Categorical Data

1
Categorical Data
2
Overview
3
Outline
4
Population Proportion

• Let p denote the proportion of entities in a
  population with a specified property. Tests
  concerning p will be based on a random sample of
  size n from the population. Provided n is small
  relative to the population the number of
  successes, those with the property of interest,
  has an approximately binomial distribution.
• If n is large then estimator for p, X/n, is
  approximately normally distributed.

5
Test Procedure
Test procedure valid provided np010 and
n(1-p0)10
6
Binomial Experiment

• The test presented is a basic binomial experiment
  where each trial has one of two possible outcomes.

7
Multinomial Experiment

• Generalizing from the binomial experiment, we
  wish to think of cases in which there are k
  possible outcomes, kgt2.

8
Example

• A store accepts three different types of credit
  cards. We observe the next n customers paying by
  credit card. Our null hypothesis will specify
  the expected proportion of each type credit card
  used. The test procedure must then evaluate
  whether the observed proportion is different from
  the expected values.

9
Example (cont.)
10
Example (cont.)
11
Test Procedure

• We will look at the discrepancy between the
  observed and the expected frequencies with H0
  being rejected if the discrepancy is sufficiently
  large.
• Clearly, we will use (observed-expected)2 as our
  measure of discrepancy.

12
Theorem

• Provided npi5, ?i,
• has approximately chi-squared distribution with
  k-1 df.

13
Test Procedure
14
Example

• Allied Health Corporation owns and operates
  hospitals in the northeast. Three properties
  were audited recently to establish compliance
  with Medicare billing regulations. A random
  sample of audited billings revealed the following
  number from each hospital H1-485, H2-405, H3-310
  for a total of 1200 billings. The auditors claim
  each billing had a equal probability of being
  from each hospital. What can you conclude about
  the auditors selection at the .01 level?

15
Solution (1)

• Let pi be the proportion of audited billings from
  each hospital (1, 2, 3). If an audited billing
  is equally likely from each hospital then pi1/3
  ?i1, 2, 3, so
• H0 p11/3, p21/3, p31/3
• Ha at least one proportion is incorrect
• a.01
• Reject H0 if c2gt c2.01, 29.21
• (using CHIINV(0.01,2))

16
Solution (2)
17
Solution (3)

• chisquaregtchisquare(.01,2) so we reject the null
  hypothesis, hence on the the proportions must be
  different from 1/3. Looking at the proportions,
  hospital 1 is 485/1200 .404, hospital 2 is
  405/1200.338 and hospital 3 is 310/1200.258.
  This shows us hospital 1 is over-represented
  while hospital 3 is under-represented.

18
Example

• MetroCodex, suppliers of accounting middleware
  for hospitals, has undertaken an employee survey
  to ascertain employee perspectives on how
  management responds employee suggestions.

19

• A management consultant predicts the outcomes as

20

• The following data were obtained from the
  employee survey

21
Question?

• Does the data conform to the consultants
  expectations (a.05)?

22
Solution

• Worksheet Metro in Workbook

23
Example

• We have 200 software modules as part of a large
  development project. We will conduct code
  inspections on all modules. For 100 of the
  modules we will use technique A which is tool
  driven while for the other 100 modules we will
  use technique B which is manual. An inspection is
  considered successful if it detects 85 of the
  known errors in the module. The success rate for
  inspections is 70.

24
Hypothesis

• H0 tool has no effect, the number of successful
  inspections would be the same with and without
  the use of the tool
• H1 tool has effect

25
Data
26
Analysis

• c2 2.38
• k2 (two group, tool and no tool)
• vk-12-11 (degrees of freedom)
• a .05
• c2 .05, 1 3.84
• Since c2 2.38 is not greater than c2 .05, 1
  3.84, we cannot reject the null hypothesis.

27
Problem

• A particular real-time system is defined as a
  collection of three redundant processors. During
  startup the three systems, independently, have a
  probability of failure of 1/6. QA has conducted
  1000 tests of the system during startup,
  resulting in the following
• Processors Failing Frequency
• 0                 600
  1                 330
  2                  60
  3                  10
• Determine if the system behavior is consistent
  with expectations.

28
Solution
29
Two-way Contingency Tables (1)

• There are I populations of interest, each
  corresponding to a different row in the table,
  and each population is divided into the same J
  categories.
• Test for Homogenity - the proportion of
  individuals in a category is the same for each
  population and that is true for every category.

30
Two-way Contingency Tables (2)

• There is single population of interest, with each
  individual in the population categorized with
  respect to two different factors.
• Tests for Independence - the individuals
  placement in a factor is independent of the other
  factor.

31
Data Representation
32
Homogenity Test Procedure
33
Estimate

• Homogenity test can be applied as long as each
  estimate5.

34
Example

• A company packages a particular product in three
  different sizes, each size produced on a
  different production line. Most can pass
  inspection but QA has identified five categories
  of nonconformance. A sample of nonconforming
  units is selected resulting in the following data
  table

35
Data
36
Solution

• Production in workbook
• Note homogenity uses higher values of a for
  hypothesis testing.

37
Independence Test Procedure
38
Goodness-of-Fit

• The chi-square test is used to test if a sample
  of data came from a population with a specific
  distribution.
• For the chi-square goodness-of-fit computation,
  the data are divided into k bins and the test
  statistic is defined as

39

• The chi-square test is an alternative to the
  Anderson-Darling and Kolmogorov-Smirnov
  goodness-of-fit tests. The chi-square
  goodness-of-fit test can be applied to discrete
  distributions such as the binomial and the
  Poisson. The Kolmogorov-Smirnov and
  Anderson-Darling tests are restricted to
  continuous distributions.

http//www.itl.nist.gov/div898/handbook/eda/sectio
n3/eda35f.htm
