CMSC424: Database Design

1
CMSC424 Database Design

• Instructor Amol Deshpande
• amol_at_cs.umd.edu

2
Data Modeling

• Goals
• Conceptual representation of the data
• Reality meets bits and bytes
• Must make sense, and be usable by other people
• Today
• Entity-relationship Model
• Relational Model

3
Motivation

• Youve just been hired by Bank of America as
  their DBA for their online banking web site.
• You are asked to create a database that monitors
• customers
• accounts
• loans
• branches
• transactions,
• Now what??!!!

4
Database Design Steps
Entity-relationship Model Typically used
for conceptual database design

• Three Levels of Modeling

Conceptual Data Model
Logical Data Model
Relational Model Typically used for
logical database design
Physical Data Model
5
Entity-Relationship Model

• Two key concepts
• Entities
• An object that exists and is distinguishable from
  other objects
• Examples Bob Smith, BofA, CMSC424
• Have attributes (people have names and addresses)
• Form entity sets with other entities of the same
  type that share the same properties
• Set of all people, set of all classes
• Entity sets may overlap
• Customers and Employees

6
Entity-Relationship Model

• Two key concepts
• Relationships
• Relate 2 or more entities
• E.g. Bob Smith has account at College Park Branch
• Form relationship sets with other relationships
  of the same type that share the same properties
• Customers have accounts at Branches
• Can have attributes
• has account at may have an attribute start-date
• Can involve more than 2 entities
• Employee works at Branch at Job

7
ER Diagram Starting Example

• Rectangles entity sets
• Diamonds relationship sets
• Ellipses attributes

8
Rest of the class

• Details of the ER Model
• How to represent various types of
  constraints/semantic information etc.
• Design issues
• A detailed example

9
Next Relationship Cardinalities

• We may know
• One customer can only open one account
• OR
• One customer can open multiple accounts
• Representing this is important
• Why ?
• Better manipulation of data
• Can enforce such a constraint
• Remember If not represented in conceptual model,
  the domain knowledge may be lost

10
Mapping Cardinalities

• Express the number of entities to which another
  entity can be associated via a relationship set
• Most useful in describing binary relationship sets

11
Mapping Cardinalities

• One-to-One
• One-to-Many
• Many-to-One
• Many-to-Many

has
customer
account
has
customer
account
has
customer
account
has
customer
account
12
Mapping Cardinalities

• Express the number of entities to which another
  entity can be associated via a relationship set
• Most useful in describing binary relationship
  sets
• N-ary relationships ?

13
Next Types of Attributes

• Simple vs Composite
• Single value per attribute ?
• Single-valued vs Multi-valued
• E.g. Phone numbers are multi-valued
• Derived
• If date-of-birth is present, age can be derived
• Can help in avoiding redundancy, enforcing
  constraints etc

14
Types of Attributes
15
Types of Attributes

• multi-valued (double ellipse)
• derived (dashed ellipse)

age
cust-name
cust-id
customer
date-of-birth
cust-street
phone no.
cust-city
16
Types of Attributes
age
cust-name
cust-id
customer
date-of-birth
cust-street
phone no.
cust-city
month
day
year
Composite Attribute
17
Next Keys

• Key set of attributes identifying individual
  entities or relationships

18
Entity Keys
Possible Keys cust-id cust-name,
cust-city, cust-street cust-id, age
cust-name ?? Probably not. Domain knowledge
dependent !!
date-of-birth
cust-name
cust-id
customer
age
cust-street
phone no.
cust-city
19
Entity Keys

• Superkey
• any attribute set that can distinguish entities
• Candidate key
• a minimal superkey
• Cant remove any attribute and preserve key-ness
• cust-id, age not a superkey
• cust-name, cust-city, cust-street is
• assuming cust-name is not unique
• Primary key
• Candidate key chosen as the key by DBA
• Underlined in the ER Diagram

20
Entity Keys

• cust-id is a natural primary key
• Typically, SSN forms a good primary key
• Try to use a candidate key that rarely changes
• e.g. something involving address not a great idea

date-of-birth
cust-name
cust-id
customer
age
cust-street
phone no.
cust-city
21
Relationship Set Keys

• What attributes are needed to represent a
  relationship completely and uniquely ?
• Union of primary keys of the entities involved,
  and relationship attributes
• cust-id, access-date, account number describes
  a relationship completely

22
Relationship Set Keys

• Is cust-id, access-date, account number a
  candidate key ?
• No. Attribute access-date can be removed from
  this set without losing key-ness
• In fact, union of primary keys of associated
  entities is always a superkey

23
Relationship Set Keys

• Is cust-id, account-number a candidate key ?
• Depends

access-date
number
cust-id
has
customer
account
24
Relationship Set Keys

• Is cust-id, account-number a candidate key ?
• Depends

access-date
number
cust-id
has
customer
account

• If one-to-one relationship, either cust-id or
  account-number sufficient
• Since a given customer can only have one account,
  she can only participate in one relationship
• Ditto account

25
Relationship Set Keys

• Is cust-id, account-number a candidate key ?
• Depends

access-date
number
cust-id
has
customer
account

• If one-to-many relationship (as shown),
  account-number is a candidate key
• A given customer can have many accounts, but at
  most one account holder per account allowed

26
Relationship Set Keys

• General rule for binary relationships
• one-to-one primary key of either entity set
• one-to-many primary key of the entity set on the
  many side
• many-to-many union of primary keys of the
  associate entity sets
• n-ary relationships
• More complicated rules

27
Next Data Constraints

• Representing semantic data constraints
• We already saw constraints on relationship
  cardinalities

28
Participation Constraint

• Given an entity set E, and a relationship R it
  participates in
• If every entity in E participates in at least one
  relationship in R, it is total participation
• partial otherwise

29
Participation Constraint
access-date
cust-name
number
cust-id
has
customer
account
cust-street
cust-city
balance
Total participation
30
Cardinality Constraints
How many relationships can an entity participate
in ?
access-date
number
cust-id
has
customer
account
0..
1..1
Minimum - 0 Maximum no limit
Minimum - 1 Maximum - 1
31
Next Recursive Relationships

• Sometimes a relationship associates an entity set
  to itself

32
Recursive Relationships
emp-name
emp-id
works-for
manager
employee
worker
emp-street
emp-city

• Must be declared with roles

33
Next Weak Entity Sets

• An entity set without enough attributes to have a
  primary key
• E.g. Transaction Entity
• Attributes
• transaction-number, transaction-date,
  transaction-amount, transaction-type
• transaction-number may not be unique across
  accounts

34
Weak Entity Sets

• A weak entity set must be associated with an
  identifying or owner entity set
• Account is the owner entity set for Transaction

35
Weak Entity Sets
Still need to be able to distinguish between
different weak entities associated with the same
strong entity
number
trans-date
trans-number
has

account
Transaction

trans-type
balance
trans-amt
36
Weak Entity Sets
Discriminator A set of attributes that can be
used for that
number
trans-date
trans-number
has

account
Transaction

trans-type
balance
trans-amt
37
Weak Entity Sets

• Primary key
• Primary key of the associated strong entity
  discriminator attribute set
• For Transaction
• account-number, transaction-number

38
Next Specialization

• Consider entity person
• Attributes name, street, city
• Further classification
• customer
• Additional attributes customer-id, credit-rating
• employee
• Additional attributes employee-id, salary
• Note similarities to object-oriented programming

39
Specialization Example
40
Finally Aggregation

• No relationships between relationships
• E.g. Associate account officers with has
  account relationship set

has
customer
account
?
account officer
employee
41
Finally Aggregation

• Associate an account officer with each account ?
• What if different customers for the same account
  can have different account officers ?

has
customer
account
?
account officer
employee
42
Finally Aggregation

• Solution Aggregation

has
customer
account
account officer
employee
43
More

• Read Chapter 2 for
• Specialization/Aggregation details
• Different types of specializations etc
• Generalization opposite of specialization
• Lower- and higher-level entities
• Attribute inheritance

44
E/R Data ModelDesign Issue 1 Entity Sets vs.
Attributes

• An Example Employees can have multiple phones

(b)
(a)
Uses
Employee
vs
Employee
Phone
no
loc
To resolve, determine how phones are used 1. Can
many employees share a phone? (If yes, then
(b)) 2. Can employees have multiple phones?
(if yes, then (b), or (a) with multivalued
attributes) 3. Else (a), perhaps with
composite attributes
Employee
phone
loc
no
45
E/R Data ModelDesign Issue 2 Entity Sets vs.
Relationship Sets
An Example How to model bank loans
Loans
Borrows
Customer
Branch
Customer
Loan
vs
(a)
amt
lno
(b)

• To resolve, determine how loans are issued
• 1. Can there be more than one customer per loan?
• If yes, then (a). Otherwise, loan info must be
  replicated for each customer (wasteful, potential
  update anomalies)
• 2. Is loan a noun or a verb?
• Both, but more of a noun to a bank. (hence (a)
  probably more appropriate)

46
E/R Data ModelDesign Issue 3 N-ary vs Binary
Relationship Sets
An Example Works_At
Ternary
Works_at
Employee
Branch
Choose n-ary when possible! (Avoids
redundancy, update anomalies)
Dept
(Joe, Moody, Acct) Î Works_At
vs
Binary
WAE
WAB
Branch
WA
Employee
WAD
(Joe, w3) Î WAE (Moody, w3) Î WAB (Acct, w3) Î WAD
Dept
47
Example Design

• We will model a university database
• Main entities
• Professor
• Projects
• Departments
• Graduate students
• etc

48
(No Transcript)
49
proj-number
SSN
sponsor
name
project
professor
start
area
budget
rank
SSN
dept-no
name
name
grad
dept
age
office
degree
homepage
50
(No Transcript)
51
Time ()
Major
52
Time ()
Major
And so on
53
Summary

• Entity-relationship Model
• Intuitive diagram-based representation of domain
  knowledge, data properties etc
• Two key concepts
• Entities
• Relationships
• We also looked at
• Relationship cardinalities
• Keys
• Participation Constraints

54
Summary

• Details unimportant
• Key idea We can represent many data properties
  and constraints conceptually using this
• Read Chapter 2
• Assignment will require you to do this anyway !
