Enhancing performance - PipeliningChapter 6Part
1 Concepts

• N. Guydosh
• 3/24/04

2
Introduction

• Parallelism built into the processor hardware
• The logical sequence of events in the execution
  of an instruction is generally wasteful of time .

• Example while an instruction is doing arithmetic
  using registers, the memory is idle ... why not
  fetch the next instruction during this time?
• The key idea is to overlap the processing of
  multiple instructions.

3
Introduction An Analogy

• Analogous to an assembly line in a factory
• The time to build an individual car does not
  decrease but the number of cars built per unit
  time is greatly increased .
• Multiple cars are simultaneously built
• While the engine is installed in one car, the
  seats are installed in another ... at the same
  time
• Success of assembly line depends on how well
  balanced it is ... we dont want one task (phase)
  taking 10 minutes, while another takes 1 hour.
  ... The car having the short task done at one
  station will have to wait idle for the next task
  station to free up.
• The series of work stations in an assembly line
  are analogous to the functional units in a
  processor data path
• A series of cars to be built passes though the
  assembly line simultaneously - each work station
  is busy.
• On startup and stopping of the line it take a
  time equal to the sum of the work stations time
  to fill and empty line (pipeline).

4
Introduction Computer Instructions

• In the assembly line example, the car becomes an
  instruction .
• The tasks done on the car become the instruction
  phases (or stages).
• The work stations become the functional units in
  the data path.
• The assembly line becomes the data path
• The data path simultaneously executing multiple
  instructions is called a pipeline

5
Introduction Computer Instructions (cont)

• Pipelining improves instruction throughput rather
  than individual instruction execution time
• The time required to move an instruction one step
  down the pipeline is one clock cycle
• The length of a clock cycle is determined by the
  time required for the slowest pipeline stage
  because all stages must proceed at the same rate

• The goal of the designer is to balance the length
  of each stage - otherwise there will be idle time
  during a stage.

6
Steps to Take

• Decompose the processing of instructions into
  phases
• Simplest decomposition is two phases or stages
  fetch and execute
• 1st stage fetches and buffers the instruction
• 2nd stage (execution) receives the buffered
  instruction from the 1st stage when it is free
• While 2nd stage is executing, the 1st stage takes
  advantage of any unused memory cycles to fetch
  and buffer the next instruction this is called
  instruction pre-fetch or fetch overlap

7
Steps to Take (Cont.)

• Problems with this approach
• Execution time is generally longer than fetch
  time.
• Fetch stage may have to wait before it can empty
  its buffer
• Ideally we would like to have the various stages
  of instruction processing take the same amount of
  time.
• A conditional branch instruction makes the
  address of the next instruction uncertain ...
  thus fetch stage waits until the execute stage
  (branch) determines the next instruction address
• Both above situations results in performance loss
  - the latter (conditional branch) can be reduced
  by guessing at, the outcome of the branch.

8
Steps to Take (Cont.)

• An improvement would be to decompose the
  instruction processing into smaller steps (finer
  granularity)
• There would be less variation in processing time
  among the stages
• These are the familiar phases of our instruction
  executionIF Instruction fetchID
  Instruction decode and register fetchEX
  Execution and effective address calculationMEM
  Memory access (fetch memory operands)WB
  Write back (into register file )
• The various phases (5 of them) will be more
  nearly equal in duration
• Register read and register write takes only 1 ns
  and all the other phases take 2 ns. Thus all the
  phases will take 2 ns - register operations will
  idle for 1 ns during the register phases

9
Steps to Take (Cont.)

• Fundamental conceptIn order to make each phase
  as independent as possible of other phases, we
  will use the single clock cycle data path (fig,
  5.19, p. 360) and a multiple clock cycle timing
  scheme.
• A hybrid of the two schemes in chapter 5.
• The single clock cycle data path has redundant
  hardware which enhances parallelism and phase
  independence.
• ALU and two adders
• But it is functionally the same as the multiple
  clock data path.

10
Single Clock Cycle Datapath for Multi Clock Cycle
Timing
Fig 6.10
11
Performance Example

• Execution of three consecutive lw instructions
  see p. 439
• 2 ns per phase except for reg phase which is 1 ns

12
Performance Example (cont.)

• Ideally with no delays for register operation, it
  would take 8 ns to execute an lw instruction and
  24 ns to do three of them sequentially.
• In a 5 stage pipeline the three could be done in
  14 ns.
• Ideally we would expect to complete an
  instruction every 8/5 1.6 ns for the 5 stage
  pipeline.
• Instead we see 2 ns between instructions
• This is due to an imbalance if the time for each
  phase all phases are 2ns and the register phase
  is 1ns
• Since an instruction is fired off every 2 ns in
  the 5 way pipeline as opposed to every 8 ns in a
  non pipelined scheme, it would seem that the
  performance advantage should be 8/2 4.
• But what we see is 24/14 1.7
• The reason we are not getting the 41 ration is
  that this example never filled the pipe about
  2/3 of time was spent filling and emptying the
  pipe
• Maximum parallelism is achieved only when the
  pipe is filled
• Suppose we increase the number of instructions
  executed by 1000
• Non pipelined 24 1000(8ns/inst) 8024 ns
  Pipelined 14 1000(2ns/inst) 2014
  ns ratio 8024/2014 3.98 ? 8/2 4

13
Principles

• Principle Keep the pipe full and make the phase
  times as equal as possible.
• Sometimes disruptions cause it to empty and
  have to be refilled .... as can happen with
  successful branches

14
Principles (cont.)

• Principle In order for a pipelined scheme to
  work well, the data path stages (functional
  units) must be designed in such a way that
  instructions executing at a particular stage will
  do so independently of instructions
  simultaneously executing on other stages.
• As in an assembly line the instruction should
  flow through the data path from stage to stage
  and not require the services of multiple stages
  independently
• It turns out the single clock cycle data path
  implementation we came up within chapter 5, has
  this property to a large degree.
• fig. 6.10, p. 450 (single-cycle data path) is an
  idealistic abstraction and must be modified to
  make it work well in a pipelined environment.
  Multi-cycle clocking will be added to this single
  cycle datapath.
• Instructions roughly flow from left to right as
  they get executed. ... Instruction 1 could be in
  the ID stage while instruction 2 is in the
  EX stage.
• Two exceptions to the left to right flow(a)
  Write back (WB) stage flows from end of the pipe
  to register file in the middle of the pipe (b)
  The mem stage feeds back to the fetch stage with
  a possible non incremented branch address

15
Making the Pipeline Work

• Pipeline phase buffering
• Pipeline buffer registers between phases - saving
  the data for the next phase, thus make a phase
  immediately reusable by another instruction see
  fig 6.12, p. 452
• There is no pipeline register between WB stage
  and the ID phase (a right to left path). This
  is ok since this is a natural interdependence
  between instructions being executed ... an lw
  places data in the register file and a later
  instruction uses it. All instructions generally
  change the state of the of the machine. ... These
  kinds of instruction interdependence could get
  hairy --- see later

16
Pipelined Datapath Showing Pipeline Registers
Between Phases
Fig. 6.12
17
Preserving Information in the Pipeline

• Data to be stored by sw instructionThe data from
  rt register to be stored in memory is buffered in
  the ID/EX pipeline register but needed in the mem
  stage.
• ... so it is automatically transferred to the
  EX/MEM pipeline register during the EX phase.
  See fig 6.16, p 457 or fig 6.18
• Destination register number (rt) needed by lw
  instruction In the lw instruction the register
  number to write the data into is needed at the
  output of the mem phase (MEM/WB register) ...
  but is first buffered in the IF/ID register ...
  So it is automatically transferred though three
  pipeline registers to the MEM/WB register where
  it is needed. See fig. 6.18, p. 460This move
  is ID/EX ? EX/MEM ? MEM/WB ? register file write
  register specification
• Initially the given datapath did not have this
  path in it (a deliberate bug).
• If we did not make this correction the
  destination register number stored in ID/EX would
  get overwritten by the next instruction coming
  down the pipe and thus would result in an error.

18
Data Path Showing Information Preservation
Pass rt data for sw ?
? Preserve destination register
number for lw
Fig. 6.18
19
Notes For Scenarios Or Walk Thrus Given in the
Text See overhead slides

• Single instruction lw see fig. 6.13 though
  6.15. Assumes correction of fig 6.18
• The target register number (rt) is determined in
  the decode/register fetch stage, but is not used
  until the final stage (write-back).
• Thus the rt number stored in the ID/EX register
  must be moved along with the instruction to the
  MEM/WB register where it is needed
• This move isID/EX ? EX/MEM ? MEM/WB ? register
  file write register specification
• If we didnt do this, the destination register
  number would get wiped out in ID/EX by the next
  instruction coming down the pipe. ... And it
  would be all over but the laughing.
• This is essentially the same reason we put the
  IRWrite control line on the instruction register
  for the multi-clock non-pipelined case in chapter
  5 a copy of certain data from the fetched
  instruction must be maintained throughout the
  execution of the instruction.

20
Notes On Scenarios Or Walk Thrus Given in the
Text (cont.)

• Single instruction sw see fig. 6.16 though 6.17
  Assumes correction of fig 6.18
• First two stages (fetch and decode) identical to
  lw
• Shows need to keep information used in later
  stages of execution of the instruction
• The source data from rt (to be written to memory)
  in the register file is fetched during the
  decode/register fetch stage, but is needed in the
  mem stage for storage on the memory (stored in
  ID/EX register).
• Thus this field is transferred along with the
  instruction from the ID/EX register to the EX/MEM
  register where is now available for writing to
  mem
• This is similar to the situation in lw, but not
  identical.

21
Notes On Scenarios Or Walk Thrus Given in the
Text (cont.)

• Two instructions lw and sub see fig. 6.22
  though 6.24
• Illustrates that each instruction must visit
  each phase even if it does not need any services
  in the phases.
• sub does not need the mem phase, so the ALU
  output is merely passed to the next pipeline
  register (MEM/WB) to await being written to the
  register file

22
Graphical Representation Of Pipelines

• Single clock cycle diagram
• What was used in the scenarios
• Shows state of the entire datapath during a
  single clock cycle
• All instructions in the pipeline identified by
  labels above respective stages
• Requires a sequence of such diagrams to show the
  execution of instruction(s)
• Example figs. 6.22 - 6.24 ... walk thru of a
  two instructions lw and sub
• Multiple-clock-cycle pipeline diagram
• Gives a high level overview
• Shows the pipeline activity for all clock pulses
  in a single diagram - see fig 6.20, p. 462

23
Multiple-clock-cycle pipeline diagram
Fig 6.20
Fig 6.21
24
What Can Go Wrong Pipeline HazardsA Preview

• Hazard a situation when the next instruction
  cannot execute in the following clock cycle
• Structural hazard
• What if there were a only single memory
• Example a lw followed by another instruction
  lw could be accessing data in the memory and the
  while the next instruction is attempting th be
  fetched into the same memory.

25
What Can Go Wrong Pipeline HazardsA Preview
(cont.)

• Control hazard
• The need to make a decision based on the results
  of one instruction while others are already
  executing. The decision may have an effect on
  instructions already executing
• Example conditional branch (beq) could
  invalidate instruction already in execution if
  the branch is successful.
• Possible solutionsstall the instruction after
  beq until the decision is determined (success or
  unsuccessful branch)predict or guess the outcome
  of the design. If you are correct then you run
  full speed, if you are wrong, then the following
  instruction must be flushed and the pipe refills
  from the new branched instruction stream.

26
What Can Go Wrong Pipeline HazardsA Preview
(cont.)

• Data hazard
• An instruction depends on the result of a
  previous instruction still in the pipeline.
• Exampleadd s0, t0, t1 s0 available in
  5th stagesub t2, s0, t3 s0 needed in
  2nd stage
• Naïve approach would be to stall sub until data
  is ready performance penalty
• Better make the data available earlier by
  forwarding or bypassing stagesgive the sub
  instruction the result before writing to the
  register file
• Sometime even with forwarding a stall ma be
  necessary, example
• lw s0, 20(t1) s0 available in 5th
  stage must access memory sub t2, s0, t3
  s0 needed in 2nd stage

Control and data hazard resolution is easier said
than done complicates controls implementation
details later
27
Data Hazard Forwarding
28
Pipeline Control

• Start with the controls used for the
  none-pipelined case (single clock cycle with
  controls) fig 5.19, p. 360

Fig 5.19
29
Pipeline Control (cont.)

• No controls needed for pipeline registers - they
  are written each clock cycle.
• Each control line is associated with a component
  active in only a single pipeline stage - thus
  divide the control lines into potentially 5
  groups (per stage) ... see fig. 6.29, p. 469
• Since we are using the single clock data path,
  the controls are only for last 3 stages.
• Thus, of the 5 potential groups, we will need
  only three groups

30
Pipeline Control (cont.)

• All controls are created during the decode phase
  and stored in the ID/EX pipeline register
  extending the register.
• As the clock pulses and the instruction advances
  thru the pipeline
• Control signal needed by the current execution
  phase are utilized and ...
• The remainder of them are passed to the next
  pipeline register to be used by later phases.
  See fig. 6.28 - 6.29, p. 469
• This method of asserting control lines is
  reminiscent of horizontal microcode where the
  control lines (bits in the microword) are
  asserted as the microword is executed
• ... The control bits in the phase registers play
  this role - controls for a particular phase
  becoming asserted when the phase occurs (become
  active)
• When a stage is inactive, the control lines for
  that stage are deasserted (killing that phase)

31
Pipeline ControlComparison With
Mult-clock-nonpipeline Control

• In chapter 5 (multi-clock), the sequencing of
  control required a special hardware
  implementation of an FSM, (see fig, 5.42, 5.43),
  in this case the sequencing is embedded in the
  pipeline structure itself (pipeline registers).
• all control is computed during instruction decode
  phase and then passed along via pipeline
  registers
• The generation of the control values in the
  decode phase is combinational logic done in one
  clock pulse as in the single-clock design of
  chapter 5.
• Sequencing is achieved by an instruction moving
  from one phase to another the control signals
  associated with a phase being presented as the
  stage is entered via the pipeline register for
  that phase.
• In chapter 5 (multi-clock) instruction execution
  took a variable number of clock cycles (see fig
  5.42), in this case all instructions take same
  number of cycles.

32
Pipeline Control (cont.)
Pass control signals along just like the data
Fig. 6.28
Fig. 6.29
33
Datapath with Pipeline Control
Fig. 6.30
34
Datapath with Pipeline ControlChanges from fig.
5.19 (single clock)

• Changes from fig. 5.19 (single clock) to fig 6.30
  (pipelined)
• Destination register (rt or rd) propagated
  because of multi-clock timing.
• PC set twice via PCSource for the MUX
• increment in fetch phase
• branch address if instruction is beq in MEM phase
  overwrites incremented value if successful
• jump instruction not implemented in fig 6.30

35
A Scenario Showing Pipeline ControlsSee pdf
figures 6.31 6.35

• Scenario for the following sequence (see
  overheads slides)lw 10, 20(1) note that
  these instructions are independent of each
  other!sub 11, 2, 3and 12, 4, 5or 13,
  6, 7add 14, 8, 9
• A fully loaded pipeline (5 instructions), with
  controls ... Takes 9 clock cycles to complete.
  See fig 6.31 - 6.35
• Although one instruction begins (and completes)
  each clock cycle, an individual instruction takes
  five cycles to complete
• Note the propagation of the destination register
  thru the pipe starting in fig 6.33
• It takes 4 cycles before the 5 stage pipeline is
  operating at full efficiency (see fig 6.33)
  filling the pipe.
