. . . presents

1

• . . . presents

2
SERIES 800 MOMENT BALANCE SYSTEM
3
Nobody Knows Moment Weighing Like AWS

• Unique System to Moment Weigh a SPHERE
• Connecting Rods
• Engine Blades
• Fan
• Turbine
• Rotor
• Compressor

4
Customers Depend on AWS

• More Than 30 Years Experience in Moment Weighing
• Systems That Were Installed in the 1970s Are
  Still Operational
• Low Maintenance
• Increased Productivity

5
GE Aircraft Engines Group
So reliable is AWS equipment, that in 1982 GE
awarded a Class 0ne, Group One QC Code Rating
making AWS a self-certified vendor.

• Proved the AWS Method is Most Accurate
• AWS Equipment Specified For ALL Facilities
• Engine Blade
• Engine Assembly
• Engine Maintenance

6
PRATT WHITNEY AIRCRAFT

• Engine Blades Manufactured by
• HOWMET Corporation
• I.E.P.I.
• TURBO PRODUCTS
• NEW ENGLAND AIR FOIL
• Approved for Use on all PW Engines

7
U.S. Air Force

• Units in Service
• Kelly AFB (3)
• Travis AFB (2)
• Altus AFB
• Dover AFB

• Engine Maintenance
• Overhaul
• Total Time to Balance an Engine Reduced by More
  Than 30

8
BLADE MOMENT BALANCE
9
BASE ASSEMBLY

• Tubular Steel Construction
• Sand Filled to Eliminate Ringing
• Adjustable Feet for Leveling

10
Custom HOUSING

• Eliminates Air Currents About the System
• LEXAN and Aluminum Tube Construction
• Sliding Doors Allow Full Access

11
Time Proven AWS Weigh Cell

• Patented Mass Balance, Hydraulic Dampening
• Readings Obtained in Less Than 150 Milli-seconds
• Accuracy to 0.01 of Full Scale
• Counterbalanced for Tooling and Master Load

12
SCALE Assembly
13
RANGE OPTIONS
RESOLUTION 0.001 of TOTAL CAPACITY
14
CUSTOM Designed Manufactured Blade Tooling

• Designed to Critically Hold Blade as It Will Be
  Installed
• Actual Moment As If Installed In Disk Assembly
• Matched to Scale For Superior Accuracy

15
CRADLE Assembly
16
Computer Configuration

• Pentium III Compatible or Better
• MS/DOS 6.22
• 1 Serial Port
• 1 (9 Pin) for the Input From the Scale
• 2 Parallel Ports
• 1 for the Label Printer
• 1 for the Report Printer

17
Moment Software(version 9.3)

• Interactive Prompts for Each Operation
• Part Data Entry/Modification in Less Than a
  Minute
• All Settings Password Protected From Unauthorized
  Changes
• Prompted Scale Set-Up and Calibration

18
Ease of Use

• Minimal Time for Part Selection Changeover
• Four Screws to Remove Replace The Cradle
• Menu Selection to Change Software Part
  Specifications
• Reference the MASTER for the New Part

19

• Limited Operator Data Input
• Eliminates Transcription and Entry Errors
• AUTOMATIC Data Recording
• Individual Piece Serial Numbering
• Operator ID
• Measurement Result

20
Part Sorting and Data Retrieval

• Sort to Groups
• Sort for Matched Pairs
• Sort Pairs to Matched Sets
• Absolute Sort of Complete Assembly
• Data to Labels, Reports, and Files

21
THEORY OF OPERATION
MOMENT is a factor of the mass of the part,
times the distance of the Center of Mass from the
Centerline of the Scale Assembly

• The MOMENT is Measured From the Centerline of the
  Assembly, Rather Than Some Arbitrary Point .
• Computes the MOMENT by Determining the
  Difference (plus or minus 10 of the Total) from
  the MASTER or OPTIMUM Blade Moment..
• RESULT The AWS Method Renders Results That Are
  At Least 10 Times More Accurate Than Other
  Methods Of Moment Determination.

22
OPERATION

• After the the System Setup, The Operator Follows
  These Steps
• Enters Individual Operator ID
• Selects the Part to be Measured
• Inserts a MASTER Blade into the Cradle for
  Referencing
• Removes the MASTER, Inserts a Part to be
  Measured

23

• After Closing the Housing Doors,
• Allows the Scale to Settle, Pushes theF5 Key,
  Enters the Part Serial Number and Press the ENTER
  Key
• The Label is Printed and the Measurement Data is
  Saved to a File
• The Operator Continues Inserting Parts Until a
  Sufficient Number for Accurate Classification
  Have Been Measured

24
The Entire Process of Loading a Part into the
Cradle, Closing the Housing Door, Measuring the
Part, Removing It, and Affixing the Label Takes
Less Time Than It Is Taking Me to Tell You About
It!
25
Cost Benefits

• Increased Productivity
• Up to 10 Parts Per Minute
• Limited Operator Data Entry Between Parts
• One Scale Can Measure Several Parts
• More Than 35 Reduction in TOTAL Time to Balance
  an Engine
• Economical Operation
• 115 VAC/60Mhz Power
• Minimum Operator Training Required

26
Advantages of the AWS System

• Unmatched Accuracy
• Mechanically Provable In the Field
• Ease of Use
• Selectable Part Sorting Methods
• Increased Productivity
• Economy of Operation

27
TO FIND OUT MORE, Contact

• Inside Sales
• Advance Weight Systems, Inc. 409 North
  Main Street P.O. Box 6 Grafton, OH 44044
• Telephone [phone]
• FAX [phone]
• http//www.advancew8.com
