Orientation Session

1
(No Transcript)
2
Orientation Session

• Presentation of the scope of the project and
  preliminary results for discussion

3
Introduction to the Afternoon Background

• Paul Watkiss
• Paul Watkiss Associates

4
Background

• Sheffield has air quality problems
• City-wide exceedance of Objectives
• Emissions from road vehicles major source
• Can reduce vehicles or vehicle km, or
• Can introduce cleaner vehicles

5
Low Emission Strategy

• Encourage use of cleaner vehicles
• Include voluntary, planning, partnership,
  enforced approach
• Potentially different vehicles (Lorries, Bus,
  Van, Taxi, Car)
• Potentially different area (centre, city,
  corridors, DA, region)
• Different emission criteria (age, Euro standard,
  RPC)

6
Low Emission Zone

• Introduced in Sweden, at implementation phase for
  London, being considered by other UK cities
• As with all LES, bring forward cleaner fleet
  new vehicles, new engine or retrofit
• Formal enforced zone with defined emission
  criteria
• London is greater London, HGVs and buses, Euro 2
  RPC in 2008, tightening in 2010 and possibly
  including vans

7
The Study

• Commissioned to provide independent analysis of
  options
• Assess emissions, AQ benefits, and progress
  towards Obj.
• Costs of schemes, practicality and acceptability
• Wider benefits health
• Socio-economic effects, including costs to
  operators

8
Today Your Views

• Views on acceptability and practicality of
  options
• Local issues, sensitive parts of the fleet,
  inequalities, conflicts with other policies
• Ranking of schemes use of simple tool
• Aim to identify smaller number of options to
  study in detail

9
(No Transcript)
10
Introduction to the Potential Options

• Gwyn Jones
• AEA Technology Environment

11
Large number of options

• Instruments or schemes that could implement a low
  emission strategy
• Emissions standard or standards that could apply
  within a low emission strategy
• Where to apply schemes? Central Sheffield, whole
  authority or whole of South Yorkshire?
• When to apply schemes?

12
Regulatory schemes

• Traffic Regulation Orders
• Traffic Regulation Conditions
• Public carriage office licensing
• The local planning framework
• Supplementary planning documents
• Section 106 agreements

13
Voluntary schemes

• Quality Bus Partnerships perhaps focused on major
  public transport corridors
• Freight Quality Partnerships
• Public Relations Campaigns

14
Economic schemes

• Mixture of incentives and penalties
• Vehicle scrappage in exchange for grant or travel
  permit
• Differentiated parking charges
• Grants to retro-fit abatement equipment
• Fines for non-compliance

15
Emission objectives
16
(No Transcript)
17
Implementation Issues Indicative Cost of Options

• Tom Parker
• Transport and Travel Research Ltd

18
Overview

• Implementation options
• Options and issues
• Costs and impacts

19
Implementation options

• Planning conditions for development control
  (large and small scale development)
• Low Emission Zone
• Taxi licensing
• Traffic Regulation Conditions Quality Bus
  Contract
• Statutory Bus Partnership Quality Bus
  Partnership
• Freight Quality Partnership
• Parking charges
• Scrapping incentives

20
Planning conditions (1)

• Supplementary Planning Document to ensure AQ
  considerations included in the City Development
  Framework
• City-wide
• Already in place
• Gradual and long-term impact
• Cost to SCC (low), cost to others (low)

21
Planning conditions (2)

• s106 conditions to ensure new Developments have
  reduced emissions by setting standards for
  construction vehicles, plus office and
  residential parking
• Can only be applied early in process e.g. Lower
  Don Valley, but probably not NRQ
• LDV may include 12,000 parking spaces
• Cost to SCC (low), cost to developer/user
  (medium)
• Requires a desirable development site

22
Low Emission Zone

• Formal designated zone, discouraging
  non-compliant vehicles through payment or penalty
• Central zone or city-wide
• Potentially all vehicle types, but can target
  specific
• Medium term measure possible multiple phases
• Cost to SCC (medium high), cost to other (high)
• Potential for exemptions, more impact on
  specialist fleet as longer lifetimes

23
Taxi regulation licensing conditions

• Require higher standards as licensing condition
  for taxi and private hire vehicles
• Has been used in London to develop an emission
  improvement strategy, supported by a 50p fare
  levy
• Could apply SCC wide
• Time-scale for taxi/phv response is medium term
• Cost to SCC (low), cost to taxi / phv
  (low-medium)

24
Traffic Regulation Conditions

• Powers from late 2004 for Traffic Commissioner to
  direct Bus Companies to improve fleet
• Could apply to all local buses in city
• Timescale medium e.g. 2 years
• Cost to SCC (low), cost to operator (medium/ low
  if used planned fleet renewals)
• Not tested yet, would depend on TC taking on case

25
Bus Quality Contracts

• SYPTE and Tyneside PTE asked companies to join in
  mock tendering exercise to investigate risks and
  costs
• Under a BQC services, fares and frequencies
  (timetables) are specified for defined routes or
  groups
• Bus Operators bid for exclusive right to operate
  services.
• Cost to SCC (low/med), Cost to operator
  (medium/low)
• Has not been tested, but may avoid route swapping

26
Quality and Statutory Bus Partnerships

• Improved service and vehicles in exchange for
  roadside infrastructure/priority binding
  non-binding variations
• Operates on a route by route basis, for local bus
  services use local) bus stops and priority routes
• Medium timescale to complete whole network
• Cost to SCC/SYPTE (medium-high), cost to operator
  (medium-low)
• Vehicles can be moved between routes to comply

27
Freight quality partnership

• Voluntary arrangements whereby Industry and
  Highway Authority agree improvements
• Coverage and impact depends on enthusiasm and
  agreement for FQP and emission standards..
• Timescale could be 1-3 years or longer for
  effective scheme
• Costs to SCC and others (low to medium) depend on
  extent of improvements

28
Parking management and charges

• Extension of park for a penny scheme
• City-wide, but focus is 1500 SCC city centre
  spaces
• Short/Medium term implementation, impact will
  decrease
• Cost to SCC (low / neutral), and for car park
  users overall (but high cost for older cars
  drivers)
• Impact will on shoppers/ commuters

29
Scrapping incentives

• Incentive for scrapping old high polluting
  vehicles money or public transport pass
• City wide
• Short term measure - target old fleet
• Cost to SCC (medium) /cost to others (low)
• Might have some additional benefits in targeting
  abandoned vehicles, but difficult to control

30
Impact and Cost Summary
31
Conclusions

• Coverage geographically, vehicles, users
• Time-scales
• Cost to council
• Cost to others
• Feasibility and practicability

32
(No Transcript)
33
Emissions The Potential Benefits of Options

• Gwyn Jones
• AEA Technology Environment

34
Method

• Local traffic growth factors
• Vehicle-kilometres (veh.km) for Sheffield
  (urban), Sheffield (whole authority) and South
  Yorkshire (4 LAs)
• National emission factor, fleet composition and
  cost data
• Pure substitution (e.g. all pre-Euro veh.km
  converted to at least scheme entry requirement)

35
Baseline trends
36
2008 Baseline NOx
37
2008 Baseline PM10
38
Emissions benefits NOx
39
Emissions benefits PM10
40
Air quality benefits
5m from roadside 20,000 AADTF 6 HDV City-wide
implementation
41
(No Transcript)
42
Other Effects

• Paul Watkiss
• Paul Watkiss Associates

43
Other Effects

• Health benefits of the schemes
• Numbers of vehicles affected
• Potential costs (to operators)
• Distribution or socio-economic effects
• Effects on wider economy

44
Health Benefits

• Background Health Impacts are important
• Sheffield studies 6 of heart disease, 11 of
  strokes
• Nationally tens of thousands of premature
  deaths, many millions of respiratory illnesses
• PM most strongly implicated NO2 less so
• Health benefits will follow emissions

45
Number of Vehicles

• Scheme will affect those registered and driving
  in area
• Data available for registrations but have to
  predict forward
• Plus those that come in from outside
• Very difficult to estimate, as not tracked
• Likely to include large number of regional
  registrations

46
Registered Vehicles (2004)

• Cars 190,000
• Taxis 500
• Vans 18,000
• Coach and Bus 1,000
• Goods vehicles 2,800

47

• Cars and coach/bus similar to national fleet,
  goods little older

48
Costs

• Costs to operators relate to action taken to
  comply
• Buy new or second hand vehicle, new engine,
  retrofit
• Stricter emission criteria bring more vehicles
  into the scheme
• Increase benefits, but increase costs to
  operators
• Larger vehicle (HGV/Bus) have higher emission, so
  more cost-effective to target also have
  retrofit options
• Smaller vehicles (cars) have small emissions,
  less cost-effective, no retrofit options

49
Other Issues

• Older vehicles affected more by scheme
• Specialist vehicles more expensive so longer
  lifetimes
• Certain sectors more transport intensive
  (haulage, trade)
• Smaller companies tend to run vehicles for longer
• Older cars driven by lower income groups -
  inequality

50
Wider Costs

• Smaller schemes may merely divert traffic move
  pollution problem from one area to another
• Some economic costs but low in relation to
  typical operating costs will be some benefits
  local retrofit
• Competitiveness vs. national operators, but note
  London anyway
• Could influence retail attractiveness (if car
  based)

51
Wider Benefits

• No demand changes if not this then what
• Large benefits outside immediate area, from
  cleaner vehicles driving elsewhere
• Will be noise benefits, as newer vehicles tend to
  be quieter
• Operators likely to get fuel benefits, lower
  maintenance costs from modern vehicles
• Government grant systems in place for heavier
  vehicles (EST)
• More attractive environment for people and
  companies

52
(No Transcript)
