Dont get Nervous

1
Dont get Nervous!

• An Intro to the Human Nervous System and Neuron
  Structure

2
Overview the Brain as a Control Center

• The human brain contains about 100 billion nerve
  cells, or neurons
• Each neuron may communicate with thousands of
  other neurons
• Functional magnetic
• resonance imaging (MRI) is a
• technology that can reconstruct
• a three-dimensional map of
• brain activity

3
Organization of Nervous Systems

• All animals except sponges have
• a nervous system
• What distinguishes nervous systems of different
  animal groups is how neurons are organized into
  circuits
• The simplest animals with nervous systems, the
  cnidarians, have neurons arranged in nerve nets

4
Invertebrate Nervous Systems
LE 48-2a
Radial nerve
Nerve ring
Nerve net
Hydra (cnidarian)
Sea star (echinoderm)
5
LE 48-2d
Brain
Spinal cord (dorsal nerve cord)
Brain
Sensory ganglion
Ganglia
Squid (mollusc)
Salamander (chordate)
6
Vertebrate Nervous Systems

• In vertebrates, the central nervous system
  consists of a brain and dorsal spinal cord
• All other parts of the nervous system which relay
  information between the central nervous system
  and other parts of the body peripheral nervous
  system
• The peripheral nervous system (PNS) connects to
  the central nervous system (CNS)

7
Central nervous system (CNS)
Peripheral nervous system (PNS)
Brain
Cranial nerves
Spinal cord
Ganglia outside CNS
Spinal nerves
8
Nervous systems process information in three
stages sensory input, integration, and motor
output
Sensory input
Sensor
Integration
Motor output
Effector
Central nervous system (CNS)
Peripheral nervous system (PNS)
9
Neuron Types

• Sensory neurons transmit information from sensors
  that detect external stimuli and internal
  conditions carry impulses from receptors to the
  CNS
• Sensory information is sent to the CNS, where
  interneurons integrate the information
• Motor output leaves the CNS via motor neurons,
  which communicate with effector cells to produce
  responses
• The three stages of information processing are
  illustrated in the knee-jerk reflex

10
Gray matter
Cell body of sensory neuron in dorsal
root ganglion
Quadriceps muscle
White matter
Hamstring muscle
Spinal cord (cross section)
Sensory neuron
Motor neuron
Interneuron
11
Reflex Arc

• The simplest nerve pathway
• A neural circuit that travels only through the
  spinal cord, not the brain
• Provides a framework for a reflex action
• Stimulus is detected by sensory neuron ?
• relayed to the inter- or motor neuron in the
  spinal cord ? a response is transmitted via the
  motor neuron ? the effector cell responds

12
Neuron Structure

• Most of a neurons organelles are in the cell
  body
• Most neurons have dendrites, highly branched
  extensions that receive signals from other
  neurons
• The axon is typically a much longer extension
  that transmits signals to other cells at synapses
• Many axons are covered with a fatty protein for
  insulation myelin sheath

13
Neuron Structure
Dendrites
Cell body
Nucleus
Synapse
Signal direction
Axon hillock
Axon
Presynaptic cell
Synaptic terminals
Myelin sheath
Postsynaptic cell
14
Now YOU get to Build a Neuron

• In your lab groups, build a neuron
• Use the materials at your lab bench however you
  want to make a sensory or a motor neuron (see p.
  413)
• Mount your representation onto a piece of paper
  and label the parts OR use pins to label
• - Dendrites - Myelin Sheath
• - Synapse - Axon hillock
• Axon - Cell body
• Pre-synaptic cell - Post-synaptic cell
• Schwann cell - Node of Ranvier
• Be creative and have fun!
