3.Small Angle Neutron Scattering
3
ILL
ILL, Grenoble/FR the most advanced
Neutron Scattering facility in the world.
4
ILL Guide Hall
5
ILL Reactor
6
ILL Experimental Hall
7
SANS at ILL Beamline D22
8
SANS at IFF - Jülich / GE
9
NEUTRON Sources
10
NEUTRON Sources
11
(No Transcript)
12
(No Transcript)
13
(No Transcript)
14
(No Transcript)
15
(No Transcript)
16
Scattering lengths and Cross section
17
H2O vs. D2O
18
(No Transcript)
19
(No Transcript)
20
SANS Contrast Matching
21
Scattering from a Gaussian coil polymer in
solution
22
Scattering from a uniform sphere
23
Scattering from cylindrical shapes
24
Real SANS data
25
Real SANS data
26
Real SANS data
27
Real SANS data
28
Real SANS data
29
Real SANS data
30
Real SANS data
31
Real SANS data
32
Real SANS data
33
Real SANS data
34
Real SANS data
35
Real SANS data
36
Nucleation and growth studied by time-resolved
SANS
S.U. Egelhaaf (ILL), P. Schurtenberger (ETH
Zürich), J. Morris, U. Olsson, H. Wennerström
(Lund University)
Figure 1 Oligodisperse oil-in-water
microemulsion droplets are quenched into a two
phase area. At final equilibrium, smaller
droplets coexist with an excess oil phase that
nucleates at a few of the initial droplets which
subsequently grow (t gt 0), allowing the majority
of droplets to decrease in size. This growth
phase proceeds with a constant number of large
drops (t gtgt 0).
37
Nucleation and growth studied by time-resolved
SANS
S.U. Egelhaaf (ILL), P. Schurtenberger (ETH
Zürich), J. Morris, U. Olsson, H. Wennerström
(Lund University)
Figure 2 Sequence of scattering curves from a
time-resolved small-angle neutron-scattering
experiment recorded during the nucleation and
growth of an excess oil phase from oil-in-water
microemulsion droplets. For clarity only every
second measurement is shown. As an example the
scattering curve obtained at t 3150 s is added
as an inset.
38
Nucleation and growth studied by time-resolved
SANS
S.U. Egelhaaf (ILL), P. Schurtenberger (ETH
Zürich), J. Morris, U. Olsson, H. Wennerström
(Lund University)
Figure 3 Time-dependence of the radius of
gyration Rg,big as obtained from a Guinier fit.
Also shown is the power law behaviour expected
for a classical Ostwald ripening process.
39
(No Transcript)
40
(No Transcript)
41
(No Transcript)
42
(No Transcript)
43
(No Transcript)
44
