A Shoulder Pad Insert Vibrotactile Display

1
A Shoulder Pad Insert Vibrotactile Display
ISWC 2003

• Aaron Toney
• Bruce H. Thomas
• Wearable Computer Laboratory
• University of South Australia

Lucy Dunne Susan P. Ashdown Department of
Textiles and Apparel Cornell University
2
Our Goals for Todays Mass-Market Wearable Devices

1. Maintain consumers current relationship with
   garments (physical, psychological, and social)
2. Minimize impact of devices on user social
   interactions (minimize social weight)

3
Wearable Integration

• Embedding technology within the current structure
  of clothing imposes restrictions on
• Size
• Weight
• Form factor
• User interface options

4
Our Solution Standard Clothing Inserts
5
What are Standard Clothing Inserts?

• Layers of padding, interfacing, or other
  materials meant to give shape, strength, or
  protective function to the garment.
• Location and function of clothing inserts vary
  with age, gender, season, garment function, and
  current fashions.
• Inserts are a fundamental part of the clothing
  structure, not pockets which are added to the
  surface.

6
Standard Clothing Inserts
7
Standard Clothing Inserts

• Exist in many common garments
• Maintain physical and psychological expectations
  and user relationships between wearer and
  garment
• Minimize outward appearance of electronics,
  diminishing social impact of augmented garments

8
But I Dont Wear Shoulder Pads Anymore!
9
Goals of this Research

• Examine the utility of clothing inserts as a
  housing space for electronic components.
• Evaluate the potential of shoulder worn
  vibrotactile displays

10
Why a Tactile Shoulder Pad?

• Proximity of clothing to the body provides
  optimal opportunity for integration of tactile
  displays
• Shoulder area is a culturally habitual area for
  receiving tactile stimuli
• Shoulder pad provides a pre-existing volume in
  which to embed electronics.
• Shoulder pad is a part of the business suit, one
  of the most standardized garment systems in our
  culture.

11
Some Applications for a Tactile Shoulder Display

• Navigation for both fully-sighted and
  seeing-impaired individuals
• Silent alerts
• Socially subtle transmission of information
• Motion guidance for physical activities

12
Development of a Shoulder Pad Insert Vibrotactile
Display
13
Fitting the Population
ANSUR Measures Used

• Army ANSUR database of anthropometric measures
• 3,982 subjects 2,208 female
• US Army population

A Shoulder Length, B Cervicale Height, C
Axilla Height, D Acromial Height
14
Derived Body Size Specifications
Body Size
Pad Size
15
Fabrication of Shoulder Pad

• Conflicting goals
• Stability and structure
• Isolation of individual vibration areas
• Compromise a layered prototype

16
Fabrication of Shoulder Pad Final Prototype
Pad interior, showing layers and motor attachment
(4-motor configuration)
Pad closure, outside edge
17
Integration of Vibrotactile Shoulder Pad into
Test Jackets
18
Fabrication of Shoulder Pad Prototype
Configurations
Motor locations for right shoulder 4- and 6-
motor configurations pictured against the shoulder
19
Experimental Subjects

• 12 subjects, all female
• Ages 19-34
• Varied body types and sizes
• Shoulder lengths 9 - 14.5cm

20
Experimental Procedure Subjects
21
Experimental Procedure Trials

• Tested dominant side
• Motor activation
• individuals, pairs, threes, fours, fives, and
  sixes, randomly generated combinations
• total 15 trials for 4-motor configuration, 24
  trials for 6-motor configuration
• Subjects responded on generic torso figure (open
  response)

22
Experimental Procedure Subject Responses
23
Experimental Procedure Qualitative Questionnaire

• Following pad testing, subjects completed a
  questionnaire concerning
• comfort of the electronic shoulder pad vs.
  standard shoulder pad
• comfort of vibrational sensation
• mental difficulty in determining location of
  stimulus

24
Results Mapping Stimuli
Composite subject responses responses often
covered a much larger area than the actual
shoulder pad.
25
Results Comfort

• All subjects found the electronic shoulder pads
  at least as comfortable as the standard shoulder
  pads
• Subject responses to the vibration stimulus
  varied from soothing or comforting (3 subjects)
  to annoying or ticklish (3 subjects), but most
  subjects found the stimulus neither annoying nor
  comfortable

26
Results Cognitive Load

• Generally high concentration level
• Qualitative responses
• Observational data
• Reflected in accuracy of responses
• Stimuli appeared less difficult to localize in
  4-motor configuration

27
Results Perception of Motors

• Each subject experienced at least one motor
  location that could not be felt.
• Subject perceptions generally consistent
  throughout trials
• Motor coupling effects extended the perceived
  activation area

28
Example of a Missed Motor for One Subject

• Redactual activated motors
• Shadingsubject response
• Lower front motor missed in both trials

Trial 1
Trial 2
29
Results Missed Motors
Shoulder
Shoulder

• Body locations of consistently missed motors are
  not consistent between the 4-motor and 6-motor
  configuration.

Neck
Neck
Missed Motors Miss frequency for each motor
location

• The neck-edge motor was missed in both
  configurations.

30
Conclusions

• Shoulder worn displays show promise for wearable
  multi-bit wide displays.
• Garment inserts provide a viable space to house
  electronic components for wearable devices.
• Each subject felt at least one combination of
  motors.
• Distinct perceptibility of individual motors or
  patterns varied considerably between subjects.
• Individual subjects perceptions were consistent
  throughout testing.

31
Future Work

• Further experimentation to determine consistent
  perceptibility
• Wireless shoulder pad unit
• Testing of moving tactile patterns
• Use of shoulder pad to transmit information
• Involve in a physiologist for further
  multidisciplinary insights

32
Future Work
Come See our Demo! Broadcloth Special Interest
Smart Clothing Listserve email
broadcloth_at_hhhh.org subject line subscribe
