ClearSight Analyzer Version 6'0

1
ClearSight AnalyzerVersion 6.0
ClearSight Networks, Inc.
2
Whats new in 6.0?

• Application Support
• VoIP Enhancements, including IPTV
• Decode Enhancements
• Tools Menu
• Protocol Forcing
• Multicast Enhancements
• Filter Enhancements
• Report Enhancements

3
Application Support

• Microsoft Network Messenger
• HTTP Child Flow Configuration
• Skype Support

4
Microsoft Network Messenger

• Flow Diagram
• Message Window
• Statistics Window
• Reports
• Alarms
• Filter on MSN

5
MSN Flow Diagram
6
MSN - Message Window
7
MSN - Statistics Window

• Server addresses
• Caller names

8
MSN - Alarms

• Check Enable decode problem generation option
  in Configuration-gtPreferences-gtDecode-gtGeneral
  page.
• Goto Configuration-gtPreferences-gtProblem-gtThreshol
  ds, select MSN, then check all and set all
  threshold to 1
• Open trace file 4.21 MsnLoginErrorWith911.adc
• Goto Tracefiles\Problem, user can find 3
  problems.

9
HTTP Child Flow Configuration

• What is Child Flow?
• Individual request within an HTTP flow

10
HTTP Child Flow Configuration

• Enable HTTP Child Flow monitoring in the
  Configuration

11
Skype

• Enable Protocol Monitoring in Configuration gt
  Protocol Settings
• Click the Skype box

12
Skype - Flow Diagram
13
Skype - Statistics
14
VoIP Enhancements

• New features for VoIP in CSA 6.0
• -iLBC codec
• -Call Log History
• -T-38 Fax over IP
• -IPTV

15
Support for Additional VoiP CODEC

• iLBC Internet Low Bitrate Codec, new codec for
  high-loss VoIP environments

16
Support for Additional VoiP CODEC
17
VoIP Call Log History Report

• VoIP Call Log Report
• Provides overview of all calls monitored by the
  analyzer
• Provides information to quickly pinpoint problem
  connections and locations
• Means validate improvements as the result of QoS
  implementations

18
VoIP Call Log History Report

• Enable in Configuration gt History gt Database
  Settings
• Select Enable VoIP Call Log and Triple-Play Module

19
VoIP Call Log Browser
20
Call Log Browser

• Call Log Browser
• Provides ability to focus analysis efforts on
  calls satisfying certain criteria
• Selection Criteria includes
• Date Range
• Call Duration
• MOS Score

21
T.38 Fax Support

• Ability to re-assemble fax from transmitted
  packets

22
T.38 Fax Support
23
T.38 Fax Support
24
IPTV

• Video QoS Statistics
• VQ Factor
• New Playback GUI / Video Export
• H.264 MPEG-4 Digital Video codec support
• MEGACO Binary Encoding Support

25
New Video Qos Statistics
26
VQ Factor

• Video Quality Factor
• Measures overall quality of video stream
• Scale 1 to 5

27
Improved Audio and Video Playback GUI
28
Video Export

• Right-Click video to export .mpg file.

29
MDI counters in RTP statistics

• Media Delivery Index - indication of traffic
  jitter and measure of deviation from nominal flow
  rates

30
MDI Problem Thresholds

• Configuration gt Problem gt Thresholds gt MDI Values

31
Alarm Based Trigger

• Start capture when video quality drops or
  degrades
• Capture gt Trigger gt RTP MDI Values

32
Decode Enhancements

• Multiple Decode Windows
• Real Time Decode Clear Button

33
Multiple Decode Windows

• Configuration gt Decode gt General
• Under Decode Engines section select ClearSight.
• Under Number Of Files Open Concurrently select
  3
• Open any 2 Trace Files from the traces directory

34
Real Time Decode Clear Button

• Monitor gt Real-Time Decode tab gt Run
• Real-Time Decode will be displayed
• Click on Clear button
• Current contents of the Real-Time Decode display
  will clear

35
Tools - Look and Feel

• Switch GUI between several templates

36
Protocol Forcing

• Global Configuration
• Decode Configuration

37
Global Configuration
38
Decode Configuration
39
Multicast Enhancements

• Multicast GUI Reorganization
• IGMP Support
• Multicast Trending
• Channel Changing Support
• Channel Zapping

40
Multicast GUI Reorganization
41
IGMP Support

• IGMP
• IPv4
• Host Membership Query Sent by router to find
  hosts belonging to group
• Join Sent by host to join multicast group
• Leave Sent by host to leave multicast group

42
Trending
43
Channel Zapping

• Channel Zapping
• Occurs when view changes channels from one
  multicast stream to another
• Client sends IGMP Leave for previous stream
• Client sends IGMP Join for new stream

44
Channel Zapping

• Channel Zapping Issues
• Channel Change Latency
• Time between when the IGMP Join is sent and when
  the multicast stream is received
• Very short if stream is already near router
• Long if reverse path must be built to the
  multicast source

45
Channel Zapping
Receive Rate(pps)
Leave Ch.2(S1,G1)
Join Ch.3(,G2)
Leave Ch.3(,G2)
Join Ch.4(,G4)
Join Latency
Leave Latency
Channel3 (,G3) Stream
Channel4 (,G4) Stream
Channel2 (S1,G2) Stream
Time (t)
Channel Overlap
Channel Gap
Channel Change latency
46
Real Time Filter Indicator

• Configure gt Monitor Settings gt Filter gt Define
  Filter (for example, all HTTP Get Commands

47
Real Time Filter Indicator

• Only desired traffic will be displayed on the
  Monitor page

48
Pattern Filter Hex Support
49
Report Enhancements
50
Total Calls for all VoIP Applications
51
Triple-play distribution
52
Triple-play distribution trend
53
Triple-play traffic trend
54
Improved History Reports
55
Thank YouClearSight AnalyzerVersion 6.0
ClearSight Networks, Inc.
