Connecting Computer Modules

1
Connecting Computer Modules
2
Connecting

• All the units must be connected
• Different type of connection for different type
  of unit
• Memory
• Input/Output
• CPU

3
Computer Modules
4
Memory Connection

• Receives and sends data
• Receives addresses (of locations)
• Receives control signals
• Read
• Write
• Timing

5
Input/Output Connection(1)

• Similar to memory from computers viewpoint
• Output
• Receive data from computer
• Send data to peripheral
• Input
• Receive data from peripheral
• Send data to computer

6
Input/Output Connection(2)

• Receive control signals from computer
• Send control signals to peripherals
• e.g. spin disk
• Receive addresses from computer
• e.g. port number to identify peripheral
• Send interrupt signals (control)

7
CPU Connection

• Reads instruction and data
• Writes out data (after processing)
• Sends control signals to other units
• Receives ( acts on) interrupts

8
Buses

• There are a number of possible interconnection
  systems
• Single and multiple BUS structures are most
  common
• e.g. Control/Address/Data bus (PC)
• e.g. Unibus (DEC-PDP)

9
What is a Bus?

• A communication pathway connecting two or more
  devices
• Usually broadcast
• Often grouped
• A number of channels in one bus
• e.g. 32 bit data bus is 32 separate single bit
  channels
• Power lines may not be shown

10
Data Bus

• Carries data
• Remember that there is no difference between
  data and instruction at this level
• Width is a key determinant of performance
• 8, 16, 32, 64 bit

11
Address bus

• Identify the source or destination of data
• e.g. CPU needs to read an instruction (data) from
  a given location in memory
• Bus width determines maximum memory capacity of
  system
• e.g. 8080 has 16 bit address bus giving 64k
  address space

12
Control Bus

• Control and timing information
• Memory read/write signal
• Interrupt request
• Clock signals

13
Bus Interconnection Scheme
14
Big and Yellow?

• What do buses look like?
• Parallel lines on circuit boards
• Ribbon cables
• Strip connectors on mother boards
• e.g. PCI
• Sets of wires

15
Single Bus Problems

• Lots of devices on one bus leads to
• Propagation delays
• Long data paths mean that co-ordination of bus
  use can adversely affect performance
• If aggregate data transfer approaches bus
  capacity
• Most systems use multiple buses to overcome these
  problems

16
Traditional (ISA)(with cache)
17
High Performance Bus
18
Bus Types

• Dedicated
• Separate data address lines
• Multiplexed
• Shared lines
• Address valid or data valid control line
• Advantage - fewer lines
• Disadvantages
• More complex control
• Ultimate performance

19
Bus Arbitration

• More than one module controlling the bus
• e.g. CPU and DMA controller
• Only one module may control bus at one time
• Arbitration may be centralised or distributed

20
Centralised Arbitration

• Single hardware device controlling bus access
• Bus Controller
• Arbiter
• May be part of CPU or separate

21
Distributed Arbitration

• Each module may claim the bus
• Control logic on all modules

22
Timing

• Co-ordination of events on bus
• Synchronous
• Events determined by clock signals
• Control Bus includes clock line
• A single 1-0 is a bus cycle
• All devices can read clock line
• Usually sync on leading edge
• Usually a single cycle for an event

23
Synchronous Timing Diagram
24
Asynchronous Timing Read Diagram
25
Asynchronous Timing Write Diagram
26
PCI Bus

• Peripheral Component Interconnection
• Intel released to public domain
• 32 or 64 bit
• 50 lines

27
PCI Bus Lines (required)

• Systems lines
• Including clock and reset
• Address Data
• 32 time mux lines for address/data
• Interrupt validate lines
• Interface Control
• Arbitration
• Not shared
• Direct connection to PCI bus arbiter
• Error lines

28
PCI Bus Lines (Optional)

• Interrupt lines
• Not shared
• Cache support
• 64-bit Bus Extension
• Additional 32 lines
• Time multiplexed
• 2 lines to enable devices to agree to use 64-bit
  transfer
• JTAG/Boundary Scan
• For testing procedures

29
PCI Commands

• Transaction between initiator (master) and target
• Master claims bus
• Determine type of transaction
• e.g. I/O read/write
• Address phase
• One or more data phases

30
PCI Read Timing Diagram
31
PCI Bus Arbitration
32
Memory Structures

• Mix chapter 4 and 5

33
Characteristics of Memory

• Location
• Capacity
• Unit of transfer
• Access method
• Performance
• Physical type
• Physical characteristics
• Organisation

34
Location

• CPU
• Internal
• External

35
Capacity

• Word size
• The natural unit of organization
• Number of words
• or Bytes

36
Unit of Transfer

• Internal
• Usually governed by data bus width
• External
• Usually a block which is much larger than a word
• Addressable unit
• Smallest location which can be uniquely addressed
• Word internally
• Cluster on M disks

37
Access Methods (1)

• Sequential
• Start at the beginning and read through in order
• Access time depends on location of data and
  previous location
• e.g. tape
• Direct
• Individual blocks have unique address
• Access is by jumping to vicinity plus sequential
  search
• Access time depends on location and previous
  location
• e.g. disk

38
Access Methods (2)

• Random
• Individual addresses identify locations exactly
• Access time is independent of location or
  previous access
• e.g. RAM
• Associative
• Data is located by a comparison with contents of
  a portion of the store
• Access time is independent of location or
  previous access
• e.g. cache

39
Memory Hierarchy

• Registers
• In CPU
• Internal or Main memory
• May include one or more levels of cache
• RAM
• External memory
• Backing store

40
Memory Hierarchy - Diagram
41
Performance

• Access time
• Time between presenting the address and getting
  the valid data
• Memory Cycle time
• Time may be required for the memory to recover
  before next access
• Cycle time is access recovery
• Transfer Rate
• Rate at which data can be moved

42
Physical Types

• Semiconductor
• RAM
• Magnetic
• Disk Tape
• Optical
• CD DVD
• Others
• Bubble
• Hologram

43
Physical Characteristics

• Decay
• Volatility
• Erasable
• Power consumption

44
Organization

• Physical arrangement of bits into words
• Not always obvious
• e.g. interleaved

45
The Bottom Line

• How much?
• Capacity
• How fast?
• Time is money
• How expensive?

46
Hierarchy List

• Registers
• L1 Cache
• L2 Cache
• Main memory
• Disk cache
• Disk
• Optical
• Tape

47
Internal Memory
48
Semiconductor Memory Types
49
Semiconductor Memory

• RAM
• Misnamed as all semiconductor memory is random
  access
• Read/Write
• Volatile
• Temporary storage
• Static or dynamic

50
Memory Cell Operation
51
Dynamic RAM

• Bits stored as charge in capacitors
• Charges leak
• Need refreshing even when powered
• Simpler construction
• Smaller per bit
• Less expensive
• Need refresh circuits
• Slower
• Main memory
• Essentially analogue
• Level of charge determines value

52
Dynamic RAM Structure
53
DRAM Operation

• Address line active when bit read or written
• Transistor switch closed (current flows)
• Write
• Voltage to bit line
• High for 1 low for 0
• Then signal address line
• Transfers charge to capacitor
• Read
• Address line selected
• transistor turns on
• Charge from capacitor fed via bit line to sense
  amplifier
• Compares with reference value to determine 0 or 1
• Capacitor charge must be restored

54
Static RAM

• Bits stored as on/off switches
• No charges to leak
• No refreshing needed when powered
• More complex construction
• Larger per bit
• More expensive
• Does not need refresh circuits
• Faster
• Cache
• Digital
• Uses flip-flops

55
Static RAM Structure
56
Static RAM Operation

• Transistor arrangement gives stable logic state
• State 1
• C1 high, C2 low
• T1 T4 off, T2 T3 on
• State 0
• C2 high, C1 low
• T2 T3 off, T1 T4 on
• Address line transistors T5 T6 is switch
• Write apply value to B compliment to B
• Read value is on line B

57
SRAM v DRAM

• Both volatile
• Power needed to preserve data
• Dynamic cell
• Simpler to build, smaller
• More dense
• Less expensive
• Needs refresh
• Larger memory units
• Static
• Faster
• Cache

58
Read Only Memory (ROM)

• Permanent storage
• Nonvolatile
• Microprogramming (see later)
• Library subroutines
• Systems programs (BIOS)
• Function tables

59
Types of ROM

• Written during manufacture
• Very expensive for small runs
• Programmable (once)
• PROM
• Needs special equipment to program
• Read mostly
• Erasable Programmable (EPROM)
• Erased by UV
• Electrically Erasable (EEPROM)
• Takes much longer to write than read
• Flash memory
• Erase whole memory electrically

60
Organization in detail

• A 16Mbit chip can be organised as 1M of 16 bit
  words
• A bit per chip system has 16 lots of 1Mbit chip
  with bit 1 of each word in chip 1 and so on
• A 16Mbit chip can be organised as a 2048 x 2048 x
  4bit array
• Reduces number of address pins
• Multiplex row address and column address
• 11 pins to address (2112048)
• Adding one more pin doubles range of values so x4
  capacity

61
Refreshing

• Refresh circuit included on chip
• Disable chip
• Count through rows
• Read Write back
• Takes time
• Slows down apparent performance

62
Typical 16 Mb DRAM (4M x 4)
63
Packaging
64
Module Organization
65
Module Organization (2)
66
Error Correction

• Hard Failure
• Permanent defect
• Soft Error
• Random, non-destructive
• No permanent damage to memory
• Detected using Hamming error correcting code

67
Error Correcting Code Function
68
Advanced DRAM Organization

• Basic DRAM same since first RAM chips
• Enhanced DRAM
• Contains small SRAM as well
• SRAM holds last line read (c.f. Cache!)
• Cache DRAM
• Larger SRAM component
• Use as cache or serial buffer

69
Synchronous DRAM (SDRAM)

• Access is synchronized with an external clock
• Address is presented to RAM
• RAM finds data (CPU waits in conventional DRAM)
• Since SDRAM moves data in time with system clock,
  CPU knows when data will be ready
• CPU does not have to wait, it can do something
  else
• Burst mode allows SDRAM to set up stream of data
  and fire it out in block
• DDR-SDRAM sends data twice per clock cycle
  (leading trailing edge)

70
IBM 64Mb SDRAM
71
SDRAM Operation
72
RAMBUS

• Adopted by Intel for Pentium Itanium
• Main competitor to SDRAM
• Vertical package all pins on one side
• Data exchange over 28 wires lt cm long
• Bus addresses up to 320 RDRAM chips at 1.6Gbps
• Asynchronous block protocol
• 480ns access time
• Then 1.6 Gbps

73
RAMBUS Diagram
74
Cache Memory
75
So you want fast?

• It is possible to build a computer which uses
  only static RAM (see later)
• This would be very fast
• This would need no cache
• How can you cache cache?
• This would cost a very large amount

76
Locality of Reference

• During the course of the execution of a program,
  memory references tend to cluster
• e.g. loops

77
Cache

• Small amount of fast memory
• Sits between normal main memory and CPU
• May be located on CPU chip or module

78
Cache operation - overview

• CPU requests contents of memory location
• Check cache for this data
• If present, get from cache (fast)
• If not present, read required block from main
  memory to cache
• Then deliver from cache to CPU
• Cache includes tags to identify which block of
  main memory is in each cache slot

79
Cache Design

• Size
• Mapping Function
• Replacement Algorithm
• Write Policy
• Block Size
• Number of Caches

80
Size does matter

• Cost
• More cache is expensive
• Speed
• More cache is faster (up to a point)
• Checking cache for data takes time

81
Typical Cache Organization
82
Mapping Function

• Cache of 64kByte
• Cache block of 4 bytes
• i.e. cache is 16k (214) lines of 4 bytes
• 16MBytes main memory
• 24 bit address
• (22416M)

83
Direct Mapping

• Each block of main memory maps to only one cache
  line
• i.e. if a block is in cache, it must be in one
  specific place
• Address is in two parts
• Least Significant w bits identify unique word
• Most Significant s bits specify one memory block
• The MSBs are split into a cache line field r and
  a tag of s-r (most significant)

84
Direct MappingAddress Structure
Tag s-r
Line or Slot r
Word w
14
2
8

• 24 bit address
• 2 bit word identifier (4 byte block)
• 22 bit block identifier
• 8 bit tag (22-14)
• 14 bit slot or line
• No two blocks in the same line have the same Tag
  field
• Check contents of cache by finding line and
  checking Tag

85
Direct Mapping Cache Line Table

• Cache line Main Memory blocks held
• 0 0, m, 2m, 3m2s-m
• 1 1,m1, 2m12s-m1
• m-1 m-1, 2m-1,3m-12s-1

86
Direct Mapping Cache Organization
87
Direct Mapping Example
88
Direct Mapping Summary

• Address length (s w) bits
• Number of addressable units 2sw words or bytes
• Block size line size 2w words or bytes
• Number of blocks in main memory 2s w/2w 2s
• Number of lines in cache m 2r
• Size of tag (s r) bits

89
Direct Mapping pros cons

• Simple
• Inexpensive
• Fixed location for given block
• If a program accesses 2 blocks that map to the
  same line repeatedly, cache misses are very high

90
Associative Mapping

• A main memory block can load into any line of
  cache
• Memory address is interpreted as tag and word
• Tag uniquely identifies block of memory
• Every lines tag is examined for a match
• Cache searching gets expensive

91
Fully Associative Cache Organization
92
Associative Mapping Example
93
Associative MappingAddress Structure
Word 2 bit
Tag 22 bit

• 22 bit tag stored with each 32 bit block of data
• Compare tag field with tag entry in cache to
  check for hit
• Least significant 2 bits of address identify
  which 16 bit word is required from 32 bit data
  block
• e.g.
• Address Tag Data Cache line
• FFFFFC FFFFFC 24682468 3FFF

94
Associative Mapping Summary

• Address length (s w) bits
• Number of addressable units 2sw words or bytes
• Block size line size 2w words or bytes
• Number of blocks in main memory 2s w/2w 2s
• Number of lines in cache undetermined
• Size of tag s bits

95
Set Associative Mapping

• Cache is divided into a number of sets
• Each set contains a number of lines
• A given block maps to any line in a given set
• e.g. Block B can be in any line of set i
• e.g. 2 lines per set
• 2 way associative mapping
• A given block can be in one of 2 lines in only
  one set

96
Set Associative MappingExample

• 13 bit set number
• Block number in main memory is modulo 213
• 000000, 00A000, 00B000, 00C000 map to same set

97
Two Way Set Associative Cache Organization
98
Set Associative MappingAddress Structure
Word 2 bit
Tag 9 bit
Set 13 bit

• Use set field to determine cache set to look in
• Compare tag field to see if we have a hit
• e.g
• Address Tag Data Set number
• 1FF 7FFC 1FF 12345678 1FFF
• 001 7FFC 001 11223344 1FFF

99
Two Way Set Associative Mapping Example
100
Set Associative Mapping Summary

• Address length (s w) bits
• Number of addressable units 2sw words or bytes
• Block size line size 2w words or bytes
• Number of blocks in main memory 2d
• Number of lines in set k
• Number of sets v 2d
• Number of lines in cache kv k 2d
• Size of tag (s d) bits

101
Replacement Algorithms (1)Direct mapping

• No choice
• Each block only maps to one line
• Replace that line

102
Replacement Algorithms (2)Associative Set
Associative

• Hardware implemented algorithm (speed)
• Least Recently used (LRU)
• e.g. in 2 way set associative
• Which of the 2 block is lru?
• First in first out (FIFO)
• replace block that has been in cache longest
• Least frequently used
• replace block which has had fewest hits
• Random

103
Write Policy

• Must not overwrite a cache block unless main
  memory is up to date
• Multiple CPUs may have individual caches
• I/O may address main memory directly

104
Write through

• All writes go to main memory as well as cache
• Multiple CPUs can monitor main memory traffic to
  keep local (to CPU) cache up to date
• Lots of traffic
• Slows down writes
• Remember bogus write through caches!

105
Write back

• Updates initially made in cache only
• Update bit for cache slot is set when update
  occurs
• If block is to be replaced, write to main memory
  only if update bit is set
• Other caches get out of sync
• I/O must access main memory through cache
• N.B. 15 of memory references are writes

106
Pentium 4 Cache

• 80386 no on chip cache
• 80486 8k using 16 byte lines and four way set
  associative organization
• Pentium (all versions) two on chip L1 caches
• Data instructions
• Pentium 4 L1 caches
• 8k bytes
• 64 byte lines
• four way set associative
• L2 cache
• Feeding both L1 caches
• 256k
• 128 byte lines
• 8 way set associative

107
Pentium 4 Diagram (Simplified)
108
Pentium 4 Core Processor

• Fetch/Decode Unit
• Fetches instructions from L2 cache
• Decode into micro-ops
• Store micro-ops in L1 cache
• Out of order execution logic
• Schedules micro-ops
• Based on data dependence and resources
• May speculatively execute
• Execution units
• Execute micro-ops
• Data from L1 cache
• Results in registers
• Memory subsystem
• L2 cache and systems bus

109
Pentium 4 Design Reasoning

• Decodes instructions into RISC like micro-ops
  before L1 cache
• Micro-ops fixed length
• Superscalar pipelining and scheduling
• Pentium instructions long complex
• Performance improved by separating decoding from
  scheduling pipelining
• (More later ch14)
• Data cache is write back
• Can be configured to write through
• L1 cache controlled by 2 bits in register
• CD cache disable
• NW not write through
• 2 instructions to invalidate (flush) cache and
  write back then invalidate

110
Power PC Cache Organization

• 601 single 32kb 8 way set associative
• 603 16kb (2 x 8kb) two way set associative
• 604 32kb
• 610 64kb
• G3 G4
• 64kb L1 cache
• 8 way set associative
• 256k, 512k or 1M L2 cache
• two way set associative

111
PowerPC G4
112
Comparison of Cache Sizes
