Sensory Neurons and Muscles

1
Chapter 49

• Sensory Neurons and Muscles

2
Types of Sensory Neurons

• Mechanoreceptors- detect physical deformations
  pressure, touch, stretch, motion, and sound.
• Stretch receptors-flexion or extension or muscles
• Hair Cells-movement of fluids
• Pain Receptors-pressure
• Chemoreceptors-detect chemical changes in the
  body
• Thermoreceptors-detect temperature changes

3
Types of Sensory Neurons Stretch Receptors and
Hair Cells
4
Sensory Neurons of the Skin
5
Means of animal movement

• Cilia
• Flagellae
• Muscles

6
Vertebrate Muscle Types

• Skeletal muscle
• Striated
• Voluntary
• Smooth muscle
• Non-striated
• Involuntary
• Cardiac muscle
• Striated
• Involuntary
• Electrically coupled cells

7
Skeletal Muscle

• Many animals contain over 400 skeletal muscles
• 40-50 of total body weight
• Functions of skeletal muscle
• Locomotion and breathing
• Postural support
• Heat production

8
Structure of Skeletal MuscleConnective Tissue
Covering

• Epimysium
• Surrounds entire muscle
• Perimysium
• Surrounds bundles of muscle fibers (Fascicles)
• Endomysium
• Surrounds individual muscle fibers

9
Structure of Skeletal Muscle Microstructure

• Sarcolemma
• Muscle cell membrane
• Myofibrils
• Threadlike strands within muscle fibers
• Actin (thin filament)
• Troponin
• Tropomyosin
• Myosin (thick filament)

10
Structure of Skeletal MuscleMicrostructure

• A band
• Anisotropic (dark)
• I band
• Isotropic (light)
• Z disc
• Zwischenscheibe (between zone)
• a-actinin
• H zone
• Hellerscheibe (clear disc)

11
(No Transcript)
12
Structure of Skeletal Muscle The Sarcomere
13
Muscular Contraction

• The sliding filament model
• Movement of actin filament over the myosin
  filament
• Formation of cross-bridges between actin and
  myosin filaments
• Reduction in the distance between Z-lines of the
  sarcomere

14
The sliding-filament model of muscle contraction
0.5 ?m
(a) Relaxed muscle fiber. In a relaxed muscle
fiber, the I bandsand H zone are relatively wide.
Z
H
I
A
Sarcomere
(b) Contracting muscle fiber. During contraction,
the thick andthin filaments slide past each
other, reducing the width of theI bands and H
zone and shortening the sarcomere.
(c) Fully contracted muscle fiber. In a fully
contracted musclefiber, the sarcomere is shorter
still. The thin filaments overlap,eliminating
the H zone. The I bands disappear as the ends
ofthe thick filaments contact the Z lines.
15
Cross bridges
16
(No Transcript)
17
Myosin-actin interactions underlying muscle fiber
contraction
18
(No Transcript)
19
(No Transcript)
20
Hypothetical mechanism for the regulation of
muscle contraction
21
(No Transcript)
22
Sarcoplasmic Reticulum
23
The Neuromuscular Junction

• Site where motor neuron meets the muscle fiber
• Separated by gap called the neuromuscular cleft
• Motor end plate
• Pocket formed around motor neuron by sarcolemma
• Acetylcholine is released from the motor neuron
• Causes an end-plate potential (EPP)
• Depolarization of muscle fiber

24
(No Transcript)
25
Review of contraction in a skeletal muscle fiber
26
Motor units in a vertebrate muscle
27
Temporal summation of muscle cell contractions
28
(No Transcript)
29
Types of Skeletal Muscle Fibers
Type I Type IIa Type IIb
30
Fiber Types and athletic performance

• Type I- Slow
• Type II-Fast

31
Fiber Types and athletic performance

• Power athletes
• Sprinters
• Possess high percentage of fast fibers (Type IIA
  and IIB)
• Endurance athletes
• Distance runners
• Have high percentage of slow fibers (Type I)
• Others
• Weight lifters and nonathletes
• Have about 50 slow and 50 fast fibers

32
Bones and joints of the human skeleton
33
Energy-efficient locomotion on land
34
The interaction of muscles and skeletons in
movement
35
Vertebrate Muscle Types

• Skeletal muscle
• Striated
• Voluntary
• Smooth muscle
• Non-striated
• Involuntary
• Cardiac muscle
• Striated
• Involuntary
• Electrically coupled cells

36
Vertebrate Muscle Types

• Skeletal muscle
• Striated
• Voluntary
• Smooth muscle
• Non-striated
• Involuntary
• Cardiac muscle
• Striated
• Involuntary
• Electrically coupled cells

37
The mammalian cardiovascular system an overview
38
The mammalian heart a closer look
39
The cardiac cycle
40
The control of heart rhythm
41

• Cells are coupled via gap junctions
• Allows electrical event to spread from cell to
  cell

42
(No Transcript)
43
(No Transcript)
