Title: Cluster Administration Tool


1
Jaeyoung Choi
Jiyeon Kim, Yongkwan Park, Sungjoo Kwon, Jaeyoung
Choi
choi_at_comp.ssu.ac.kr
heaven, psiver, lithmmon_at_ss.ssu.ac.kr,
choi_at_comp.ssu.ac.kr
School of Computing, Soongsil University 1-1,
Sangdo-Dong, Dongjak-Ku Seoul 156-743, Korea
School of Computing, Soongsil University 1-1,
Sangdo-Dong, Dongjak-Ku Seoul 156-743, Korea
2
Motivation
  • Linux Cluster System widely used for high
    performance computing
  • It emphasizes on the use of commodity hardware
    and open source software
  • It delivers a very high-performance at the
    extremely low cost
  • System management is a challenging task
  • Automatic and convenient installation of OS
    application software packages
  • The effective way to navigate and interact with
    cluster component
  • Mechanism and tools to perform collective
    commands
  • Some services such as monitoring, fault detection
    and recovery

3
What is CATS-i ?
  • Cluster Administration ToolS on the Internet
  • A collection of system management tools
  • Provides automatic and convenient installation of
    OS application software packages
  • Provides efficient monitoring and management of
    cluster nodes with simple operation on the
    Internet.
  • Provides easy-to-use GUI of PBS.
  • Easy-to-install CATS-i rpm package

4
CATS-i System Architecture
  • Client Daemon
  • Get system information from local OS on each node
  • Server Daemon
  • Running on server node to collect information
    from client daemon
  • Setup tool
  • Implemented with JAVA
  • Management tool
  • Implemented with JAVA
  • Support internet

5
Difference with CATS-i
  • NodeCloner
  • CACR at CalTech
  • to make all nodes identical
  • using the Bootp and NFS
  • not provide a GUI
  • must edit the setup files related to NodeCloner
  • Beoboot
  • Rembo Technology SaRL, Swizerland
  • Boot-ROM booting
  • using DHCP
  • using batch file interpreter
  • defect make the batch file, difficult interface

6
Difference with CATS-i
  • LUI(Linux Utility for cluster Installation)
  • IBM
  • Support BOOTP protocol and using DHCP and PXE.
  • GUI Interface
  • Heterogeneous cluster
  • Must define the resource object
  • Using TFTP
  • As the number of nodes is increased, I/O road is
    increased.

7
Installation using the IP Multicasting
  • It provides same speed of installation and reduce
    I/O load
  • Automatically, multicast a client module through
    NFS
  • Sever sends slave node disk image through the D
    class IP address
  • To make up for the unreliability of UDP
  • timeout and retransmission

8
Setup tools with IP multicasting
Master node
GUI
Node DB
Network Configuration info
Error/Flow Control
Multicast Server Module
UDP
D class IP (224.0.0.0 239.255.255.255)
UDP
Node N
Node 1
Node 2
Node 3

9
Setup tool in the CATS-i
  • Disk Cloning using the NFS
  • A slave node must be boot with DHCP and NFS
    enabled kernel
  • It has a same way to boot as the diskless
    terminal
  • using DHCP
  • It makes a disk image of a slave node include
    hard disk info
  • store slave node disk image in the server disk

10
OS Setup tools Architecture - Disk cloning
  • Disk cloning preparation
  • Step 1, 2, 3
  • Command operation
  • Step 4, 5, 6, 7, 8
  • Make disk image
  • Step 9, 10, 11, 12, 13
  • Save disk image
  • Step 14, 15

11
OS Setup tools Architecture - Installation
  • Installation preparation
  • Step 1, 2, 3
  • Command operation
  • Step 4, 5, 6, 7, 8, 9
  • Installation
  • Step 10, 11, 12, 13, 14

12
OS Setup tools

Slave Node
Master Node
13
Related works for CMS -VACM
  • VA Linux Systems
  • Cluster administration tool runs on VA-Linux
  • Real-time hardware sensor data such as
    temperature, fan speed and voltage are reported

14
Related works for CMS - MAT
  • Ryerson University, Canada
  • It is implemented with Tcl/Tk
  • It causes a lot of overhead to display rapidly
    changing data
  • Individual management about each node
  • monitor about system file mainly

15
Related works for CMS - SCMS
  • Kasetsart University
  • It consists of real-time monitoring system,
    parallel unix command and numerous system
    administration utilities
  • It supports java applet to report real-time
    system information
  • It supports 3D interface using VRML

16
Related works for CMS M3C
  • Oak Ridge National Lab
  • It is implemented with java.User can manage
    multiple cluster group in one interface
  • It supports job scheduling and software
    installation

17
Management tools in the CATS-i
  • Management tool offers maintenance of cluster
    nodes.
  • Characteristics of management tool
  • It is possible to bind many node as one cluster
    group, and manage multiple cluster groups in one
    place.
  • It is possible to apply the same operation
    efficiently to all or selected nodes.
  • It offers real-time monitoring to users for
    resource information such as CPU, memory and etc.
  • Console implemented with java is interactive and
    easy to use.
  • Job scheduling using JPBS through Internet
  • CATS-i offers many function about resource.

18
CATS-i function
  • Node status
  • CPU, memory, process, user list, account
  • Disk space
  • File management
  • Alarm
  • System log
  • Shutdown/Reboot
  • Package management
  • JPBS

19
Management tools Node status
  • It shows node information for each group
  • Real-time information about CPU and memory

total view
20
Management tools Node status
  • It enable user to monitor resource information of
    cluster nodes such as CPU, memory, account, user,
    real-time CPU and memory monitoring, process
    monitoring, and managing

basic info
Performance
21
process
Disk
Account
User List
22
Management tools file management
  • It provides file management functions for a
    cluster group.

File Management
  • It is very easy to use
  • When they want to perform jobs related with
    files, users just click the right button to show
    a pop-up menu.

23
Management tools alarm function
  • Monitor import system parameters
  • Processor utilization, Memory Usage, etc.
  • Notification is done through e-mail of system
    functions.

24
Management tools system log
  • Log information is very useful in various
    situation
  • Server daemon collects log information from each
    node

Log Tree
25
Management tools RPM package
  • User can install, remove, upgrade application
    packages with management tool and query about
    installed RPM
  • Support REDHAT Linux
  • It is implemented with thread library

Option Dialog
26
Management tools PBS Interface
  • It enables users to user a general PBS with the
    same CATS-i interface.

JPBS job Submission Dialog
main screen
27
Conclusion Future works
  • CATS-i will offer more functions such as
  • Status of CPU temperature, voltage and speed
  • Extended aggregation of services
  • Statistical memory and CPU information for each
    user
  • Statistical information can be displayed
    graphically
  • Network monitoring using SNMP and network
    analysis
  • detect network bottleneck of clusters.
  • Enhanced alarm services
  • Administrator can can specify the condition to
    alarm and action to be taken
  • In emergence, CATS-i can shutdown or reboot
    cluster nodes
