Cataclysmic Variables in IPHAS

1
Cataclysmic Variables in IPHAS

• Andrew Witham
• Christian Knigge
• IPHAS Consortium

2
1 IntroductionWhy Search For New CVs With
IPHAS?

• Test theories of binary evolution and population
  synthesis models.
• There is a predicted population of short period
  CVs that are missing.
• These are expected to be strong Ha emitters.
• To establish the photometric properties and Ha
  emission line properties of CVs and look for
  correlations in these properties in an unbiased
  sample.
• To establish whether IPHAS is capable of
  discovering CVs up to its magnitude limits.

3
2 A Feasibility StudyThe Known Population Of
CVs As Seen By IPHAS.

• IPHAS photometry was used to construct r Ha vs
  r i colour-colour plots.
• Objects with a significant Ha excess are
  established using fits of the main stellar locus.
• IPHAS observed 19 CVs in the galactic plane a
  further 52 have were observed outside the plane.
• The recovery rate of CVs as Ha emitters is 70
  (48/71).

4
Known CVs On The IPHAS Colour-Colour Plane

• Ha emitters are red.
• Non-emitters are blue.
• Quality flagged objects are green.
• Interpolation was used to calculate EWs.
• Dwarf Novae show the greatest EWs.

5
EW and Orbital Period

• The maximum EW decreases with increasing orbital
  period.

6
The Period Distribution Of The Known CVs

• The period distribution of CVs detected as H
  emitters is shown in red superimposed on the
  period distribution of all the CVs observed.
• IPHAS is capable of detecting Ha emission from
  CVs irrespective of the orbital period.

7
2 ID Spectroscopy Of Bright and Clear Ha
Emitters.

• CAFOS on the Calar Alto 2.2m 79 Objects
  (limited wavelength range)
• The Cassegrain Spectrograph on the CTIO 1.5m
  Telescope 10 Objects.
• The Cassegrain Spectrograph on the 1.72m DAO 30
  objects (limited wavelength range).
• FAST on the 1.5m Tillinghast Telescope 214
  objects.
• ALFOSC on the 2.5m NOT 70 objects
• Carelec On the OHP 1.93m 19 objects
• ISIS on the 4m WHT 31 analysed 20 unanalysed
  objects

8
Results And Data Products

• 399 Objects have been analysed so far.
• The majority that have been classified are early
  type emission line stars.
• 6 CV Candidates
• 10 Young Stellar Objects e.g. T Tauri stars
• 20 late type stars, including some actual Ha
  emitters (active stars)
• 10 - 20 additional oddities.
• A webpage with spectra of the objects that dont
  appear to be early type stars is already setup
• A webpage with Photometry, Equivalent Width
  Measures, Classification and Spectra is coming
  soon.

9
Sample Spectra
Early Type Late Type Active Late Type
Young Stellar Object CV ???
10
Sample Spectra
Early Type Late Type Active Late Type
Young Stellar Object CV ???
11
Sample Spectra
Early Type Late Type Active Late Type
Young Stellar Object CV ???
12
Sample Spectra
Early Type Late Type Active Late Type
Young Stellar Object CV ???
13
Sample Spectra
Early Type Late Type Active Late Type
Young Stellar Object CV ???
14
Sample Spectra
Early Type Late Type Active Late Type
Young Stellar Object CV ???
15
Conclusions I

• The bright and clear sample of H emitters from
  IPHAS is dominated by early type emission line
  objects.
• 1.5 of the objects are candidate CVs.
• Currently no technique is known for
  distinguishing the two populations with existing
  photometry.
• Further observations are warranted to confirm the
  CV nature of several objects.
• The faint and clear sample is beginning to be
  followed-up. We may see a different population
  of objects or pick up further early type emission
  line objects in a further spiral arm.

16
3 Newly Discovered CVs!

• Spectroscopic follow-up of Ha emitters in the
  IPHAS survey has lead to the discovery of new
  CVs.
• In total 9 new candidate CVs have been found.
• 3 CVs have been observed further and their CV
  nature has been confirmed.
• These are
• IPHAS J013031.90622132.4 r 16.7
• IPHAS J051814.34294113.2 r 16.5
• IPHAS J062746.41014811.3 r 16.4

17
Time Series Photometry of IPHAS J06270148

• The system is revealed to be eclipsing.
• From the times of eclipse minimum and the eclipse
  width over the three nights it appears the
  orbital period is just longer than 12 hours.

18
Radial Velocity Analysis

• IPHAS J01306221
• IPHAS J05182941
• Average Spectra from one night of observing on
  the Calar Alto 2m

19
Period Searches
IPHAS J0130 Orbital period of 3.12 hours.
IPHAS J0618 Orbital period of 5.71 hours.
20
Conclusions II

• IPHAS is capable of detecting CVs at all Orbital
  Periods by virtue of their Ha emission.
• 9 new candidate CVs have been discovered so far
  from IPHAS follow-up.
• 3 bright CVs have been observed further and
  found to be long-period systems.
• Only by pushing fainter will we discover
  short-period systems.
• Recent empirical results and theory are
  beginning to suggest that a large population of
  short-period systems do not exist or are
  hidden.

21
Hß EW and Absolute Magnitude

• Patterson (1984) shows empirically that fainter
  CVs produce greater Hß Equivalent Widths.
• This correlation should hold for Ha emission.

22
Ha EW and Absolute Magnitude

• For CVs with known distances, absolute magnitude
  were calculated.
• For the Non-Magnetic CVs the Results agree
  qualitatively with Pattersons .

23
Conclusions

• EWs of the Ha emission from CVs have been
  estimated using the IPHAS photometry.
• Short-period CVs are capable of the greatest EWs.
• Concurrently Non-magnetic faint CVs show large
  EWs.
• Therefore IPHAS has a good chance of detecting
  short period faint CVs.

24
Future Possibilities

• These techniques can be used to test for Ha
  emission in CVs of an uncertain nature.
• The Equivalent Widths should be checked against
  measured EWs from spectroscopic observations.
• Absolute magnitudes of discs can be calculated to
  enable a better comparison with Pattersons work.
• It would be useful to compare the EWs and colours
  of CVs with other classes of objects such as
  X-Ray Binaries and Be Stars.

25
