Central Processing Unit

1
Chapter 8

• Central Processing Unit
• Sample Realistic Designs

2
Major Components of the CPU

• Every CPU consists of the three basic components
  shown in the figure below.
• Registers hold the inputs of the ALU operations
  and eventually receive the results.
• The control unitcontrols the operationof both
  ALU andregistersthrough the control signals.
• The ALU performs the actualoperations.

Registers
Control Unit
ALU
3
Realistic Organization

• With a large number of registers, dedicated
  connections are impossible.
• Some form of BUS mechanism has to be used to
  organize the connections.
• Most ALU operations require two pieces of data.
• We can send them to temporary ALU registers one
  at a time.
• Better yet, we can utilize a two bus system.

4
Register File Control

• Once the results are ready, they have to be sent
  to the proper register for storage.
• The instruction must specify the register and the
  control unit must enable the right control input.
• Registers are usually given a code to reduce the
  size of the instructions.
• This code can be decoded to create the needed
  load control inputs for the registers.

5
Controlling the ALU

• The ALU is a multi-function unit.
• The control unit needs to specify through control
  signals which operation to be performed.
• Putting all of the above together, each
  microoperation needs the following information
• Select inputs for BUS A.
• Select inputs for BUS B
• Destination register code.
• ALU operation code.

6
Register Organization
Input Data
R1
R2
R3
R4
R5
R6
R7
Load Controls
S E L B
S E L A
MUX 1
MUX 2
3 X 8 Decoder
Bus B
Bus A
Arithmetic Logic Unit ALU
O P R
SELD
3
3
3
5
Control Word
SELA
SELB
SELD
OPER
7
Example of a Microoperation

• The control word mentioned above has 14 bits.
  They will represent the different parts of the
  microoperations to be performed.
• For example, the microoperation
• R1 ? R2 R3
• has the following control word
• Field SELA SELB SELD OPER
• R2 R3 R1 SUB
• 010 011 001 00101
• The control word is
• 010 011 001 000101

8
Stack Organization

• A useful feature that is included in almost every
  CPU.
• The stack is a storage device that stores
  information in a Last In First Out (LIFO) manner.
• The stack in digital computers is essentially a
  memory unit with a dedicated address register
  the Stack Pointer that continuously points to
  the upper most item in the stack.
• Items are added to the stack using a PUSH
  operation and removed from it using a POP.
• These operations are simulated through
  incrementing and decrementing the register.

9
Register Stack

• If the microprocessor has enough registers, it is
  actually possible to implement the stack
  operation using registers.
• The stack pointer register in this situation
  would contain the index of the register
  containing the item at the top of the stack.
• With a register stack there would also be a need
  for a couple of flag registers to determine when
  the stack is completely full or completely empty.

10
Stack Based CPUs

• There are several CPUs that were designed without
  general purpose registers.
• Instead these CPUs had a fast memory stack that
  could be used instead of the registers.
• In order to effectively use such a system,
  mathematical expressions have to be re-written in
  a slightly different manner.

11
Infix Notation

• Common arithmetic expressions are written with
  the operator between its operands.
• This causes a problem for programmers.
• Consider the following expression
• A B C D
• The program must
• Read the entire expression
• Extract all of the operands
• Extract all of the operations
• Decide which operations to do first.

12
Prefix Notation

• It is possible to re-write arithmetic expressions
  so that the operation is specified before its
  operands.
• This way, there is no need to parse the entire
  expression.
• Read an operation, scan forward until the its two
  operands are obtained, execute it, continue.
• The previous expression can be re-written as
• A B C D
• We read the operator first.
• Scan forward, we find an operation. Therefore,
  the first operand of the is the result of this
  . Perform the operation.
• We find another operation. Perform it.
• Now we have the two operands for the , perform
  it.

13
Reverse Polish Notation

• The previous notation is known either as prefix
  notation or Polish Notation since it was
  defined by a Polish mathematician.
• A more popular notation is actually the reverse
  of this one Reverse Polish Notation (RPN).
• Postfix notation.
• The operands are specified first, then the
  operator.
• This notation is extremely popular with stack
  based CPUs.
• Like the CPUs in HPs scientific calculators.

14
RPN

• Our sample expression can be written as
• A B C D
• It can be evaluated as follows
• Scan from the left, as soon as an operation is
  found, perform it on the two operands immediately
  to its left.
• Replace the operation and its two operands with
  the result.
• Continue forward.

15
RPN Evaluation Example

• Evaluate the following expression
• 1 2 3 4 5 6
• First, re-write it in RPN
• 4 5 6 2 3 1
• We find 4 5 first. Evaluate that. 20. The
  expression now becomes
• 20 6 2 3 1
• Then we find 20 6 . Evaluate it. 120.
• 120 2 3 1
• Now we find 2 3 . Evaluate it. 6.
• 120 6 1
• Now we find 120 6 . Evaluate it. 126.
• 126 1
• Evaluate the last expression 126 1 .
• The result is 127.

16
Conversion to RPN

• We must follow the hierarchy of operations
• Perform all operations inside inner parenthesis
  first, then outer ones.
• Perform multiplication and division before
  addition and subtraction.
• Example
• Translate the following expression to RPN
• (A B) C (D E) F
• The result is
• A B D E C F

17
Evaluating RPN Expressions with a Stack

• Push all operands on the stack until the first
  operation.
• Pop the first two elements off the stack and
  perform the operation.
• Push the result back on the stack.
• Continue.

18
Example

• Evaluate the following expression using a stack
• 3 4 5 6
• Push the 3 on the stack.
• Push the 4 on the stack.
• Pop the 4 and the 3, perform the operation.
• Push the result (12) on the stack.
• Push 5 on the stack.
• Push 6 on the stack.
• Pop the 6 and the 5, perform the operation.
• Push the result (30) on the stack.
• Pop the 30 and the 12 off the stack, perform the
  operation.
• Push the result (42) on the stack.

19
Example 2

• Evaluate the following expression using a stack
• 1 2 3 4 5 6
• First, re-write it in RPN
• 4 5 6 2 3 1

3
2
5
6
2
6
1
4
20
120
120
120
126
4
20
120
126
127
4
5

6

2
3


1

20
Section 8.8

• Reduced Instruction Set Computer
• (RISC)

21
Instruction Set vs. Architecture

• The design of the instruction set is an important
  aspect of computer architecture.
• The instruction set chosen determines the way
  machine language programs are constructed.
• Early computers had small and simple instruction
  sets.
• Due mainly to the need to reduce the hardware
  needed to implement them.

22
CISC - Complex Instruction Set Computers

• With the invention of complex ICs, hardware
  complexity became a non-issue. This lead to the
  development of some highly complex architectures.
• Architectures with instruction sets that
  contained more than 100 instructions became
  widely spread.
• The trend was to move operations from software to
  hardware.
• Machine instructions like COS, SIN and TAN
  started to appear.
• Actually, some processors also had machine
  instructions for matrix operations.

23
RISC - Reduced Instruction Set Computers

• Complex instruction sets had a large number of
  complex instructions.
• The complex instructions required a long time to
  execute.
• The instructions required a lot of memory
  accesses.
• Some of the instructions were so specialized that
  they were used quite infrequently.
• In the early 1980s, designers tried to balance
  that by moving towards simpler instruction sets.

24
CISC Characteristics

• Designers wanted to simplify the process of
  compilation.
• Rather than translate a high level language
  instruction into many machine language
  instructions, why not design machine language
  instructions that implemented them directly.
• Complex machine language instructions.

25
CISC Characteristics

• In order to be efficient with memory use,
  variable length instructions were used.
• Register based instructions were short, 1-2
  bytes, while memory based instructions were long,
  up to 5 bytes.
• Packing such variable length instructions into a
  fixed-length memory requires some very special
  decoding circuits.

26
CISC Characteristics

• Instructions in typical CISC processors provide
  for direct manipulation of operands in memory.
• This will require multiple memory references
  during the execution of the instruction.
• The reason for including these instructions is to
  simplify the compilation of high-level language
  programs.
• Remember, most variables in a high-level language
  program are implemented as memory locations.
• As more instructions and addressing modes are
  added to a processor, more logic would be needed
  to support them.
• Ultimately, this leads to a lower performance.

27
CISC Characteristics in Summary

• A large number of instructions.
• Typically 100 200 instructions.
• Some instructions that perform specialized tasks
  and are used infrequently.
• A large variety of addressing modes.
• Variable length instruction formats.
• Instructions that manipulate operands in memory
  directly.

28
RISC Characteristics

• RISC tries to reduce execution time by
  simplifying the instruction set of the computer.
• The basic characteristics of RISC processors are
• Relatively few instructions.
• Relatively few addressing modes.
• Memory access limited to load and store
  instructions.
• All operations are done within the registers of
  the CPU.
• Fixed-length, easily decoded instruction formats.
• Single cycle instruction execution.
• Hardwired rather than micro-programmed control
  units.

29
RISC Characteristics

• Mostly register to register operations.
• Only simple load and store for memory access.
• Operands are read into registers using a load
  instruction.
• The operation is done between the registers.
• Results are stored in memory using an explicit
  store instruction.
• This simplifies the instruction set and forces
  the optimization of register usage.
• This also removes the need for many complex
  addressing modes.

30
RISC Characteristics

• Simple instruction formats.
• The instruction length is fixed.
• Instructions are aligned to memory words.
• Easy to decode instruction formats.
• This simplifies the control logic.
• Hard-wired control is used to speed-up the
  generation of control signals.

31
Single Cycle Instruction Execution

• A main feature of RISC processors is their
  ability to complete the execution of an
  instruction every clock cycle.
• This is done by overlapping the fetch, decode and
  execute cycles of two or three instructions by
  using pipelining.
• Most CISC processors today also depend on this
  important feature for speeding up their
  performance.

32
Additional Features of RISC Processors

• A relatively large number of registers.
• This would be useful for storing intermediate
  results.
• Use of overlapped register windows.
• This helps speed-up procedure calls.
• Compiler support for efficient translation of
  high-level language programs to make use of these
  features.

33
Over-lapped Register Windows

• When a function call in a high-level language
  program requires many operations to implement
• Register values in the calling program must be
  saved.
• Parameters must be placed into appropriate
  registers for the subroutine.
• The subroutine is called.
• On the return path, a similar set of operations
  are needed.
• The subroutine has to save its return values in
  the appropriate registers.
• Control is returned to the calling program.
• Registers values in the calling program are
  restored.
• All of these are very time consuming.

34
Over-lapped Register Windows

• Given that function calls occur very often in
  high-level language programs, someway of speeding
  up this process has to be found.
• Some processors use a separate register bank for
  each procedure.
• No need to save and restore the calling
  procedures registers.
• RISC processors do a similar thing but it is not
  dedicated.

35
Over-lapped Register Windows

• Each procedure is allocated a group of registers.
• When a function call is being executed, a set of
  registers are automatically assigned to the new
  procedure.
• Therefore, there is no need to save and restore
  the calling procedures registers.
• This new set of registers overlaps by a certain
  amount with the registers of the calling
  procedure.
• This overlap is used for passing parameters.
• When a function is terminated, the registers
  allocated to it are freed for later use by a
  different procedure.

36
Over-lapped Register Window Example
R0

• Our CPU has a total of 74 registers.
• When a program starts, 10 registers are allocated
  for global data.
• The main program is allocated 10 registers for
  its local data.
• The main program calls function A.
• 6 registers are allocated for passing data back
  and forth between main and A.
• 10 registers are allocated to A for local data.
• A calls B.
• 6 registers are allocated common to A and B.
• 10 registers are allocated to B for local data.
• Each procedure can access a total of 32 registers.

Global Reg.
R9
R10
Main Local Reg.
R19
R20
Shared Main, A
R25
R26
A Local Reg.
R35
R36
Shared A, B
R41
R42
B Local Reg.
R51
R52
Free Reg.
R73
37
Over-lapped Register Window Example
R15 R10 R73 R64
Common to D and A
Local to D
R63 R58
Common to C and D
R57 R48
Proc D
Local to c
R47 R42
Common to B and C
R41 R32
Proc C
Local to B
R31 R26
Common to A and B
R9 R0
R25 R16
Proc B
Common to all procedures
Local to A
R15 R10
Common to A and D
Proc A
Global registers
38
Effects on Programming

• High level languages no effect.
• All of this is done by the compiler.
• Assembly language registers no longer have a
  set name.
• If you write an instruction of the form
• ADD R1, R2
• there is no guarantee that you will actually use
  R1 and R2 of the processor.
• The above instruction means, use the first
  register and the second register in my window.

39
Over-lapped Window Parameters

• The number of registers allocated for each type
  is a parameter of the processor design.
• G the number of global registers.
• L the number of local registers.
• C the number of common register.
• W the number of windows
• Window size L 2C G
• Registers in the processors (L C)W G (reg.
  file)
• all of these depend on the design of the CPU.
• G 10, L 10, C 6 , W 4
• 101210 32 reg. register file (106)x4 10
  74
• In some processor designs, these parameters are
  decided dynamically.
• Depending on the total number of procedures and
  the total number of registers, a procedures
  window size may change.
• The operating system now has to be very
  intelligent.

40
Berkeley RISC I Example RISC CPU

• 32-bit processor.
• 32-bit address.
• 8, 16, or 32-bit data.
• 32-bit instruction format.
• 31 instructions.
• 12 Data Manipulation.
• 11 Data Transfer.
• 8 Program Control.

• 3 addressing modes
• Register.
• Immediate.
• Relative to PC.
• 138 registers.
• 10 Global registers.
• 8 windows of 32 registers each.

41
Berkeley RISC I

• Since only 32 registers are accessible at any
  point in time, only 5 bits are needed for
  register selection.
• Instructions utilize a three address format.
• Destination Register.
• Source Register.
• Second Source Register or Immediate Data.
• Register R0 is a constant 0 all the time.
• It can be used to fool the processor into
  performing additional addressing modes.

42
Instruction Formats
Register Mode
S2
Not Used
0
Rs
Rd
Opcode
5
8
1
5
5
8
S2 - Register
Register-Immediate Mode
S2
1
Rs
Rd
Opcode
13
1
5
5
8
S2 Immediate Data
Signed-extended 13 bit const
PC Relative Mode
Y
Cond
Opcode
19
5
8
Y Relative Displacement
43
Instruction Formats

• Memory access instructions use Rs to specify a
  32-bit address in a register and S2 to specify an
  offset
• R0 contains all 0s (zero quantity)
• COND field replaces the Rd field for jump
  instructions (specify one of 16 possible branch
  conditions)

44
Instruction Formats

• ADD R22,R21,R23 R23 ? R22 R21
• ADD R22,150,R23 R23 ? R22 150
• ADD R0,R21,R22 R22 ? R21 (MOVE)
• ADD R0, 150,R22 R22 ? 150(Load immed)
• ADD R22, 1,R22 R22 ? R22 1 (Inc)
• LDL (R22) 150,R5 R5 ? MR22 150
• LDL (R22) 0,R5 R5 ? MR22
• LDL (R0) 500,R5 R5 ? M500

45
Data Transfer Operations
46
Data Manipulation Operations
