ATC Divisions

1
COMSOFT
is making the link
COMSOFT AFTN/AMHS Products AIDA-NG and CADAS
Chennai, 17.12.2008 Uwe Kurpat, AFTN/AMHS
Product Manager
2
AIDA-NG/CADAS Products

• AIDA-NG

• COMSOFT's Advanced Message Handling Product

• CADAS

• ATS Client/Server System with integrated AMHS UA

AIDA-NG and CADAS are most mature AMHS products,
which are in operation in almost all ICAO Regions
3
AIDA-NG AMHS/CIDIN/AFTN Product

• AIDA-NG

• Aeronautical Integrated Data Exchange Agent -
  Next Generation

• Development History
• 1992 AFTN/CIDIN product AIDA
• 1998 Major re-design for AMHS ? AIDA-NG

4
AIDA-NG General Characteristics

• ATS message server with AFTN/AMHS gateway fully
  compliant to ICAO ATN SARPs
• Full support of IP-based networks (AMHS, AFTN)
• Full conventional AFTN/CIDIN message switch (Doc
  8259, Annex 10, EUR CIDIN Manual)
• IATA Type-B-message switch (extension
  possibility)
• Universal message gateway for all kinds of
  aeronautical data

5
AIDA-NG Open System Architecture
6
AIDA-NG Open System Architecture Standard
Solution
7
AIDA-NG Redundant Databases
8
AIDA-NG - What we avoid Shared Storage Devices
Server Cluster
single point of failure
Single Database Volume
shared RAID Storage Device

• Conventional Cluster Solutions typically use
  "shared" components, e.g. Application Software,
  Data Volumes, and Storage Devices.

9
AIDA-NG - What we avoid Database Replication
Standby Server
Operational Server
Database Operation
Database Replication
Corrupted Database Volume
Corrupted Database Volume
single point of failure

• A single database volume is in operation, which
  is replicated to the standby server
• Corrupted Volume is replicated ? Outage of the
  system ? Loss of service

10
AIDA-NG Serial Interfaces - RCC Group

• SNL-A, SNL-B
• intelligent communications controller with two
  serial V.24/V.11 interfaces
• Fast Ethernet server connection
• real-time operating system (downloadable)
• HDCL/LAB-B and ASYNC protocol drivers
  (downloadable)
• Units hot-pluggable
• "online" re-configurable

11
AIDA-NG Serial Interfaces - RCS
Maximum Configuration Up to 130 redundant serial
interfaces (Optional Up to 200 redundant serial
interfaces)
12
AIDA-NG Integrated ATSMHS
AIDA-NG is powered by ECG Core Software
COMSOFT is official ECG supplier to EUROCONTROL
13
ECG Core Software - History
EATM Communications Gateway
ECG
EATM European Air Traffic Management EUROCONTROLs
Performance Enhancement Programme for the
European ATM
14
ECG Core Software Realisation
ICAO Standards (AFTN, ATN)
COTSPlatform
Interoperability
qualified by
ECG URD
Definition

Available to all member states
ECG Core Software
Connectivity
Extensibility
eight EUROCONTROL Member States
Scalability
Portability
URD User Requirements Document
15
ECG Core Software - Key Requirements

• Integrated on COTS Platform(standard
  server-based architecture)
• Universal Connectivity (AFTN, AMHS, transparent
  gateway)
• Deployable in every ATS Environment (small(est),
  medium, big, obsolete, or advanced
  infrastructure)
• Maximum Support of the AMHS Migration("online",
  without stopping the service)

16
Long-Term Mixed Operation of AFTN and AMHS
17
Not Suitable - Fragmented System Solution
18
The Solution

• Integrated System

19
AIDA-NG Integrated Communications Gateway
Directory Service

• Unified System Management

• Harmonised Message Handling

ATN Router

• 100 Integration of AFTN and AMHS in one System
• Gateway Function for all kind of messages
• Harmonised Message Handling
• Unified System Management

20
AIDA-NG Strong Point Horizontal/Vertical
Integration
21
AIDA-NG Strong Point - Interfaces and Protocol
Stacks

• Interfaces and protocol stacks
• Up to 130 (200) serial redundant V.24/V.11
  interfaces
• AFTN/ASYNC (direct, leased lines)
• AFTN/X.25 (PVC/SVC)
• CIDIN/X.25 (PVC/SVC)
• X.400 P1 and P3/CLNP/TP4/X.25
• X.400 P1 and P3/TP0/X.25
• Up to ten Ethernet LAN 10/100/1000 Interfaces
• X.400 P1/ATN
• X.400 P1 and P3/RFC1006/TCP/IP
• AFTN/TCP/IP
• AFTN/SMTP (E-Mail-Gateway)
• AFTN/FAX
• (L)DAP

22
AIDA-NG Strong Point OSI and IP-based MTA
Connections

• Fully integrated OSI and IP connectivity
• OSI and IP-based MTA connections can be handled
  fully in parallel
• System is dedicated as boundary system between
  ICAO Regions

23
Strong Point - Common Message Database
24
Strong Point AFTN to AMHS Transition Support
Alternate Routing of AMHS messages via AFTN links
25
Strong Point - AFTN to AMHS Transition Support
26
AIDA-NG Advanced System Control and Supervision
27
Central Supervision Integrated in AIDA-NG

• AIDA-NG can be configured to permanently
  supervise allSNMP-capable devices
• AIDA-NGs event reporting system is used to
  inform the centre staff
• E-mail, SMS, Pager alarming supported

28
Central Supervision COMSOFT Network Management
System (CNMS)
29
CNMS Central Supervision of Components - Servers
30
CNMS - Supervision of Applications - Software
31
AIDA-NG Performance Values

• Reliability
• Maintainability
• Robustness
• Throughput

32
Server-Based Platform

• Integrated on Intel processor-based servers and
  workstations of various vendors (IBM, HP, DELL,
  etc.)
• RED HAT Linux Fedora Operating System
• Fast real-time database of any capacity
• X-Windows and Java-based GUIs

33
Throughput Figures Example
Scenario Source European Customer 2007, Peak
Load Measurement
34
AIDA-NG System Availability (December, 2008)
Field-proven system availability gt
35
AIDA-NG System MaintainabilityCentral
Boot/Configuration/Software Server
36
AIDA-NG Strong Point Hardware Maintenance

• Integration of a spare server
• Configure spare server via basic installation CD
  (approx. five minutes)
• Integrate spare server
• Reboot spare server
• No interruption of service during exchange of the
  server
• Installation of software, configuration,
  databases, etc. is not required

37
AIDA-NG Strong Point - Software Maintenance
38
AIDA-NG Strong Point - Dual Site Handling
BCS
Databases
Operational System Site A
Software VersionsConfiguration Data
Traffic Data,Statistics, etc.
LAN/WAN
BCS
FallbackDatabases
Contingency System Site B
BCS Boot/Configuration/Software Server
39
AIDA-NG Strong Point AMC Import
Directory Import
40
Strong Point - Message Congestion Handling

• System can hold more than 250,000 pending
  messages (AFTN/AMHS) in transmission queues
• Switching Performance and System Access is not
  degraded under this load
• System is fully protected against overload by
  flow control mechanisms

Manual Contingency Procedures on message level
(e.g. a message drain function) are not required
41
Strong Point - Unrivalled Benefits for Users

• Redundancy without any single point of failure
• Complete System Switchover in lt 5 sec
• Fully integrated and tuned X.400 COTS product
  (redundancy, stability, throughput, extended
  queue handling, diagnostics, etc. )
• Unified System Management (AMHS, AFTN, legacy
  part, X.400, etc.)
• 100 protection against overflow situations
• Unmatched high message throughput
• Dual Site Operation/Contingency Management

42
CADAS
CADAS COMSOFT Aeronautical Data Access
System COMSOFTs advanced client/server-based
ATS Terminal System
43
CADAS Client/Server Terminal System with
ATS/AFTN or ATS/AMHS UA Client Terminals
44
Strong Point - CADAS Load Balancing
User Agents are equally distributed over the
servers (load balancing)
HTTP
CADAS Server 2
CADAS Server 1
45
Strong Point - Client/Server System Database
Access
CADAS Client Terminals
CADAS Client Terminals
CADAS Client Terminals
IP Network (LAN,WAN) WWW
Central Database Access
CADAS Servers 1,2
ANSP Centre
46
Strong Point - Client/Server System Software
Maintenance
CADAS Client Terminals
CADAS Client Terminals
Deployment of Software
CADAS Client Terminals
IP Network (LAN,WAN) WWW
ANSP Centre
CADAS Servers 1,2
Software Update
47
CADAS ATS Client Terminals (AFTN or AMHS)

• Platform-independent Java Application
• "Online" monitoring of incoming messages (AMHS or
  AFTN)
• Syntactic/semantic checking of received messages
  with type detection (FPL, NOTAM...)
• Template-specific view of received messages
• Automatic printout of incoming/transmitted
  messages
• Templates for all kinds of ATS messages(FPL
  associated, etc.) with online checking mechanisms
• Highly sophisticated message retrieval function
  with a multitude of filter criteria
• Support by central static databases (aircraft
  types, flight routes, FIRs, aerodromes, etc.)

48
Strong Point CADAS ATS Client Terminal
Integrated AMHS Functionality

• Fully integrated AMHS User Agent
• Practically invisible to the end user

Attachment
Access to local andX.500-based address books
Display/hide AMHS Attributes
49
Services - How you get it

• COMSOFT delivers "turnkey" solutions

50
Services "Turnkey" Solution Example
51
Services Support During all Project Life Cycle
Phases

• Design
• Production
• Commissioning
• Long-Term System Support

52
The Goal Satisfied Customers

• Peter,
• See note from Kevin confirming that the
  transition onto AMS-UK is now complete. I like
  to add my thanks to everyone at Comsoft for your
  support in achieving this important milestone.
• The whole transition has gone very smoothly and
  the delay in transitioning the last Xx
  connections was due to a problem with the Xx
  system and NOT AMS-UK.
• Could you please forward this on to all
  interested parties at Comsoft.
• Regards,
• Malcolm.
• Gents,
• I believe all of you are aware that following an
  extremely successful transition of almost all of
  the users by the 1st week in September, we were
  stuck with problems with Xx connections.
  Following another set of testing, we have
  subsequently been able to transition them to
  AMS-UK today and I can thus declare that the user
  transition is complete. Although this is a week
  later than I had planned, in comparison to
  previous transitions of this magnitude, I cannot
  emphasise enough how well this has gone and would
  not have been achieved without a magnificent team
  effort and I take my hat off to them.
• Regards, Kevin

53
COMSOFT Customer Base

• Our Success

54
COMSOFT Experience in AFTN/AMHS

• 1994 AFTN/CIDIN Product Line
• 1998 first activities to develop and integrate
  AMHS/ATN-related products
• 2003 Delivery of the ECG core software package
  to EUROCONTROL
• 2004 2008 Delivery of 36 AMHS/CIDIN/AFTN
  systems to 20 customers in all ICAO regionsThe
  ANDRA/ECG system delivered to German Air
  Traffic Control (DFS) operates the first
  international AMHS connection in Europe between
  Germany and Spain (AENA)
• 1994 today Participation in AFTN/CIDIN/AMHS
  Working Groups/ Meetings of ICAO, EUROCONTROL,
  FAA, etc.

55
Customer Base - MHS References/Projects in Europe
NATS, UK Locations Heathrow and Gatwick 2
redundant AMHS/CDIN/AFTN systems 1 redundant
AMHS/CDIN/AFTN test system
DFS, Germany Locations Frankfurt and Langen 3
redundant AMHS/CDIN/AFTN systems first
international AMHS connection in Europe (to
Spain)
EUROCONTROL Location Brussels ECG Core Software
Package EUROCONTROL AMHS Reference System
LPS, Slovakia Location Bratislava 1 redundant
operational AMHS/CIDIN/ AFTN systems 1 single
contingency AMHS/CIDIN/AFTN system 1 redundant
disaster recovery AMHS/ CIDIN/AFTN system 1
single contingency AMHS/AFTN/CIDIN/ system
EUROCONTROL, CFMU Locations Brussels and
Paris 4 redundant AMHS/CDIN/AFTN systems
Belgocontrol, Belgium Location Brussels 1
redundant operational AMHS/CIDIN/AFTN system 1
redundant contingency AMHS/CIDIN/AFTN system 1
redundant test/training AMHS/CIDIN/AFTN system 45
CADAS AMHS UA/AFTN User Terminals
BHDCA, Bosnia and Herzegovina Location Sarajevo
and Banja Luka 2 redundant AFTN switches
EUROCONTROL Location Maastricht UAC 1 redundant
AFTN/CIDIN Switch
SMATSA, Serbia and Montenegro Location
Belgrade 1 redundant AFTN switch
LVNL, the Netherlands Location Amsterdam 1
redundant AMHS/AFTN/CIDIN switch 1 redundant
test/development system
MCAA, Macedonia Location Skopje and Ohrid 1
redundant AMHS/AFTN system
DSNA (Project MESANGE), France Location
Bordeaux and 10 remote sites 1 redundant
operational AMHS/CIDIN/AFTN system 1 redundant
contingency AMHS/CIDIN/AFTN system 1 redundant
test/training AMHS/CIDIN/AFTN system 1 redundant
AMHS/CIDIN/AFTN development system 16
concentrators installed on 10 remote sites up to
150 CADAS AMHS UA/AFTN User Terminals
skyguide (Project MESANGE), Switzerland Location
Geneva 1 redundant operational AMHS/CIDIN/AFTN
system 1 single contingency AMHS/CIDIN/AFTN
system 1 redundant test/training AMHS/CIDIN/AFTN
system up to 40 CADAS AMHS UA/AFTN User Terminals
56
Customer Base - MHS References/Projects in Middle
East Africa
CAA, Zambia Location Lusaka 1 redundant AFTN
switch
CAA, Libya Location Tripolis, Bengasi, Sirt,
Sheba,Metiga 1 redundant AMHS/CIDIN/AFTN/AIM
system 40 CADAS AFTN/AIM User Terminals
CAA, Zimbabwe Location Harare 1 redundant
AMHS/CIDIN/AFTN/AIM Switch 18 CADAS AMHS
UA/AFTN/AIM User Terminals
NANSC, Egypt Location Cairo 1 redundant
AMHS/CIDIN/AFTN system Up to 200 CADAS AMHS
UA/AFTN Terminals
ONDA, Morocco Location Casablanca 1 redundant
operational AMHS/CIDIN/AFTN system 1
AMHS/CIDIN/AFTN Test/Development System 5 CADAS
AMHS UA/AFTN User Terminals
GCAA, Abu Dhabi Location Abu Dhabi, UAE 2
redundant AMHS/CIDIN/AFTN systems 20 CADAS AMHS
UA/AFTN User Terminals
DGCAM, Oman Location Muskat 1 redundant
AMHS/AFTN/AIM system up to 25 CADAS AMHS UA/AFTN
User Terminals
DCA, Dubai Location Dubai, UAE 1 redundant AFTN
switch
GACA, Saudi Arabia Location Jeddah and Riyadh 1
redundant AMHS/CIDIN/AFTN System 1 single
AMHS/CIDIN/AFTN Backup System Up to 60 local
CADAS AMHS UA/AFTN Terminals
QCAA, Oatar Location Doha 1 redundant
AMHS/AFTN/AIM System 1 redundant AMHS/AFTN/AIM
Test System up to 60 CADAS AMHS UA/AFTN Terminals
57
Customer Base - MHS References/Projects in the
Asia Pacific Region
HKCAD, China Location Hong Kong 2 redundant
AMHS/AFTN systems up to 150 CADAS AMHS UA/AFTN
User Terminals
PCAA, Pakistan Location Karachi 1 redundant
AMHS/AFTN/AIM System up to 46 CADAS AMHS UA User
Terminals
AAI, India Location New Delhi 1 redundant
AMHS/AFTN system 25 CADAS AMHS UA User Terminals
CAAM, Macau Location Macau 1 redundant
AMHS/AFTN system 14 CADAS AMHS UA User Terminals
ATO, Philippines Location Manila 1 redundant
AMHS/AFTN/ system 40 CADAS AMHS UA/AFTN Terminals
CAAS, Singapore Location Singapore 1/1
redundant/single AMHS/AFTN systems 12 CADAS AMHS
UA/AFTN User Terminals
APII, Indonesia Location Palembang 1 redundant
AFTN switch 10 CADAS AFTN User Terminals
ASA, Australia Location Brisbane, Melbourne 2
redundant AMHS/AFTN systems 1 redundant
test/development system up to 60 CADAS AMHS
UA/AFTN User Terminals
VATM, Vietnam Location Ho Chi Min City 4
redundant AIM Systems (1main 3 sub sites) 72
CADAS AIM User Terminals
58
Customer Base References/Projects in South
America
CORPAC, Peru Location Lima and 31 domestic local
and remote sites 1 redundant AFTN/AMHS system
with AIM extension 86 CADAS AMHS UA/AIM User
Terminals
59
AIDA-NG Reference Systems

• EUROCONTROL ANg1AFTN/CIDIN/SITA/AMHS Systems
  forCentral Flow Management Unit (CFMU)
• DFS ANDRA/ECGAFTN/CIDIN/AMHS Systems for the
  international COM Centre of the German ANSP

60
Reference System CFMU Dual Site Handling
Migration to AMHS from 2007 onwards
61
Reference System DFS First AMHS Link in Europe
First AMHS Link in the EUR/NAT Region between
Germany and Spain operational since January
19th,2006
62
More Information about COMSOFT
www.comsoft.de www.comsoft.aero www.ecg.aero
63
(No Transcript)
