Membrane channels

1
Gating-by-Tilt Mechano-sensitivity of
Biomembrane transport
Pierre Sens Institut Curie - Paris. France
Institut Charles Sadron - Strasbourg. France
Matthew Turner Warwick University. England
APS - March 2004 - Montreal
2
Membrane Transport Proteins
20 of identified genes in E-Coli are associated
with membrane transport processes
Very important for the cell
Types of transport
Outline of the Talk New gating mechanism for
mechano-sensitive channels Membrane tension
influences (may inhibit ?) transport
3
Mechano-sensitive channels
Function osmotic regulation
Structure Two states
Open
Closed
Traditional picture
New picture
Influence of Membrane Tension
4
Active Transport
Very asymmetric ionic concentrations
Function creates/maintains concentration
gradients Requires Energy consumption (ATP
hydrolysis - use of ionic gradient)
Examples that involve a structural change
For some transporters, it involves A change of
protein tilt
Membrane tension influences transport rate
Protein Tilt -gt Membrane Energy -gt Protein
Conformation Energy
5
Origin of Membrane Energy
Membrane displacement (small)
Energy (Helfrich - 70s)
Bending rigidity vs. Membrane tension
6
Mechano-sensitive channels
Example MsCl
Chang Science, 1998 (side)
K. Schulten (top)
K Channel (M. Sansom)
7
2-state model ( possible intermediate,
metastable states)
Bottom view
closed
open
Channel
ENERGY
(2)
(1)
Energy barriers
Energy difference
states
Membrane
Energy difference decreases with tension
Total Energy
8
High (membrane) Gating energy High Channel
Sensitivity
Membrane contribution to the energy
Traditional picture
New picture
Gating-by-tilt
Requires large dilation for high sensitivity
Adds to (dominates) the sensitivity
Channel size
9
New Feature of Gating-by-Tilt !
Effect of Membrane asymmetry
Reduction of tension (bad for gating-by-dilation)
Increase of spontaneous curvature (good for
gating-by-tilt)
Channel opening by asymmetrical lipid addition
Observed in vitro (by EPR spectroscopy) Perozo
Nature Struct. Biol. 9, 696 (2002)
10
MEMBRANE TRANSPORT
Locher, Bass, Rees, Science 301, 603 (2003)
Active transport (uses ion gradient)
11
Active transition
2-State model
(0)
(2)
Passive (thermal) transition
(1)
-p/4 -p/6 -p/12 0 p/12
p/6 p/4
Involves a change of protein tilt
Membrane energy
May destabilize the metastable state and inhibit
membrane transport
12
Summary
Physical consequences of tilted protein
conformation
Membrane tilt may have a dominant contribution to
the gating energy of mechano-sensitive channels
Gating-by-Tilt explains the channel sensitivity
to membrane asymmetry
Membrane elasticity plays an important role in
Active transport
Active transport may - too - be
mechano-sensitive And may be inhibited under high
membrane tension
M.S. Turner P. Sens. Gating-by-tilt of
mechanosensitive membrane channels.
cond-mat/0311574
13
pierre.sens_at_curie.fr http//perso.curie.fr/Pierre.
Sens/
14
(No Transcript)
15
hydrophilic
hydrophobic
Cell membrane are composed of amphiphilic
molecules which self-assemble into fluid bilayers
16
Mechano-sensitive channels
Example MsCl
Sukharev Nature 409, 771 (2001)
17
Patch clamp measurements

• Open area from conductivity
• Energy DG estimated from
• open area x tension

Frans Maathuis, York
18
Corresponding tilt angles
q
Channel q100 (degrees) 100 of gating DGdilate q10 (degrees) 10 of gating DGdilate
MscL 39 12
MscS 24 8
MscA1 21 7
MscA2 31 10
MscMJ 16 5
MscMJR 35 11
