multiple measures
• Alternatives to cow milk dont bring any benefit


9
(No Transcript)
10
HPI 26th Day of Life

• Child is in tachypnea, with intercostal
  retractions

11
CXR 26th day of life
Anteroposterior Film of the Chest on the 26th Day
of Life. The lungs are hyperinflated, with
bilateral streaky opacities in a parahilar,
peribronchial distribution. The heart appears
normal, and the superior mediastinal contour is
narrow. There is a bone-within-bone appearance of
the vertebral bodies and anterior flaring of the
ribs.
12
CXR 26th Day of Life
Lateral Film of the Chest on the 26th Day of
Life. The lungs are hyperinflated, with
bilateral streaky opacities in a parahilar,
peribronchial distribution. The heart appears
normal, and the superior mediastinal contour is
narrow. There is a bone-within-bone appearance of
the vertebral bodies and anterior flaring of the
ribs.
13
HPI 26th Day of Life

• Management ?
• Specimens were obtained for culture
• Administration of Gentamicin and Ampicilline

14
(No Transcript)
15
CXR 30th day of life

• Air space Disease in the right upper lobe, a
  finding consistent with the presence of
  atelectasis

16
HPI 30th Day of Life

• Blood cultures were positive for
  coagulase-negative streptococci
• Administration of antibiotics for additional 11
  days
• Condition improved

17
HPI 36th Day of Life

• Radiographic findings had improved

18
HPI 40th Day of Life

• Three days after the end of the antibiotic
  treatment tachypnea recurred
• But another radiograph still shows improvement
• What would you do?
• Administration of Cefuroxime, Clindamycin and
  Cisapride
• Babys conditon improves again

19
HPI 44th Day of Life

• CXR again shows abnormalities
• Infant ist transferred to hospital this day

20
PE

• Axillary Temp. 36,2C
• Pulse 99
• Respirations 70 / min while breathing oxygen by
  nasal cannula
• BP 105/90

21
PE

• Length 41cm (below 2 SD of new born)
• Weight 2100g (below 2 SD of new born)
• Head circumference 34.5 cm (1 SD below the mean)
• Lungs occasional wheezes and scattered fine
  crackles are heard bilaterally
• Minimal subcostal retractions
• Liver edge palpable 5mm below right costal margin

22
Assessment

• 44-day-old premature girl with recurrent
  respiratory distress, severe lymphopenia and
  failure to gain weight

23
(No Transcript)
24
(No Transcript)
25
(No Transcript)
26
Cultures and serologic studies

• No evidence of
• Chlamydia
• RSV
• Adenovirus
• Influenza A Virus

27
Stool specimen

• No ova or parasites

28
Initial Treatment

• Erythromycine and multivitamin
• Albuterol by nebulizer
• Axillary temperature does not exceed 37.7 but is
  normal on most occasions

29
Stained blood smear

• Anisocytosis ()
• Poikilocytosis ()
• Polychromatophilia ()
• Hypochromia ()
• Many microcytes
• Few macrocytes
• Rare teardrop cells and schistocytes
• 2 nucleated red cells per 100 white cells

30
(No Transcript)
31
Effect of the therapy

• Infants condition improves and remains stable
  for several days
• Considerable mucus production and coughing
• Moderate respiratory distress (50-60/min)
• Axillary temp 36,4C
• Pulse 179 /min
• SpO2 89

32
ABG

• While breathing supplemental oxygen
• Oxygen 137 mmHg
• Carbon Dioxide 46 mmHg
• pH 7.39
• Bicarbonate 28 mmol/l

33
CXR After Initial Treatment

• Resolution of pulmonary abnormalities

34
Upper GI Series

• Normal findings

35
DD

• AIDS/ HIV Infection
• Intestinal Lymphangiectasia
• Severe Combined Immunodeficiency SCID

36
AIDS

• Could explain this form of prolonged and profound
  lymphopenia in adults
• But in this case
• There is no evidence for HIV-Infection of the
  mother
• No risk factors of the mother are known
• CD4 Lyomphopenia is manifested later in life
• No clinical features or lymphadenopathy
  characterisic of pediatric AIDS

37
Intestinal lymphangiectasia

• Leads to extensive lymphopenia and accumulation
  of lymphocytes in the gut
• BUT
• Infants are immunocompetent and do not aquire
  early opportunistic infections
• The absence of diarrhea makes this diagnosis
  unlikely

38
Forms of Severe Combined Immunodeficiency ( SCID )

• SCID with deficient T- cells and normal or high
  levels of B-cells
• X-linked form (common ?-chain-deficiency)
• Autosomal recessive form Janus kinase 3 (JAK3)
  deficiency
• SCID with deficient T-cells and B-cells
• Adenosine deaminase (ADA) deficiency
• Defect in Recombinase activating gene (RAG) 1 or
  2
• Reticular dysgenesis

39
(No Transcript)
40
Red Cell Studies

• Absence of adenosine deaminase activity and
  elevated levels of deoxyadenosine triphosphate
• Levels of purine nucleoside phosphorylase normal

41
Peripheral blood lymphocytes

• No proliferative response to phytohemagglutinin

42
SCID due to ADA-Deficiency

• Autosomal - recessive form 20 of all SCID
  patients
• Due to various mutations in the ADA gene
• Accumulation of adenosine, deoxyadenosine
  deoxyadenosine triphosphate and
  S-Adenosy-L-homocysteine are toxic to lymphocytes
  ? this causes the
  immunodeficiency
• ADA-SCID presents with a more severe lymphopenia
  than other forms of SCID (absol. counts lt
  500/mm³)

43
Clinical Presentation of SCID due to ADA

• Lymphopenia with marked depletion of T and B
  lymphocytes
• Normal or increased NK Cells
• No corticomedullary demarcation of the thymus
  (Absence of Hassalls bodies and thymocytes)
• Lymphnodes retain their normal architecture but
  contain only very few lymphocytes
• Rib cage abnormalities similar to rachitic
  rosary, predominantly at the costochondral
  junctions, the apophyses of the iliac bones and
  in the vertebral bodies

44
Clinical Presentation of SCID due to ADA (2)

• Circulating B-cells may present in some patients
• Severity depends on the type of mutation in the
  ADA gene and the resulting degree of the ADA
  definciency
• Growth and developmental abnormalities, including
  neurologic and osseous findings, have been
  observed

45
SCID Treatment of the Patient

• Our patient was treated with polyethylene-glycol
  modified adenosine intramuscularly, initially
  twice a week, guided by the levels of ADA and the
  toxic metabolites
• She began smiling and interacting with the
  environment already after two doses of ADA
• Suspected P. carinii infection was treated with
  Trimethoprim-Sulfamethoxazole i.v.

46
SCID Treatment

• HLA identical or haploidentical bone marrow
  transplantation without chemotherapy
• first perfomed in 1969
• graft-versus-host disease is uncommon
• Survival 100 for HLA identical and 78 for
  haploidentical graft
• Gene therapy
• Substitution of the enzyme

47
Follow Up

• 500 mg immunoglobuline per kilogram every three
  or four weeks will give her enough protection
• No live vaccinating agents
• She is expected to grow and develop normally
• The cartilaginous abnormalities should disappear
• She can have a normal diet

48
Thank you for your attention
