Efficient SAT/BDD-based Techniques for Predicate
Abstraction
Shuvendu K. Lahiri
Microsoft Research, Redmond

Joint work with Thomas Ball, Randy Bryant, Byron
Cook, Robert Nieuwenhuis, Albert Oliveras
2
Program analysis and abstraction

• Unbounded state space
• Unbounded integers, arrays, heap
• State exploration may not terminate
• Abstraction
• Construct an overapproximation of program
  behavior
• Abstract domain/operators ensures that the
  analysis terminates

3
Automatic predicate abstraction

• Graf Saïdi, CAV 97
• Underlying framework
• Abstract Interpretation, Cousot Cousot 77
• Idea
• Given set of predicates P P1, , Pk
• Formulas describing properties of system state
• Finite Abstraction
• Abstraction (s) subset of P1, , Pk holds
  on s
• At most 2k abstract states

4
Predicate abstraction in practice

• Boolean Program from C programs
• SLAM
• Software Model Checking
• BLAST, MAGIC,
• Loop invariant synthesis for arrays and lists
• ESC-JAVA,..
• Distributed Protocol Verification
• UCLID, Murphi,

5
Definitions

• Predicates
• Literals in some theory T
• P x 1, x y, x lt y 2, f(x) f(y) 2,..
• Formula
• Boolean combination of predicates
• ?(x 1 ? x lt y 2)

6
Fundamental Operation Predicate Cover

• FP (?)
• Predicate cover of ?
• Weakest expression over P that implies ?

P Set of predicates ? Formula
7
Example
P x lt y, x 2

• Minterms over P
• x ? y ? x ? 2
• x lt y ? x ? 2
• x ? y ? x 2
• x lt y ? x 2

? y gt 1
8
Traditional approaches

• FP (?)
• Predicate cover of ?
• Weakest expression over P that implies ?

?
FP (?)

• Check which minterms imply ?
• Use a decision procedure to check the implication

Exponential number of Decision Procedure Calls
Partitioning defined by the predicates
P Set of predicates ? Formula
9
Traditional approaches

• Large number of decision procedure calls
• Worst case exponential in P
• Exponential behavior often seen in practice
• Each decision procedure call can be expensive
• Limits scalability
• FP (?) invoked a few thousand times during a
  single software verification run
• Tools have to sacrifice precision for efficiency

10
Overview of the talk

• Two approaches to predicate abstraction
• Symbolic Decision Procedures
• Satisfiability Modulo Theory (SMT) based
• Symbolic decision procedures (SDP)
• Lahiri, Ball, Cook CAV05
• SMT-based predicate abstraction
• Eager Lahiri, Bryant, Cook CAV03
• DPLL(T) based Lahiri, Oliveras, Nieuwenhuis
  CAV06
• Challenges ahead

11
Predicate Abstraction using Symbolic Decision
Procedures
12
Overview of SDP

• Symbolic Decision Procedures
• Predicate abstraction
• SDP for Equality Logic
• Combining SDP for two theories

13
Computing FP (?)

• FP distributes over conjunction
• FP (?1 ? ?2) FP (?1) ? FP (?2)
• Suffices to compute FP (e1 ? e2 . ? en)
• Each ei is a literal
• First convert ? to an equivalent conjunctive
  normal form (CNF)
• Rest of the talk, assume n 1 (simplicity)
• Concentrate on computing FP (e)

14
Decision Procedure (DP)

• Input
• A set G g1,, gm of literals
• A literal e
• Output
• Is G ? e valid?
• Equivalently
• Is g1 ? .. gm ? ?e UNSAT?
• Is G ? ?e UNSAT?

15
Symbolic Decision Procedure (SDP)

• Input
• A set G g1,.,gm of atomic expressions
• An atomic expression e
• Output
• Representation for
• G G ? G, and G ? ?e is UNSAT
• Symbolic Decision Procedure
• One run of SDP(G,e) represents an exponential
  (2G) number of runs of DP(G,e)

16
Predicate Abstraction and SDP

• PBar ?p p ? P
• SDP(P ? PBar, e) represents FP (e)
• FP (e)
• all minterms over P ? PBar that imply e
• SDP(P ? PBar, e)
• G G ? P ? PBar , and G ? ?e is UNSAT

17
Overview of SDP

• Symbolic Decision Procedures
• Predicate abstraction
• SDP for Equality Logic
• Combining SDP for two theories

18
A Decision Procedure for Equality Logic

• Atomic expressions
• x y, x ? y
• Inference Rules (R)
• Reflexivity, Symmetry, Transitivity
• Contradiction
• x y, x ? y ? ?
• Inference rule
• generates a new expression from existing
  expressions

19
A Decision Procedure for Equality Logic
G ab,bc e (a c)

• Atomic expressions
• x y, x ? y
• Inference Rules (R)
• Reflexivity, Symmetry, Transitivity
• Contradiction
• x y, x ? y ? ?
• Inference rule
• generates a new expression from existing
  expressions

20
A Decision Procedure for Equality Logic
G ? ?e

• Atomic expressions
• x y, x ? y
• Inference Rules (R)
• Reflexivity, Symmetry, Transitivity
• Contradiction
• x y, x ? y ? ?
• Inference rule
• generates a new expression from existing
  expressions

R
R
lg(G)
R
Yes
Contains ?
UNSAT
SAT
21
Symbolic DP for Equality Logic
G ab,bc,ad,dc e (a c)

• Modifications
• Introduce a Boolean variable g for each
  expression g in G
• Add true for ?e
• Construct a shared expression for the
  derivations

a b
b c
true
a d
d c
a b
b c
a ? c
a d
d c
22
Symbolic DP for Equality Logic
G ab,bc,ad,dc e (a c)

• Modifications
• Introduce a Boolean variable g for each
  expression g in G
• Add true for ?e
• Construct a shared expression for the
  derivations

a b
b c
true
a d
d c
a ? c
a b
b c
a d
d c
a ? c
a c
23
Symbolic DP for Equality Logic
G ab,bc,ad,dc e (a c)

• Modifications
• Introduce a Boolean variable g for each
  expression g in G
• Add true for ?e
• Construct a shared expression for the
  derivations
• SDP(G,e)
• The expression representing ? after lg(G)
  steps

a b
b c
true
a d
d c
a ? c
a b
b c
a d
d c
a ? c
a c
?
24
Symbolic DP for Equality Logic
G ab,bc,ad,dc e (a c)

• Output
• A shared Boolean expression with . variables in
  the leaves

a b
b c
true
a d
d c
a ? c
a b
b c
a d
d c
a ? c
a c
?
25
SDP for Equality Logic

• Expression representing ? after lg(G) steps
• Shared expression for G G ? G, and DP(G,e)
  is UNSAT
• Shared expression can be computed in polynomial
  time
• Derivations repeated for lg(G) steps
• Each step has at most V2 atomic expressions
• V number of vars in G

26
SDP for other theories
G ? ?e

• Bounded-depth Saturating Theory T
• Decision procedure for T can be implemented by
  saturation
• Provide a function Depth G ?Nat, to denote the
  max. depth to iterate

R
R
Depth(G)
R
Yes
No
Contains ?
UNSAT
SAT
27
SDP for other theories

• Equality with Uninterpreted Functions (EUF)
• Expressions f(x) f(g(y)), x f(z)
• Depth(G) lt 3m
• m is the number of terms in G
• Polynomial Complexity of SDP
• Difference Logic (DIFF)
• Expressions x ? y c
• Depth(G) lt lg(G)
• Pseudo Polynomial Complexity of SDP
• Depends on the size of constants in G

28
Overview of SDP

• Predicate Abstraction
• Symbolic Decision Procedures
• Predicate abstraction
• SDP for Equality Logic
• Combining SDP for two theories

29
Combining SDPs for two theories

• Extend Nelson-Oppen method for combining decision
  procedures for two theories T1, T2
• Nelson, Oppen TOPLAS 79
• The decision procedures communicate via
  equalities over shared variables
• Given SDP1 and SDP2 for theories T1, T2
• Disjoint signatures, convex theories
• Each theory generates derivations of all
  equalities between variables
• Complexity of the resultant SDP (for T1?T2) only
  increases linearly in the number of variables

30
Combining SDP for two theories
G1
SDP1
G2
N number of shared variables
xy
SDP2
G1
xy
SDP1
31
Combining SDP for theories

• Combined SDP for EUF DIFF
• Pseudo Polynomial complexity
• Important fragment of most program verification
  queries (especially in SLAM)

32
SDP to Predicate Abstraction

• Output of SDP is an Expression DAG
• Represents FP (e)
• Can be used directly to construct Boolean
  programs (with intermediate variables)
• To compute explicit expression for FP (e)
• Construct a Binary Decision Diagram (BDD) from
  SDP, and enumerate prime-implicants
• BDDs crucial for exploiting the shared
  representation

33
Evaluation

• SLAM benchmarks
• Generated 665 predicate abstraction queries from
  device driver verification
• Decision Procedure (Zapato) based approach
  27904sec
• SDP based approach 273s
• 100X speedup

34
Challenges

• SDP for other interesting theories and
  combinations
• Linear arithmetic, non-convex theories
• Incremental SDPs
• Useful for combining SDPs
• Output sensitive predicate abstraction?
• Complexity is polynomial in the number of
  minterms in the output

35
Conclusion

• Predicate abstraction via symbolic decision
  procedures
• Polynomial algorithms for useful theories
• Modular combination of Symbolic Decision
  Procedures for theories
• Can design SDP for each theory in isolation
• Simple prototype implementation
• Promising results on SLAM queries

36
Overview of the talk

• Two approaches to predicate abstraction
• Symbolic Decision Procedures
• Satisfiability Modulo Theory (SMT) based
• Symbolic decision procedures (SDP)
• Lahiri, Ball, Cook CAV05
• SMT-based predicate abstraction
• Eager Lahiri, Bryant, Cook CAV03
• DPLL(T) based Lahiri, Oliveras, Nieuwenhuis
  CAV06
• Challenges ahead

37
SMT-based predicate abstraction
38
Satifiability Modulo Theories (SMT)

• SMT
• Decide satisfiability of a (ground) first-order
  formula with respect to a background theory T
• Example (EUF)
• g(a) c ? (f(g(a)) ? f(c) ? g(a) d) ? c ? d
• SMT-solvers
• Leverages efficient Boolean search of Boolean
  satifiability (SAT) solvers

39
SMT for predicate abstraction

• Input
• A formula ?, a set of predicates P over a theory
  T
• Output
• GP (?) External predicate cover of ?
• Same as ?FP (??)
• Main Idea Lahiri et al. CAV03, Clarke et al.
  FMSD 04
• Introduce fresh Boolean variables B b1,.., bn
• Construct the formula ? ? (?i (bi ? Pi))
• Enumerate all the models over B

40
Eager SMT techniques
? (X, B)

• Methodology
• Translates a (ground) formula into
  equisatisfiable Boolean formula
• Use off-the-shelf SAT solvers to check the
  satisfiability
• Tools UCLID

Equisatisfiable Translation
?bool (A, B)
Variables introduced during translation
41
Predicate abstraction using eager SMT techniques
? ? (?i (bi ? Pi))

• Methodology
• Lahiri, Bryant, Cook CAV03
• Translates a (ground) formula into Boolean
  formula
• Use off-the-shelf BDD or SAT solvers to perform
  AllSAT over B
• Implemented in UCLID
• Uses SATQE (Kroening)

Equisatisfiable Translation Preserves
solutions over Boolean variables
Equisatisfiable Translation
?bool (A, B)
Variables introduced during translation
42
Advantage over explicit approach

• Single Call to SAT-based Quantification Engine
• Removes exponential number of calls to theorem
  prover
• Learning in Incremental SAT
• Retains conflict clauses across different
  solutions
• Leverage future advances in SAT
• Without any change to the framework

43
Evaluation

• Compared with a black-box decision procedure
  based approach
• Das, Dill and Park, CAV99
• SLAM benchmarks
• Device driver verification
• Eager SMT technique improves 50-100X on many
  benchmarks
• Distributed protocol verification (UCLID)
• Lahiri, Bryant VMCAI04
• Decision procedure (SVC/CVC) based approach
  unable to finish on most examples
• gt 10,000 theorem prover calls

44
Lazy SMT techniques

• Integrate a theory T-solver with SAT solver
• Lazily rule out T-inconsistent Boolean models
  using theory solver
• CVC-Lite, Verifun, MathSAT, Barcelogic,
• Barcelogic Tool
• R. Nieuwenhuis and A. Oliveras CAV05
• Optimizations (based on DPLL(T))
• Check partial Boolean models for T-inconsistency
• Upon T-inconsistency, use the explanation as a
  conflicting clause and perform backjump
• Theory (unit) propagation to generate implied
  facts

45
Predicate abstraction using lazy methods

• Lahiri, Nieuwenhuis, Oliveras CAV06, using
  Barcelogic
• Enumerate all the models over B for
• ? ? ? ? (?i (bi ? Pi))
• while ? is T-satisfiable do
• M T-model for ? using SMT-solver
• M project M onto B
• Consider ?M as a conflicting clause
• Perform conflict analysis to generate backjump
  clause
• Optionally add backjump clause
• Backjump and continue
• return all models over B

46
Experimental results

• SLAM benchmarks
• 5seconds on 665 benchmarks
• gt 100X improvement on SDP based approach
• Hardware and protocol benchmarks UCLID
• 7 set of benchmarks
• 22X 143X improvement over Eager-SMT based
  approach
• Linked list verification Lahiri, Qadeer POPL06
• 4 set of benchmarks
• 31X 40X improvement over Eager-SMT based
  approach
• SDP-based technique not applied on the latter two
  classes
• Need support for (sound) quantifier-reasoning

47
Hardware and protocol benchmarks
Benchmarks Preds Eager (secs) Lazy (secs) minterms cubes
Aodv 21 657 4.6 2916 458
Bakery 32 245 11 426 294
BRP 22 3.5 0.1 30 24
Cache_ibm 16 34 1.3 326 123
Cache_ibm2 26 1119 23 2238 1022
Dlx 23 335 13 30808 2704
OOO 25 921 36 10728 242
cubes Number of prime-implicants in the BDD
for the minterms

• Theory propagation crucial for benchmarks with
  arithmetic
• E.g. 17X slowdown in OOO without it
• Reusing lemmas and clauses improves 1.5X 3X on
  most examples

48
Conclusions

• Relatively easy to turn SMT solver to perform
  predicate abstraction
• Clear benefit from leveraging learned clause and
  not restarting the search after each model
• Improvements in SMT translate to predicate
  abstraction case

49
Overview of the talk

• Two approaches to predicate abstraction
• Symbolic Decision Procedures
• Satisfiability Modulo Theory (SMT) based
• Symbolic decision procedures (SDP)
• Lahiri, Ball, Cook CAV05
• SMT-based predicate abstraction
• Eager Lahiri, Bryant, Cook CAV03
• DPLL(T) based Lahiri, Oliveras, Nieuwenhuis
  CAV06
• Challenges ahead

50
Summary

• Symbolic decision procedures
• Can construct DAG representation of output in
  polynomial time for useful theories
• Modular combination of SDPs
• Require more optimizations to make it practical
• SMT-based procedures
• Can leverage SMT solvers without much effort
• ALLSAT using SAT-solvers (Eager) or SMT solvers
  (Lazy)
• Lazy approaches benefit from tighter SATtheory
  reasoning

51
Challenges for predicate abstraction tools

• Predicate abstraction with non-ground formulas
• Quantifiers were removed with simple
  instantiation techniques for UCLID/List
  verification benchmarks
• Generate partial models during ALLSAT
• Should improve the performace when ratio of
  minterms cubes is large
• Incremental refinement of approximations
• Construct refined approximation of FP (?) from
  coarser approximations, without repeating work
• Some initial directions in CAV06 paper
• Refining the abstraction (incrementally) with
  monotonically increasing set of predicates

52
Questions?
53
(No Transcript)
54
Overview

• Predicate Abstraction
• Symbolic Decision Procedures (SDP)
• Predicate abstraction
• SDP for Equality Logic
• Combining SDP for two theories
• Implementation and Results
• Related Work

55
Zap Overview

• Ball, Lahiri, Musuvathi
• Many automated program analysis tools require
  symbolic reasoning
• e.g. Unit-testing, model checking, static
  analysis,
• Support symbolic operations for such tools
• Support richer operations, apart from validity
  checking
• Support useful theories for program analysis
• Leverage advances in SAT solving and theorem
  proving

MUTT unit-testing
Zing model checking
Boogie static analysis
SLAM/SDV
Zap theorem prover
56
Symbolic Reasoning for Automated Software Analysis

• Validity / Satisfiability
• Model generation
• Useful in test case generation
• Quantifier elimination
• Image operation in model checking
• Abstract interpretation operations
• abstract transformers, join, widen
• Interpolants
• For abstraction-refinement

57
Interesting Theories

• Theories
• Equality with uninterpreted functions (EUF)
• Linear Arithmetic
• Arrays
• Bounded Integers
• Lists
• Sets
• Combine the symbolic operations for different
  theories

58
Symbolic Reasoning for Automated Software Analysis

• Validity / Satisfiability
• Model generation
• Useful in test case generation
• Quantifier elimination
• Image operation in model checking
• Abstract interpretation operations
• abstract transformers, join, widen
• Interpolants
• For abstraction-refinement

59
?FP (??)
60
Evaluation

• SLAM benchmarks
• Generated 665 predicate abstraction queries from
  device driver verification
• Decision Procedure based approach 27904sec
• SDP based approach 273s
• 100X speedup
• Synthetic benchmark
• Comparison with UCLID
• More than 100X speedup

61
Related Work

• Decision Procedure Based
• Calls a decision procedure to check implication
  with each minterm
• Das Dill, Saidi Shankar,
• Boolean Quantifier Elimination Based
• Lahiri, Bryant, Cook, CAV 03, Clarke et al.,
  FMSD 04
• Performs predicate abstraction by quantifier
  elimination
• Reduces restricted first-order quantifier
  elimination to Boolean quantifier elimination

62
Experimental Setup

• Symbolic Method
• Incremental SAT-based method
• SATQE Simple extension to Zchaff
• Built by Daniel Kroening at CMU
• Explicit Method
• Algorithm of Das, Dill Park, CAV99
• Avoids exponential worst case in many cases in
  practice
• Uses SVC as a decision procedure
• Device Driver Benchmarks from SLAM Toolkit
• Ball and Rajamani, MSR
• Queries during C ? Boolean Program construction

63
Evaluation on SLAM-benchmarks
Example Preds Explicit Explicit Symbolic Symbolic
Example Preds Calls Time (sec) Prop-vars SAT-based time (sec)
Dr.10 19 gt7576 gt1000 115 9.9
Dr.13 20 gt7351 gt1000 234 44.7
Dr.15 23 gt7237 gt1000 336 68.2
Dr.17 15 3041 507 105 6.1
Dr.3 13 2023 355 125 7.0

• BDD based approach worse than SAT on larger
  benchmarks

64
Symbols

• ?????????????????????????????????????????????

65
Challenges ahead
