Ronald Westra

1

• Ronald Westra
• Dep. Mathematics
• Faculty of Humanity and Sciences
• Universiteit Maastricht

2

• Lecture 6
• Self-Organisation
• and
• Collective Phenomenae

3
Percolation revisited
4
Percolation (Definition from Wikipedia)In
chemistry and materials science, percolation
concerns the movement and filtering of fluids
through porous materials.
During the last three decades, percolation
theory, an extensive mathematical model of
percolation, has brought new understanding and
techniques to a broad range of topics in physics
and materials science.
5
Percolation

• Given the probability p of an occupied site
• What is the size M(p) of the largest connected
  cluster?
• Clearly, M(p) grows with p

6
Relation with fractal shapes

• p the probability of a site being occupied
• (1-p) the probability of a site being unoccupied
• At a certain threshold value pc, the size of the
  largest connected cluster becomes very large.
• pc is called the percolation threshold
• The largest connected cluster has a fractal shape

7
Duration of a fire

• How long does a fire last (depending on p and L)?
• Graph shows duration as a function of p
• L 20, 100, 500 (from bottom to top graph)
• pc ? 0.5928

8
Phase transitions

• The sudden transition from no percolation to
  percolation at the percolation threshold is a
  phase transition
• Compare the boiling of water at the critical
  temperature Tc 1000 Celsius.
• For L ?? (infinitely large forest) the cluster
  size becomes infinite too

9

• Probability that a randomly-selected tree is
  reached by fire as a function of p
• The larger L, the more pronounced the transition
  from 0 to 1

10
L ? ?

• What does it mean and why is it important?
• It means that percolation extends over an
  infinite distance
• At the transition point, systems exhibit
  universal (predictable) behaviour
• At the transition point, the system becomes scale
  invariant (? fractal)

11
Intuitive understanding

• What is the relation between fractal shape and
  critical behaviour?
• Self-similarity across scales
• E.g., zooming in on the coast of England
• Google-earth
• Basis for the renormalization approach

12
Renormalization

• At the phase (or percolation) transition, the
  system is scale invariant
• Scale invariance implies that the system exhibits
  identical behaviour at all spatial scales
• Zooming out renormalization

13
Zooming out

• A new lattice is formed by grouping three sites
  of the original lattice into one site
• Occupation of the new site is determined by the
  majority rule
• If most are occupied, new site is occupied too.
  The new site is unoccupied otherwise.

14
zooming out
15
Mathematical derivation(for the triangular
lattice)

• p is the percolation value of the original
  lattice
• p is the percolation value of the new (zoomed
  out) lattice
• The probability for an occupied site on the
  original is p
• The probability for an unoccupied site on the
  original lattice (1-p)
• The probability for an occupied site on the new
  lattice is
• The probability that all three original sites are
  occupied p?p?p p3
• The probability that one of the three original
  sites is unoccupied (1-p)p2which can occur in
  three ways
• Hence, p p3 3(1-p)p2

please take a nap if you dont like this, or if
you dont (want) to understand this
16
Mathematical derivation

• p p3 3(1-p)p2
• We are interested in the case p p
• i.e., no change in occupation probability when
  zooming out
• p p3 3(1-p)p2 ? p3 3(1-p)p2-p 0
• p3 3p2 (1-p) -p -2p(p-0.5)(p-1)
• Which gives zero for p 0, p 1, and p 0.5
• These three values of p correspond to the fixed
  points of the recursive relation p p3
  3(1-p)p2

17
Graphical illustration
18
Mathematical derivation(for the square lattice)

• p is the percolation value of the original
  lattice
• p is the percolation value of the new (zoomed
  out) lattice
• The probability for an occupied site on the
  original is p
• The probability for an unoccupied site on the
  original lattice (1-p)
• The probability for an occupied site on the new
  lattice is
• The probability that all four original sites are
  occupied p?p ?p?p p4
• The probability that one of the four original
  sites is unoccupied (1-p)p3which can occur in
  four ways
• Hence, p p4 4(1-p)p3

please take a nap if you dont like this, or if
you dont (want) to understand this
19
Phase transition

• At a critical value of T, Tc, the behaviour of
  the systems changes (it becomes critical)
• The critical behaviour is characteristic for the
  system (and other systems)

20
Phase transitions micro vs macro

• Phase transitions in different systems often
  possess the same characteristics. This is known
  as universality.
• Universality is a prediction of renormalization
  theory
• Renormalization theory states that the properties
  of a phase transition depend only on a small
  number of features, such as dimensionality and
  symmetry, and is insensitive to the underlying
  microscopic properties of the system.

21
Universality

• Universality is the observation that there are
  macroscopic properties for a large class of
  systems that are independent of the microscopic
  dynamical details of the system.
• Systems that display universality tend to be
  chaotic and often have a large number of
  interacting parts

22
Applications

• Percolation
• Spread of diseases
• Spread of rumours

23
Conclusions

• Phase transitions are universal
• They occur in many systems
• Economics
• Foraging in ants
• Movements of people
• Growth patterns
• Birth of solar systems

24
End of revisit of Percolation
25
Self-Organization
26
Overview

• Definition of self-organization
• Natural patterns
• Flocking
• Boids
• Period doubling in clapping
• Mexican Waves

27
Self-organization

• Self-organization is a process where the
  organization of a system spontaneously increases,
  i.e., without this increase being controlled by
  the environment or an encompassing or otherwise
  external system.

Principia Cybernetica Webhttp//pespmc1.vub.ac.be
/SELFORG.html
28
Natural patterns
29
Metal leaves produced during the
electrochemical deposition of ZnSO4
30
Colonial cooperative self-organization
Paenibacillus vortex
31
Colonial cooperative self-organization
Paenibacillus dendritiformis
32
Spontaneous clustering

• Brownian bugs are random walkers
• Two simple principles
• Birth always occurs near to a bug
• Death may occur anywhere

33
time
34
Self-organization in the brain

• Orientation sensitivity

35
Self-organization in the brain

• Direction tuning

36
Ant Self-Organization
37
Flocking
38
Steering behaviour for Autonomous Characters
www.red3d.com/cwr/steer
39
Lion King sequence

• Simulation stampede simulated using boid
  techniques

40
Self-organization of clapping
Global noise intensity
Local noise intensity
Correlation parameter
Average noise intensity
Clapping period
41
Period doubling

• Transition from asynchronous to rhythmic
  clapping skip every second beat
• Yields a clapping mode with a double period

42
Mexican Wave
43
Mexican-Wave model
44
Mexican-Wave demo
http//angel.elte.hu/wave
45
Lane formation and other demos
http//www.helbing.org/
46
Conclusions on self-organisation

• Self-organizing processes underlie patterns in
  nature, society, and culture
• What is the relation between individual behavior
  and collective behavior?
• Not always obvious, e.g., termite behaviour
• Nature evolves group behaviors that improve
  fitness
• Society evolves group behaviors that improve
  social acceptance

47

• The End
