Deconvolution, Regularization

1
Deconvolution, Regularization Maximum Entropy
Methods

• Mario Juricmjuric_at_astro.princeton.edu

April 27th 2005, AST Observational Seminar,
Princeton University
2
A two-figure summary
Cygnus A radio source (6cm, VLA)
3
Atmosphere
Detector
Telescope
4
Sources of signal pollution

• Telescope and detector PSF
• Noise
• Incomplete coverage
• Interferometry
• Gamma ray astronomy

5
Mathematical model (linear)
Signal (Input)
Output
6
Recovering the signal
?
7
Deconvolution

• Inversion?
• Ill posed problem
• Infinite number of solutions satisfy the noise
  requirement
• Naïve deconvolution amplifies noise (with
  potentially catastrophic consequences)

8
Regularization

• Problem is well-posed when it is (Hadamard,
  1902)
• uniquely solvable and is such that the solution
  depends in a continuous way on the data.
• If the solution depends in a discontinuous way on
  the data, then small errors, whether rounding off
  errors, measurement errors, or perturbations
  caused by noise, can create large deviations.
• Most measurement problems are inherently
  ill-posed
• Regularization is the process of introduction of
  additional information about the problem in order
  to obtain a well-behaved inverse

http//www.math.uu.se/kiselman/ipp.html
9
Weiner filter

• Assumption we know Ps(k) and Pn(k)
• Acknowledge that some of the signal (in k-space)
  has been washed out by noise and suppress those
  frequencies

http//osl.iu.edu/tveldhui/papers/MAScThesis/node
15.html
10
CLEAN algorithm

• Assumption an image is generated by a set of
  point sources
• Introduced by Högbom (1974) for use in
  radioastronomy
• Iterative procedure where at each step strongest
  peak in the image is identified and subtracted
  until no more strong peaks are left

http//www.cv.nrao.edu/abridle/deconvol/node7.htm
l
11
Regularization procedures

• Common feature Incorporate prior knowledge (or
  assumptions) about the statistical properties of
  the image
• Intensity always has to be positive
• Expected form of the signal
• Eg. generated by point sources (CLEAN algorithm)
• Signal smoothness
• Expected signal and noise power spectrum (Wiener
  filtering, Richardson-Lucy algorithm)
• All of these algorithms require certain dose of
  intuition about what we expect from the signal.
  Can we somehow formalize this process (and make
  it least subjective as possible)?

12
Restatement of the problem

• Testable information
• There is a space of all possible signals (images)
• We have a-priori constrains
• Eg. the positivity constraint
• w x h image size
• We have our measured data
• We have constraints on how wrong our data can be
  (chi-squared)
• The goal
• Out of all possible signals consistent with the
  available information, select the one which
  incorporates all that is known (testable
  information), but is maximally noncommittal about
  what is not known.

Which one?
Gull (1988)
13
Toy interferometry example

• Out of all possible signals consistent with the
  available information, select the one which
  incorporates all that is known (testable, but is
  maximally noncommittal about what is not known.

• How do we avoid injecting unnecessary information
  into the system while doing the reconstruction?

14
Entropy

• Information theory (Shannon)
• Average Shannon information content of an outcome
  (also called uncertainty)
• H is proportional to our lack of knowledge
• Statistical mechanics (Boltzmann)
• A measure of the number of microscopic ways that
  a given macroscopic state can be realized. For W
  alternatives, each with probability p, entropy is
  defined by (1), and by (2) for a general case of
  alternatives with unequal probabilities.
• exp(S) is proportional to the probability of
  getting that outcome

i.e. MacKay (2003)
15
Entropy maximization subject to constraints

• For images, identify probability with normalized
  intensity (1). Our image now bootstrapped a
  probability density function (giving the
  probability pi of the next photon arriving to
  pixel i )
• Given that bootstrap estimate, search for a new
  PDF pi which maximizes the entropy S(I), subject
  to testable information constraints C(I).
• This new PDF is the MAXENT-reconstructed image.

(1)
Lagrange multiplier
16
f1
f2
f3
A
f1
f2
f3
B
Skilling Bryan (1984)
17
Example reconstructions with varying amounts of
noise
Data
Reconstruction
Steinbach (1997), http//cmm.info.nih.gov/maxent/
18
General properties of a MAXENT reconstructed image
Model
Dirty map

• Peaks resolved(superresolution)
• Ripples removed
• Reduced resolutionat lower peaks
• Spurious peaks nearthe absorptionfeature

MAXENT
CLEAN
Narayan Nityananda (1986)
19
Form of entropy function

• Specifying a different entropy function is
  equivalent to specifying a different measure of
  information
• The standard Shannon entropy choice is motivated
  by counting the number of ways in which the image
  could have arisen

20
Popular choices for S(I)

• Burg (1978)
• Frieden (1978)
• Gull Skilling (1991)

Starck et al (2002)
21
Things to note

• MAXENT is essentially a way of generating a PDF
  on a hypothesis space which, given a measure of
  entropy, is guaranteed to incorporate only
  testable information
• MAXENT cannot be derived from Bayes theorem
  (despite what you may find in the literature). It
  is fundamentally different, as Bayes theorem
  concerns itself with inferring a-posteriori
  probability once the likelihood and a-priori
  probability are known, while MAXENT is a guiding
  principle to construct the a-priori PDF.
• For our application (deconvolution), we identify
  the PDF with an image (where individual
  probabilities are proportional to pixel
  intensities)
• As probabilities are positive by definition,
  positivity of intensities is automatic
• MAXENT produces images with least features
  (information) that are consistent with the data
  and known constraints (testable information).
  Another way of stating this is that MAXENT
  produces the most uniform image consistent with
  the data.

Jaynes (1988), Jaynes (1995), Gull (1988)
22
MAXENT Success stories in astronomy
23
Dirty map
Cygnus A radio source (6cm, VLA)
MAXENT reconstruction
Pearson Readhead (1984)
24
MAXENT reconstructions of simulated triple
sources with a) 250 events (gamma ray photons
registered at the detector),b) 500 events andc)
1000 events
Skilling, Strong Bennett (1978)
25
Original image
The Jet of M87 Original photograph vs. the
MAXENT reconstruction. Note the smoothing of the
noise and the increase in the level of detail in
the area of the jet (superresolution).
MAXENT reconstruction
Bryan Skilling (1980)
26

• Pioneer 10
• images of Ganymede
• Original image
• Wiener filtering
• MAXENT reconstruction

Frieden Swindell (1976)
27
Summary

• Most deconvolution we meet problems are
  inherently ill-posed (have an infinite number of
  solutions) which makes direct inversion
  impossible
• By adding additional constraints we regularize
  the problem (select one solution)
• Maximum entropy methods when applied to image
  reconstruction select the solution which produces
  an image having least features (information) that
  is consistent with the data. Another way of
  stating this is that MAXENT produces the most
  uniform image consistent with the data.
• On a deeper information theoretical level, MAXENT
  methods are a consistent and systematic way to
  build priors on a hypothesis space given some
  testable information (constraints). It is a
  general way to build priors.

28
Deconvolution Trivia

• While most people can see with a resolution of
  1, the image on our retina is blurred through a
  PSF of width as large as 5 due to various
  effects (the largest being chromatic aberration).
• And while we still struggle with finding optimal
  deconvolution algorithms, the brain happily
  performs the procedure on a 8500x5400 (43Mpix)
  image, a few times per second, 17 hours a day,
  365 days a year.

MacKay (2003) Tidwell (1995), http//www.hitl.wash
ington.edu/publications/tidwell/ch3.html
29
Deconvolution of motion blurring
Maximum Entropy Data Consultants,
http//www.maxent.co.uk/
30
References

• Jaynes, E.T., Probability Theory The Logic of
  Science (1995, Cambridge University Press)
• Jaynes, E.T., The Relation of Bayesian and
  Maximum Entropy Methods (1988), in
  Maximum-Entropy and Bayesian Methods in Science
  and Engeneering (Vol. 1), 25-20
• Gull, S.F., Bayesian Inductive Inference and
  Maximum Entropy, in Maximum-Entropy and
  Bayesian Methods in Science and Engeneering (Vol.
  1), 53-74
• Narayan, R. and Nityananda, R. Maximum Entropy
  Image Restoration in Astronomy, ARAA (1986),
  24, 127
• Skilling, J. and Bryan, R. K., Maximum Entropy
  Image Reconstruction General Algorithm, MNRAS
  (1984), 211, 111
• Skilling, J., Strong, A.W., Bennet, K.
  Maximum-entropy Image Processing in Gamma-ray
  Astronomy, MNRAS (1979), 187, 145
• Bryan, R. K. and Skilling, J., Deconvolution by
  Maximum Entropy, as Illustrated by Application to
  the Jet of M87, MNRAS (1980), 191, 91
• MacKay, D.J.C., Information Theory, Inference
  and Learning Algorithms, Cambridge University
  Press (2003)
• Frieden, B.R. and Swindell, W., Restored
  Pictures of Ganymede, Moon of Jupiter, Science
  (1976), 191, 1237
• Gull, S.F. Daniell, G.J., "Image reconstruction
  from incomplete and noisy data". Nature (1978),
  272, 686-690.
• And lots of papers, books and information at
  http//bayes.wustl.edu/ and http//astrosun2.astro
  .cornell.edu/staff/loredo/bayes/

31

• Journal of Inverse and Ill-Posed Problems
• http//www.kluweronline.com/issn/0928-0219/

32
Example
I1
I2

• Set of two pixel images constrained by with total
  intensity I4

3 1 0 0 0 0 0 0 0 0 0 1 1 0 1 0 1
0 1 1 2 0 2 0 1 1 2 1 2 1 3 0 2 1 3 1 3 1
3 1 3 1
4 0 0 0 1 0 2 0 3 0 4 0
2 2 0 0 0 0 0 0 0 0 0 0 0 0 0 1
0 1 1 0 1 0 0 1 1 0 1 1 1 1 1 1 1 1 0 2
2 0 2 1 1 2 1 2 2 1 1 2 2 1 2 2 2 2 2 2 2
2 2 2 2 2
Gull Daniell (1978)
