Title: Earthquake Notes


1
Earthquake Notes
2
What is an earthquake?
  • Earthquake the shaking of the earths crust
    (remember waves transmit energy!).
  • FrequencyOne happens somewhere on earth every
    30 seconds!

3
What Causes Earthquakes?
  • Caused when stress (the force per unit area) is
    greater than the strength of the rocks. Strain
    is when rocks deform due to stress.
  • Causes of stress
  • Shifting of tectonic plates
  • Volcanic eruption
  • Collapsing cavern
  • Meteor impact
  • Final Exams

4
(No Transcript)
5
Epicenter and Focus
  • Epicenter is the point on the surface of the
    earth directly above the focus of an earthquake.
  • Focus is the place where a fault plane first
    ruptures during an earthquake

6
Earthquake Calculations
  • Seismograph is the machine used to measure the
    ground shaking during an earthquake
  • Seismogram is the actual paper recording that
    shows the degree of ground shaking.

http//www.wwnorton.com/nrl/geology/earth/animatio
n_list.htm
7
Remember Types of Waves?
  • Primary Waves (P-Waves)
  • cause particles in rocks to move back and forth
    in the same direction that the wave is traveling
  • http//www.uh.edu/jbutler/physical/pwave.mov

8
More Earthquake Waves!
  • 2. Secondary Waves (S-Waves)
  • Move through Earth by causing particles in rocks
    to move at right angles to the direction of wave
    travel
  • http//www.uh.edu/jbutler/physical/swave.mov

9
Yes, More Earthquake Waves!
  • 3. Surface Waves
  • Cause the most destruction
  • Move rock particles in a backward rolling
    motion and a side-to-side, swaying motion
  • http//www.uh.edu/jbutler/physical/rayleighWave.
    mov

10
How Waves Indicate Composition
11
Earth Does the Wave
Wave Fronts
Waves
12
Savage Earth Unleashed!
  • http//www.pbs.org/wnet/savageearth/animations/ear
    thquakes/main.html
  • http//www.discoverourearth.org/student/earthquake
    s/index.html

13
S-P Wave Lag Time
  • S-P Lag Time is the time between the arrivals of
    P and S waves on a seismogram.
  • Seismographs farther from the epicenter have
    longer S-P lag times.

14
Travel Time Curve
  • If you know the S-P lag time, you can use a
    time-travel curve to figure out the stations
    distance from the epicenter.

15
Time Travel Curve
16
Triangulation
  • If you know
  • The distance of three stations from the epicenter
  • Then you can
  • Determine the location of the epicenter using
    triangulation

17
(No Transcript)
18
Type To Find an Epicenter!
  • Work in groups of TWO.

19
DES Today! Wednesday October 25th
  • 10 minutes to finish lab if needed.
  • Damage Scales and Faults (Targets 8 9)
  • Pre-Lab the Friction Lab
  • Tonights Homework
  • Look up/define 4 more vocabulary words.
  • Assess your understanding of targets 2- 6, 8-9

20
Amplitude
  • Amplitude is the height of a wave
  • Amplitude indicates the amount of energy the
    wave transmits

21
Richter Magnitude
  • If you know
  • the stations distance from the epicenter
  • AND
  • The amplitude of the wave
  • Then you can
  • determine magnitude using a Nomogram tool.

22
What is a nomogram?
23
Earthquake Severity
  • Richter Earthquake Magnitudes Effects
  • Less than 3.5 Generally not felt, but recorded.
  • 3.5-5.4 Often felt, but rarely causes damage.
  • Under 6.0 At most slight damage to well-designed
    buildings. Can cause major damage to poorly
    constructed buildings over small regions.
  • 6.1-6.9 Can be destructive in areas up to about
    100 kilometers across where people live.
  • 7.0-7.9 Major earthquake. Can cause serious
    damage over larger areas.
  • 8 or greater Great earthquake. Can cause serious
    damage in areas several hundred kilometers
    across.

24
Richter Scale, cont.
  • Richter Scale starts at 1 (very small earthquake)
    and has no maximum value
  • Largest earthquake recorded9.5 Chile, 1960

Effects of a 7.8 earthquake in 1906.
Although each earthquake has a unique Magnitude,
its effects will vary greatly according to
distance, ground conditions, construction
standards, and other factors. Seismologists use a
different Mercalli Intensity Scale to express the
variable effects of an earthquake.
25
Earthquakes in Illinois
Info http//www.isgs.uiuc.edu/earthquakes/appgeop
hys_eq_home.htm Archive of Seismograms http//w
ww.isgs.uiuc.edu/earthquakes/appgeophys_eq_dp_arch
ive2004.htm
26
Every Place Has Its Faults!
  • A fault is a fracture in the Earth's crust along
    which two blocks of the crust have slipped with
    respect to each other.
  • Faults are divided into three main groups,
    depending on how they move
  • Normal faults
  • Thrust (reverse) faults
  • Strike-slip (lateral) faults
  • http//www.iris.edu/gifs/animations/faults.htm

27
Key Terms Know em, Love em
Hanging Wall- Always above the fault
plane Hangs on the footwall Foot Wall- Always
below the fault plane Shaped like a foot
28
Stress, Stress, and More Stress!
29
Normal Faults
  • Occur in response to pulling or tension the
    overlying block moves down the dip of the fault
    plane.
  • Most faulting along divergent boundaries
    (spreading zones) is normal.

30
Hanging wall moves DOWN the footwall
Forces pulling apart rock (tension) create normal
faults
31
Normal Faults
32
Reverse Faults
  • Occur in response to squeezing or compression
    the overlying block moves up the dip of the
    fault plane.
  • Most faulting along subduction zones (convergent
    boundary) is thrust faults.

33
Forces pushing rock together (compression) create
reverse faults
Hanging wall moves UP the footwall
34
Reverse Fault
35
Reverse Fault
36
Strike-slip (lateral) faults
  • Occur in response to either type of stress the
    blocks move horizontally past one another.
  • Most faulting along transform faultsis
    strike-slip.

37
Sideways motion (shearing) creates strike-slip
faults
Example San Andreas Fault
38
  • Strike-slip (shear)
  • -fractures caused by horizontal shear

39
Strike-Slip Fault
40
Strike-Slip Fault
41
Strike Slip Fault
42
DES Today! Thursday October 26th
  • Change of Plans!
  • Target 12
  • Tonights Homework
  • Look up/define 4 more vocabulary words.
  • Finish write-up of friction lab

43
Latitude vs. Longitude
  • Latitude-
  • distance in degrees north or south of the Equator
    (0)
  • Horizontal lines on a map

44
Latitude vs. Longitude
  • Longitude-
  • distance in degrees east or west of the Prime
    Meridian (0)
  • Vertical lines on a map

45
Measuring Latitude and Longitude
  • Each Degree is broken down into minutes
  • (60 minutes in one degree)
  • A minute is shown with a sign. (example 8806)

46
To Open from School
  • Open PowerPoint
  • Click on Open
  • In the Look In field, Select Global on
    Nccluster
  • Open the folder labeled Pollard-DES
  • Open the PowerPoint labeled Virtual Earthquake
    Measurement
  • View the PowerPoint and then click on the address
    on the first slide.

47
(No Transcript)
48
Virtual Earthquake Measurements
  • http//vcourseware4.calstatela.edu/eec/
  • Earthquake/
  • Press Epicenter and Magnitude button
  • Next, press Start Activity
  • Wait for Pop-up, and Select Run on the following
    screen
  • Class code 692784

49
DES Today! Friday October 27th
  • Target 12 Explain the roll of friction in
    earthquakes.
  • Class Meeting
  • Friction Lab (Write-Up Due Tuesday)
  • Tonights Homework
  • Look up/define 4 more vocabulary words.
  • Assess your understanding of Target 12
