Biomedical Sensors

1
Biomedical Sensors
A key in knowing what is wrong with you.
2
What is Measured and How?

• Measurand - a biomedical property that can be
  measured.

• Transducible property - that property of a
  measurand that allows it to be measured.

• Biosensor - converts a measurand into a
  measurable signal, usually electrical.

3
Classification of Measurands

• Biopotentials, for example, ECG, EEG, etc. That
  is, those that arise from an electrical signal
  generated in the body.

• Nonbiopotentials, for example, temperature, blood
  pressure, rate of blood and air flow.

4
Classification of Sensors

• Diagnostic - temperature, blood pressure, ECG

• Therapeutic- defibrillators, pacemakers

• Assistive - cochlear implants, functional
  neuromuscular stimulation

5
Location of Sensor

• Noninvasive/noncontact - blood gases,
  electrolytes, etc.

• Noninvasive/contact - ECG electrodes,
  temperature, oximetry, etc.

Invasive/short-term - EMG electrodes, catheter,
etc.
Invasive/long-term - Pacemaker, FES electrodes,
etc.
6
Measuring a Physiological Potential
7
Measurable Physiological Potentials
Voltage (V)
0.1 1 10 100
1,000 10,000
Frequency (Hz)
8
Electrodes

• Metal conductor in an electrolyte solution

Transduces an ion to an electron current
Characterized by electrode potentials
9
Surface Electrodes
Foam
Self Adhesive
Tan Weave
Multi Use
10
Electrode Potential
Metal
- - - - - - - - - - -
- - - - - -











Ehc




-
-
-



-
-


-
-
-
-
-
-
-
-
-
-
-
-
-
-
-

Electrolyte Gel

-
-
-

-
-


-

-

-
-


-

-
-



-
Skin
Half-cell potential
11
Ag/AgCl Electrodes

• Very important clinically and in research.

Cl is the primary charge carrier and is present
in tissue.
Low noise electrodes.
12
PHYSICAL MEASUREMENTS

• Force, acceleration, displacement

Temperature systemic, thermography
Pressure blood, pulmonary
Volume blood, pulmonary
Flow blood, air
Blood oxygen content (oximetry)
13
Linear Variable Differential Transformer
Ferrite Core
14
Differential Capacitive Transducer
15
Electromagnetic Flowmeter
16
Electromagnetic Flowmeters
17
(a)
(b)
(a) Signals without noise are uncorrupted. (b)
Interference superimposed on signals causes
error. Frequency filters can be used to reduce
noise and interference.
18
(a)
Figure 1.15 (a) Original waveform. (b) An
interfering input may shift the baseline. (c) A
modifying input may change the gain.
19
(a)
(b)
Figure 1.16 Data points with (a) low precision
and (b) high precision.
20
(a)
(b)
Figure 1.17 Data points with (a) low accuracy and
(b) high accuracy.
