CS394 Strategic Program Planning

1
CS394 Strategic Program Planning

• Conduct 7 IT Architecture

May 13, 2002
2
ArchitectureGoals for Today

• What is Architecture?
• Why Do It?
• To Be presentations

3
Agenda
IT Architectures Middleware 60-75
minutes Break Two Presentations Next Steps
4
Agenda

• IT Architectures Middleware
• What Is It and Why?
• Process
• Organizational Types
• Personality Profile Are you an Architect?
• Break
• Two Presentations
• Next Steps

5
The A-word is pretty flexible

• Architecture as someone elses problem
• Architecture as an engineering discipline
• Architecture as a sellable product
• Architecture as a fine art
• Architecture as a religion

6
IT Architecture Lofty DefinitionWhat is
Architecture?
Architecture is that great living creative
spirit which from generation to generation,
from age to age, proceeds, persists, creates,
according to the nature of man, and his
circumstances as they change. That is
architecture.
- Frank Lloyd Wright, 1937
7
IT Architecture Pragmatic DefinitionWhat is
Architecture?
Architecture is about making the link between
business problems and IT Solutions. It is about
turning a functional design into an
implementation design, deciding how to divide the
functionality across programs, choosing the best
middleware technology, and defining the
requirements for supporting infrastructure -
Chris Britton, 2001
8
IT Architecture Pragmatic DefinitionWhat is
that picture?
9
IT Architecture Pragmatic DefinitionArchitectu
re is over-used and has many dimensions

• Narrow focus to wide focus
• Consider a single project to considering all
  projects in an enterprise
• Specific versus generic
• One (specific) to many (generic)
• Look for points in common
• Detailed versus high-level
• High-level guidelines Detailed design
  specifications
• Not always the same as enterprise-wide you can
  have a detailed enterprise-wide network diagram

10
IT Architecture Pragmatic ObjectivesBottom
Line the practice of Architecture saves money

• Reduce Total Cost of Ownership
• Teams buy great tools, without cross platform,
  cross-department sharing
• Building tactically means tools are not leveraged
  with proprietary results
• Delivery On Time Within Budget
• Every project is a maiden voyage
• Estimating models never developed
• Software reuse will reduce development time
• Infrastructure reuse will reduces deployment time
• Common Skills and Alignment
• Enterprise development standards
• A limited set of platforms and a standard set of
  cross platform tools

11
IT Architecture Pragmatic Objectives by
Focusing on Implementation Design, or Solutions

• The architect guides the implementation design
• Enforce generic principles and patterns
• ACROSS multiple projects

12
IT Architecture ChallengesPolitical
Environment, Participation, and Skills

• Participate in the development process
• Dont bolt-on - organizational changes are
  inevitably needed
• Identify the political environment you are in
• Shelfware
• What makes an Architect?
• Not skills, its a personality type

13
Agenda

• IT Architectures Middleware
• What Is It and Why?
• Process
• Organizational Types
• Personality Profile Are you an Architect?
• Break
• Two Presentations
• Next Steps

14
IT Architecture ProcessFirst Steps Build the
Roadmap, Build the team

• The Technology Roadmap
• Iterative Approach - deliver value quickly
• Strategic Intent and Technology Principles first
• Leverage previous efforts to the optimal extent,
  validate and extend
• Critical to Enforcement is the Solutions Team
• Architecture Standards helps teams balance
  business needs with constraints/advantages of the
  technology environment
• Project funding decisions cannot be made without
  considering the effect on the enterprise
  architecture
• What Teams?

15
IT Architecture ProcessHow does architecture
fit into the overall IT scheme?
Program Management Office
Development Services
Technology Delivery
Planning andTechnology
Client Management
Technology Operations
IT Asset Management Services

• The core process flow begins with Client
  Management flowing through to Technology Delivery
  of a new system or a maintenance release of an
  existing system
• Project Management Office, Technology Operations
  and IT Asset Management Services are supporting
  functions
• The PMO supports the execution of the portfolio
  of projects, ensuring alignment of new
  initiatives with the transformation program,
  providing reporting and tracking services to
  management, and driving consistency in IT
  practices
• The Technology Operations supports the production
  environments, along with the development and
  testing environments within the Development
  Services area
• IT Asset Management Services provides the support
  for assets, contracts, vendors, and cost
  accounting

16
IT Architecture ProcessHow does architecture
fit into the overall IT scheme?

• Planning and Technology is a discrete function
  performed by specialists, because this crucial
  activity has less chance of being compromised by
  operational needs
• Planning and Technology is responsible for four
  functions
• To ensure business alignment, it sets the overall
  strategy which guides all IT activities
• On a project by project basis, it formalizes the
  scoping requirements (fed via the Client
  Management team) and engineers a solution.
  Planning and technology ensures quality assurance
  is planned into every solutions design and
  implementation processes.
• Establishing and maintaining IT architectural and
  software engineering standards and practices
• Provides a means for directed Research
  Development of future technology

17
IT Architecture ProcessHow does architecture
fit into the overall IT scheme?

• Planning and Technology consists of the following
  components
• Strategy and Planning In response to overall
  business goals as well as goals set by individual
  lines of business, Strategy and Planning is
  responsible for setting and maintaining the IT
  Strategy for the enterprise. Strategy and
  Planning, Business Unit IT leadership and PMO
  work together to define and submit the annual
  budget targets to the business leadership using
  the IT strategy as the key input document.
• Solutions The solutions process takes scoping
  requirements for new initiatives submitted
  through the client management group, formalizes
  them, and develops solutions to fulfill the
  requirements leveraging knowledge of the current
  capabilities of relevant systems, other projects
  in the pipeline, costs, and benefits. The group
  consists of experts in software engineering,
  insurance, and the current processing environment.

18
IT Architecture ProcessHow does architecture
fit into the overall IT scheme?

• Technical Architecture since this group works
  closely with Solutions and Planning processes it
  is beneficial to wire this function directly
  into the overall Planning and Technology
  function. Responsibilities of this group
  include
• Develop and maintain an overall technology
  framework which defines basic technologies and
  systems to be deployed
• Develop and maintain an overall enterprise
  architecture plan defining the component
  standards for each major sub-system (platform,
  operating system, database, etc.)
• Evaluate specific vendors and products for
  inclusion into the enterprise architecture
• Develop and maintain a physical site management
  plan for the central site, administration areas
  and remote facilities
• Evaluate and select systems and management tools
  for each component of the enterprise
  architecture, e.g., data warehouse toolset and
  enterprise application integration
• Map technology strategy back to Service Level
  Agreement and Operating Level Agreement1
  objectives

1An operating level agreement is an agreement
between two parties one level or more removed
from the end-user e.g., Technology Operations
may have an operating level agreement with ATT
to provision a frame relay connection in x days.
19
IT Architecture ProcessHow does architecture
fit into the overall IT scheme?

• Technical Architecture (continued)
• Develop and maintain an overall plan to acquire
  the necessary skills needed to support each
  component of the distributed environment
• Map technical training requirements back to
  Service Level Agreement and Operating Level
  Agreement objectives and lay out a high level
  training plan to guide the Service Level
  Management area
• Develop an overall strategy for training service
  delivery personnel
• Develop technical curriculum and procedures for
  monitoring the completion of training
• Technology Research The purpose of this
  function, which may or may not be staffed full
  time, is to identify new technologies that have
  the potential to deliver significant business
  value. This group, in coordination with Client
  Management leadership, would pilot new
  technologies to prove business value and
  reliability. The group also helps to keep
  Technical Architecture and Solutions current.

20
IT Architecture ProcessKey Interfaces
Development Services
Program Management Office
Development Services
Technology Delivery
Planning andTechnology
Client Management
Technology Operations
IT Asset Management Services
Development Services
Development Center oExcellence
ProductionCenter oExcellence
Production Design and Testing
21
IT Architecture ProcessKey Interfaces
Production Design and Testing
Development Services
Development Center oExcellence
ProductionCenter oExcellence
Production Design and Testing
22
IT Architecture ProcessKey Interfaces
Technology Delivery
23
IT Architecture ProcessKey Interfaces
Technology Operations
24
IT Architecture ProcessKey Interfaces IT
Asset Management Services
25
Agenda

• IT Architectures Middleware
• What Is It and Why?
• Process
• Organizational Types
• Personality Profile Are you an Architect?
• Break
• Two Presentations
• Next Steps

26
IT Architecture Organizational Types High
LevelMonarchy, Federated, Autonomous
Collective ?

• Monarchies
• Strong Central Control, one of everything
• Architecture Strategy is very specific (Small
  list of vendors)
• Federal
• Departmental development groups
• Architecture Strategy is higher level (Free to
  choose Java vs. Microsoft),
• Usually one Architecture group for the entire
  enterprise
• Distributed, aka Autonomous Collective aka
  Chaos
• Share a network, and little else
• Architecture Strategy is individualized by
  department, line of business, etc.
• Northwestern

27
IT Architecture Federal ModelIntroduction

• Constitution-driven, decentralized design
• Principles are explicit and based on overall
  business strategy
• Architecture is loosely tied to technology
• Tactical efficiency is traded for overall utility

28
IT Architecture Federal ModelGovernance

• Constitution leaves low-level implementation
  details to end-user groups
• Common infrastructure is closely tied to business
  strategy

29
IT Architecture Federal ModelControl Mechanisms

• Discourages expensive infrastructure for tactical
  applications
• Impetus to centralize management of shared
  resources
• Build the aqueduct, they will use the water for
  something

30
IT Architecture Federal ModelAdvantages

• Dynamic balance between innovation and control
• Minimal IS bureaucracy
• Application investment at the end-user

31
IT Architecture Federal ModelAdvantages

• Centralized technologies, such as Data
  Warehouses, workflow engines, and enterprise
  application integration are treated as enterprise
  entities
• Supports Customer Intimate value discipline

32
IT Architecture Federal ModelImplementation

• Establish Architecture Authority
• Reach constitutional consensus
• Collapse duplicate standards
• Prioritize technology commitments
• Collectivize shared utilities
• Privatize point application

33
IT Architecture Federal ModelDisadvantages

• De-facto standards can be imposed by the market,
  such as J2EE versus COM/DCOM
• Can degenerate into a single-view dictatorship
• Tactical inefficiency can discourage adequate
  investment

34
IT Architecture Federal ModelDisadvantages

• Incorrect interpretation of corporate values can
  lead to wrong design principles
• Consensus building can be slow - impatience or
  the environment can weaken the model

35
Agenda

• IT Architectures Middleware
• What Is It and Why?
• Process
• Organizational Types
• Personality Profile Are you an Architect?
• Break
• Two Presentations
• Next Steps

36
Joining 4 disciplines of the architect to
knowledge
The Artist
The Guru
The Spy
The Coach
37
The Artist Discipline - uses inductive approaches
to solve problems quickly

• Inductive reasoning is a different use of
  neurons dont be afraid
• Not just looking for right answers turning over
  new stones to find treasure

38
The Guru Discipline - uses meticulous data
collection to solve problems precisely

• Understanding some topics in depth, others in
  breadth
• Deductive, provable bottom up methods
• Construction-oriented urges
• Levitation optional, but encouraged

39
The Coaching Discipline is crucial to building
new Architects

• Coordination with the rest of the program
• Finding points of influence within the project
  plan, getting off the critical path
• Teaching is a great motivator for learning
• Leverage means actually using your vacation time

40
The Spy Discipline - learns across many topics
and synthesizes unique viewpoints

• Drawing synthesis from the data
• I know I have seen this problem before
• How does my deep knowledge of Gilligans Island
  help in this situation?
• Understanding the Big Picture
• Turning wide knowledge into understanding
• Knowing how things got this way

41
Agenda
IT Architectures Middleware Break 15
minutes Two Presentations Next Steps
42
Agenda
IT Architectures Middleware Break Two
Presentations 25 minutes X 2 Next Steps
43
Agenda
IT Architectures Middleware Break Two
Presentations Next Steps 45 seconds
44
Conduct 7Four more lectures Quiz next week

• Week 8 (Kiep) - May 20, 2002
• Continue As Is and To Be Presentations 4
  more
• Quiz covering Program Management Architecture
  max. 6 questions
• Week 9 (Kiep) - May 29, 2002 (this is a
  WEDNESDAY!)
• Planning and Implementation Topic Paul Roma
• Week 10 (Abbattista) - June 3, 2002
• Planning and Implementation Topic continued
• Course Wrap-Up
• Early Presentations - optional
• Week 11 (Abbattista) - June 10, 2002
• Planning piece and overall Project Due
• Presentations

45
Conduct 7Quizzes

• Pick up your quizzes at the front of the room
