Topic 1: Review of Combinational Logic Design

1
Topic 1Review of Combinational Logic Design

• SFSU ENGR 852
• Spring 2003
• 1/27, 2/3

2
ResourcesCombinational Logic

• http//jever.phys.ualberta.ca/gingrich/phys395/no
  tes/node117.html
• Number Systems, Binary, Octal and Hexadecimal
  Numbers, Number Representation, Boolean Algebra,
  Logic Gates, Combinational Logic, Combinational
  Logic Design Using Truth Tables, The AND-OR Gate,
  Exclusive-OR Gate, Half and Full Adders,
  Multiplexers and Decoders
• http//www.play-hookey.com/digital/derived_gates.h
  tml
• Combinational Logic
• http//6004.lcs.mit.edu/currentsemester/tutprobs/l
  ogic.pdf
• To page 3
• http//kom.auc.dk/logic/design.html
• Design steps

3
What Well work on in this class

• Review Combinational Sequential Circuits
• Meally, Moore, Memory
• Introduce Asynchronous Circuits
• Design of Large Digital Systems
• Examine How to Test Those Circuits
• Show How To Interface with the Real World
• How Digital Circuits Are Actually Designed
• CAD Tools
• Implementation Options

4
Big Topic Large System Design

• Take a description of a large system
• For example, a car A thing you can ride in that
  can get you from one place to another.
• Break it into smaller parts
• Some way to make it go, some way to make it stop,
  and some way to make it turn.
• Break those parts into smaller parts
• How to make it go Gas peddle, connection to
  valve, spark to make gas explode, place to let
  gas explode without exploding other things
• Stop when you have a piece that you know you can
  build.

5
Design and implementation

• Top down design
• Example Break telephone into small blocks that
  you know you can design.
• Bottom up implementation
• Build the small blocks
• Move up a level to the block that contains the
  blocks you just designed.
• Build that block using the blocks you just
  designed.

6
In our case
For example A Radio
A/D (Analog to Digital converter)
A data digital data processing block.
D/A (Digital to Analog converter)
Analog
Analog
Digital
7
Schedule

• Combinational and sequential circuit design
• Asynchronous system and circuit design
• Larger digital systems
• Microcontroller use and design
• RAM use in designs
• CAD and implementation methods
• Circuit and chip testing

8
Why Digital Design?

• Because its kinda fun
• Can play at a higher level than analog
• Can do math on/manipulate digital values
• Can select and adjust values
• Values hard to corrupt
• Harder to mistake 0 1 than 3.7894 3.4952
• Because you can build anything
• Learn interfacing methods and its true!

9
Basics 1 Analog vs. Digital
10
Basics 2 How You Build

• Building by Gate
• Find Boolean Logic then Draw Design in Gates
• VHDL, Verilog, ABEL Other HDLs
• Write a Program
• State Flow Model
• Draw a State Machine
• Transistor level
• Draw at layout or transistor level
• Program a microprocessor
• Write an machine language program (or use a
  compiler)

11
Basics 3 What You Build

• Combinational Circuits
• Not Clocked
• Sequential
• Clocked
• Has State
• Asynchronous
• No Clock but Has State. Huh?

12
Basics 4 Components

• AND (NAND)
• OR (NOR)
• XOR (XNOR)
• INV (Inverter)
• MUX
• Flip-Flop
• Latch

13
Class QuestionBasic Components
14
Combinational Logic Design

• Steps in Designing a Combinational Circuit

UNDERSTAND PROBLEM!!!!!!!!!
Step 1
UNDERSTAND PROBLEM!!!!!!!!!
Step 2
UNDERSTAND PROBLEM!!!!!!!!!
Step 3
UNDERSTAND PROBLEM!!!!!!!!!
Step 4
15
Combinational Logic Design

• Steps in Designing a Combinational Circuit

UNDERSTAND PROBLEM!!!!!!!!!
Step 1
Determine I/O
Step 2
Truth Table
Step 3
Generate Logic Equations
Step 4
Draw Logic
Step 5
16
Combinational Logic ExampleStep 1

• Step 1
• Understand Problem
• A Circuit Which Subtracts 2 From a 3-bit Number
• Example
• If input is 101 (5), output is 011
• Is Description Complete?

17
Combinational Logic ExampleStep 1

• Step 1
• Understand Problem
• A Circuit Which Subtracts 2 From a 3-bit Number
• Example
• If input is 101 (5), output is 011
• Is Description Complete?
• What Happens When the Input is 1?
• Lets Limit Input to Values Greater than 1.

18
Combinational Logic ExampleStep 2

• Step 2
• Determine I/O

Circuit-to-be
19
Combinational Logic ExampleStep 3

• Step 3
• Truth Table
• Tool 1

X2 X1X0 Y2 Y1Y0
0 0 0 X X X 0 0 1
X X X 0 1 0 0 0 0
0 1 1 0 0 1 1 0 0
0 1 0 1 0 1 0 1 1
1 1 0 1 0 0 1 1 1
1 0 1
20
Combinational Logic ExampleStep 4

• Step 4
• Generate Logic Eq.
• From TT
• SOP
• POS
• K-Map
• SOP
• POS
• Guess? (By examination)

X2 X1X0 Y2 Y1Y0
0 0 0 X X X 0 0 1
X X X 0 1 0 0 0 0
0 1 1 0 0 1 1 0 0
0 1 0 1 0 1 0 1 1
1 1 0 1 0 0 1 1 1
1 0 1
21
Combinational Logic ExampleStep 4 SOP

• Step 4
• From TT
• SOP
• Sum of Products
• Look For 1s
• Y2X2 X1 X0 X2 X1 X0 X2 X1
• Y1 X2 X1 X0 X2 X1 X0 X2 X1
• Y0 X2 X1 X0 X2 X1 X0 X2 X1 X0
• X2 X1 X0 X2 X0
• (OR Y0 X0. X can be Anything so it can be
  1 in the second row)

X2 X1X0 Y2 Y1Y0
0 0 0 X X X 0 0 1
X X X 0 1 0 0 0 0
0 1 1 0 0 1 1 0 0
0 1 0 1 0 1 0 1 1
1 1 0 1 0 0 1 1 1
1 0 1
22
Combinational Logic ExampleStep 4 POS

• Step 4
• From TT
• POS
• Product of sums
• Look For 0s
• Y2(X2X1X0)(X2X1X0)
• (X2X1X0)(X2X1X0)
• X2?X1
• Y1 (X2X1X0)(X2X1X0)
• (X2X1X0)(X2X1X0)
• X1 Y0 left for you to do.

X2 X1X0 Y2 Y1Y0
0 0 0 X X X 0 0 1
X X X 0 1 0 0 0 0
0 1 1 0 0 1 1 0 0
0 1 0 1 0 1 0 1 1
1 1 0 1 0 0 1 1 1
1 0 1
23
Combinational Logic ExampleStep 4 SOP K-MAP

• Step 4
• K-map
• Tool 2
• SOP
• Sum of Products
• Look For 1s

X2 X1X0 Y2 Y1Y0
0 0 0 X X X 0 0 1
X X X 0 1 0 0 0 0
0 1 1 0 0 1 1 0 0
0 1 0 1 0 1 0 1 1
1 1 0 1 0 0 1 1 1
1 0 1
24
Combinational Logic ExampleStep 4 SOP K-MAP

• Step 4
• K-map (SOP)
• Most Convenient to Make Xs in First Column zeros.
• Logic Becomes Y2 X2X1

X2 X1X0 Y2 Y1Y0
0 0 0 X X X 0 0 1
X X X 0 1 0 0 0 0
0 1 1 0 0 1 1 0 0
0 1 0 1 0 1 0 1 1
1 1 0 1 0 0 1 1 1
1 0 1
25
Combinational Logic ExampleStep 4 SOP K-MAP

• Step 4
• K-map (SOP)
• Most Convenient to Make Xs in First Column ones.
• Logic Becomes Y1 X1

X2 X1X0 Y2 Y1Y0
0 0 0 X X X 0 0 1
X X X 0 1 0 0 0 0
0 1 1 0 0 1 1 0 0
0 1 0 1 0 1 0 1 1
1 1 0 1 0 0 1 1 1
1 0 1
26
Combinational Logic ExampleStep 4 SOP K-MAP

• Step 4
• K-map (SOP)
• Most Convenient to Make X in First Row a Zero and
  X in Second Row a One.
• Logic Becomes Y0 X0

X2 X1X0 Y2 Y1Y0
0 0 0 X X X 0 0 1
X X X 0 1 0 0 0 0
0 1 1 0 0 1 1 0 0
0 1 0 1 0 1 0 1 1
1 1 0 1 0 0 1 1 1
1 0 1
27
Combinational Logic ExampleStep 4 POS K-MAP

• Step 4
• K-map (POS)
• Most Convenient to Make Xs in First Column zeros.
  (This table isnt a good example of POS).
• Logic Becomes Y2 X2 X1 Therefore Y2
  X2X1

X2 X1X0 Y2 Y1Y0
0 0 0 X X X 0 0 1
X X X 0 1 0 0 0 0
0 1 1 0 0 1 1 0 0
0 1 0 1 0 1 0 1 1
1 1 0 1 0 0 1 1 1
1 0 1
28
Combinational Logic ExampleStep 2

• Step 2
• Determine I/O

29
Combinational Logic ExampleStep 5

• Step 5
• Draw K-MAP SOP logic
• Y2 X2 X1
• Y1 X1
• Y0 X0

Y0
X0
Y1
X1
Y2
X2
30
Combinational Logic ExampleStep 4 POS K-MAP

• Step 4 (Example. Not related to example weve
  been doing)
• K-map (New Random Table to Show a Better Example
  of Finding Reduced POS From K-Map)
• Logic Becomes Y (X2X1)(X2X1)


31
Class QuestionDrawing Gates

• Step 5
• Draw logic gates for last slide

32
Combinational Logic ExampleStep 4

• Step 4
• Last Choice Method for Determining Logic Guess
• (By Examination)

33
Class Questions Incrementer and Pattern Matcher

• Design 1 (incrementer) Specifications
• Adds 1 to Input.
• Design 2 (Pattern Matcher) Specification
• Matches any value with exactly two 1s. Input is
  a 3-bit number.

Label and show all steps. Do SOP, POS, K-map
SOP, K-map POS
34
Combinational Logic Design

• Steps in Designing a Combinational Circuit

UNDERSTAND PROBLEM!!!!!!!!!
Step 1
Determine I/O
Step 2
Truth Table
Step 3
Generate Logic Equations
Step 4
Draw Logic
Step 5
35
Class QuestionA Simple System

• Now that you have
• How would you make the following circuit

36
Cascaded Logic

• Though the last class question may have seemed
  trivial, it is very powerful in building larger
  circuits. Lets look at one more example of
  cascading smaller blocks.

37
Cascaded Logic

• Example Divide-by-ten circuit
• Understand the problem (Big picture)
• Input A number. At least 4-bits wide. Here lets
  say 8 bits
• Output Quotient Remainder

38
Cascaded Logic

• Make some design decisions
• How do you do it by hand?
• If you subtract 1010 from four bits and the
  result is greater than 0 you put a 1 in the
  quotient

39
Cascaded Logic

• Make some design decisions
• How do you do it by hand?
• If you subtract 1010 from four bits and the
  result is less than 0 you put a 0 in the
  quotient

40
Cascaded Logic

• Make some design decisions
• How do you do it by hand?
• If you subtract 1010 from four bits and the
  result is greater than 0 you concatenate the next
  bit in the dividend to the end of the result and
  start the process over with that number

41
Cascaded Logic

• Make some design decisions
• How do you do it by hand?
• If you subtract 1010 from four bits and the
  result is less than 0 you concatenate the next
  bit in the dividend to the end of the original
  4-bits and start the process over with that number

42
Cascaded Logic

• Make some design decisions
• Design a per-step block using by-hand model
• Input A 5-bit wide number (Call it IN).
• Output Original number if IN- 1010 lt 0
• IN 1010 if IN- 1010 ? 0
• 0 if IN- 1010 lt 0
• 1 if IN- 1010 ? 0

Dividend
Quotient Bit
43
Cascaded Logic

• Design the block

44
Cascaded Logic

• Design circuit

Remainder
45
Class Question?Half-adder, Full-adder

• Build a single-bit adder
• A B Sum and Carry
• Build a single bit adder with carry-in
• A B Carry-in Sum and Carry

Label and show all steps.
46
Class Question

• Build a 4-bit adder using half-adder and full
  adder blocks.

47
Other Combinational Logic Implementations

• What weve done
• Gate-based logic
• Component based logic
• ROM-based combinational logic
• Decoder-based combinational logic

48
ROM Based logic

• First, what is a ROM?
• Read-Only-Memory
• Remember what gate-based logic is You put
  something in (inputs) and get something out (a
  value).
• Whats ROM? You put something in (address) and
  get something out (a value).

49
Basic ROM Memory3x8 ROM
50
ROM-Based Logic Example

• Say youre given
• Y A?B A?C
• Make a truth table

Y
51
ROM-Based Logic Example

• Hmmmm. The truth table/circuit looks a lot like
  the ROM picture back a couple of slides.

A B C
3x8 ROM
Y
52
ROM-Based Logic Example

• I contend that the ROM below is an implementation
  of the logic equation Y A?B A?C

A B C
Y
3x1 ROM
Address Value 000 0
001 1 010 0 011
1 100 1 101
1 110 0 111
0
Address/ABC
Data/Y
3
53
ROM-Based Logic Design Steps

• Steps
• Determine I/O. (How many inputs? How many
  outputs?) ?Select ROM size
• Draw truth table.
• Burn values into ROM.

54
Class QuestionROM-Based Logic

• Implement the following circuit in a ROM
• Y2 X2 X1
• Y1 X1
• Y0 X0

55
Decoder-Based logic

• First, what is a decoder?

56
Decoder-Based logic

• Remember what gate-based logic is You put
  something in (inputs) and get something out (a
  value).
• Whats Decoder? You put something in (a value)
  and get something out (a high value on the line
  of the input value).

57
Decoder-Based Logic Example

• Say youre given
•
• Make a truth table

_ _ _ _ _
_ Y A?B?C A?B?C A?B?C A?B?C
Y
58
Decoder-Based logic

• The implementation (SOP) (Fewer 1s than 0s)

_ _ _ _ _
_ Y A?B?C A?B?C A?B?C A?B?C
59
Decoder-Based logic

• The implementation (POS) (Fewer 0s than 1s)

_ _ _ _ _ _ Y
A?B?C A?B?C A?B?C A?B?C
60
DeMorgans Theorem

• DeMorgan's Theorem
• The most important logic theorem for digital
  electronics, this theorem says that any logical
  binary expression remains unchanged if we
• Change all variables to their complements.
• Change all AND operations to ORs.
• Change all OR operations to ANDs.
• Take the complement of the entire expression.

http//www.cs.iupui.edu/ddillow/N301/deMorgan.htm
l
61
DeMorgans Theorem
The Gates

62
Decoder-Based logic

• The implementation (POS) (Fewer 0s than 1s)

_ _ _ _ _
_ Y (A?B?C) ?(A?B?C)?(A?B?C)?(A?B?
C)
63
Review of Combinational Logic Generation
64
Class QuestionWhat Logic to select?

• Many outputs
• Many inputs
• Many zeros in output
• Dont want to test much
• Needs to be small
• Needs to be fast

65
Class QuestionDeMorgans

• Implement in all NAND gates and inverters

66
Class QuestionDeMorgans

• Implement in all NAND gates and inverters

67
Class QuestionDeMorgans

• Implement in all NAND gates and inverters

68
Another Look at Design

• Where to Start?
• Maybe Youll see the Big Picture
• Sometimes Easy to Overlook Things
• ? I want you to follow steps for all problems
  done for this class.
