Earth Structure

1
Earth Structure

• Using seismic waves

2
Waves Propagate with a Wide Range of
Velocities
Disturbances that Move through Space as Time
Progresses

• Seismic Waves 100s m/s to 10s km/s
• Sound Waves 100s m/s
• Radio Waves 299,800,000 m/s
• Light Waves 299,800,000 m/s
• Water Waves 100s m/s

Propagation Velocity
3
Attributes of a Propagating Wave

• Arrive Time and Velocity
• Location (hazards, monitoring for nukes)
• Determine structure (oil, gas, water, formation
  of Earth)
• Amplitude
• Magnitude (hazards)
• Discrimination (EQ or nuke?)
• Frequency/Period (used in all above applications)
• Frequency 1/Period
• Wavelength

4
Using Propagating Waves
Using Our Description of Propagating Waves
V X / T Velocity is defined as distance divided
by time (ft/s) material property
determination X V ??T Distance traveled
calculated from material velocity and travel
time distance to lightning distance to
earthquake depth to layers in earth T X / V
Travel time determined by distance from
source to receiver and velocity time of
arrival of ground shaking time of arrival of
tsunami time of arrival of sonic bomb
5
Outline

• Refraction Seismology
• Reflection Seismology
• Seismic Waves in a Spherical Earth
• Body Wave Travel Time Studies
• Anisotropy
• Attenutation
• Deep earth

6
Earth Structure

• In general, travel times used to study structure
• Body waves
• Ray approximation travel time
• T travel time S source r receiver 1/v
  slowness
• Surface waves can be used (tomography), but
  usually based on group and phase velocity
  measurements

7
Ray Theory Basics

• Rays bent when they reach an impedance contrast
  refraction
• Rays turned back at interface reflection

8
Snells Law

• Snells Law controls what direction (angle) the
  rays are bent

9
Critical Angle
10
Critical Angle and Huygens Principle

• Incident angle where the bent ray becomes
  horizontal
• Called a head wave travels along interface
• Huygens Principle generating a head wave along
  the interface as a series of point sources

11
Huygens Principles

• Head wave point sources along boundary

12
Basic Ray Paths
13
Travel Time Curve

• Crossover distance
• Refracted wave overtakes direct wave
• Critical distance
• Refracted wave begins

14
Travel Times for Basic Paths

• Direct wave
• Reflected
• Refracted

15
How do we use this to determine Earth structure?

• What can we do?
• Refraction experiment
• Reflection experiment
• What else?
• Body wave and surface wave tomography

16
(No Transcript)
17
(No Transcript)
18
Reflection and Refraction

• Seismic refraction survey
• Each wiggle is a recording
• Evenly spaced recordings
• Notice change in slope of arrival time

19
Seismic Refraction Survey

• Components
• SOURCE
• PROPAGATION THROUGH EARTH
• RECEIVER

20
Seismic Refraction Survey 1. SOURCE
21
Seismic Refraction Survey 2. PROPAGATION
22
Seismic Refraction Survey 3. RECEIVER
23
Seismic Refraction Survey
24
Wave Propagation for Shallow Structure
Refraction Seismology
h
Soil V1
Rock V2
Direct wave travels directly through
soil Refracted wave travels through soil,
refracts and Travels in the rock and then
refracts back to surface
V2 gt V1
25
Resulting Travel Time Curve
?t2
?x2
td
V2 ?x2 / ?t2
?t1
Time (seconds)
V1 ?x1 / ?t1
h ( xc/2) (V2 - V1)/(V2 V1)1/2
?x1
?
Xc (Crossover Distance)
?
Distance (feet)
26
Rays and Travel Times
27
A Local Experiment

• What is the crossover distance?
• What is V1? V2?

28

• A large experiment

29
More complicated structure

• Travel times

• Ray paths

30
Blind Zone

• Layer too thin

31
Dipping Structure
32

• Travel time

33
Real data!
34
Low Velocity Zones

• Rays bent away
• Questions
• Would you generate a head wave?
• What would a raypath look like?
• What might a travel time plot look like?
• Can you image the LVZ with refraction?

35
Advanced Methods

• Modeling amplitudes and times

36
Crustal Structure

• Forward modeling to get structure
• Simple 1-D velocity model

37
Wavelength and Structure

• Velocity
• V w/k f l l/T
• Period
• T 2p/w 1/f l/v
• Wavelength
• l 2p/k v/f vT
• Wavenumber
• K 2p/l w/v 2pf/v
• Resolution
• Body waves?
• Surface waves?

38
Crustal Velocity Models Western U.S.
39
Crustal Thickness
40
Pn Velocity
41
Global Thickness
42
What is the Moho?
43
Rocks and Velocity
44
Travel Time Curve for Reflections

• Travel time
• Hyperbola
• Slope of hyperbola gives velocity
• Flatter higher
• Normal Moveout (NMO)
• Difference between travel times from some
  distance and zero offset

45
Ray Parameter

• Relationship between ray path and travel time
  curves
• Slope of travel time curves
• Ray parameter is constant along ray

46
Multiple layers

• Multiple layers result in multiple reflections
• Will get different travel time curves
• Hyperbolic approximation good for large offsets
• Get layer velocities from travel time curves

• Derive Dixs equation (interval velocity)

47
Travel Time Curves for Multiple Layers

• The deeper the layer, the flatter the curves
• Becomes difficult to resolve

48
Reflections and Dippling Structure

• Hyperbola will be offset

49
Slowness

• Useful to think in terms of v(z)
• p sin(i)/v(z) constant along ray
• For a ray, total travel time is given as T(p),
  where u(z)1/v(z) is called the slowness

50
Constant Ray Parameter
51
Vertical and Horizontal Slowness

• Lets derive on the board the intercept-slowness
  formulation for travel times

52
(No Transcript)
53
(No Transcript)
54
(No Transcript)
55
(No Transcript)
56
(No Transcript)
57
(No Transcript)
