Title: Fireboats 2004


1
1
Fireboats 2004
2
History overview
Fireboats
  • 1906 Earthquake
  • 1909 Fireboats
  • Scannell and Sullivan
  • 1954 Fireboat Phoenix
  • 1984 Engine 35 arrives
  • 1989 Earthquake
  • 1990 Fireboat Guardian

2
Fireboats 2004
3
History
Dennis T. Sullivan David Scannell
1909 1954
3
Fireboats 2004
4
History
Phoenix
1954 present
4
Fireboats 2004
5
History
Engine 35
1984 present
5
Fireboats 2004
6
History
1989 Earthquake
6
Fireboats 2004
7
History
1989 Earthquake
Fireboat Phoenix saves the Marina.
7
Fireboats 2004
8
History
Fireboat Guardian
1990 present
8
Fireboats 2004
9
Mission
Phoenix Guardian
  • AWSS (augmented water supply system)
  • Fire suppression
  • Rescue
  • Dewatering
  • Port security (OES)

9
Fireboats 2004
10
Fire Suppression
Phoenix Guardian
  • Fire Suppression for the Port and City of San
    Francisco
  • Provide mutual aid to the Bay Area
  • Major oil refineries (Chevron Tosco)
  • Port of Oakland (Oakland Fireboat out of service)

10
Fireboats 2004
11
Pumping Capacity
Phoenix 9,600 GPM _at_ 125 PSI Guardian
24,000 GPM _at_ 125 PSI
11
Fireboats 2004
12
Pumping Platform
High Pressure Manifold System
  • 5 manifolds on the waterfront
  • 10, 3 inch connections on each manifold
  • Pump in Series 150 150 300 PSI output
  • Computerized control valve system

12
Fireboats 2004
13
Pumping Platform
Portable Hydrant System
  • 4 Hose Tenders carry 4,000 feet of 5 inch hose.
  • Services nine miles of SF waterfront.
  • Saved the Marina in 1989.
  • Provides water to low hydrant volume areas such
    as
  • Hunters Point, the Naval Shipyard and 3-Com
    Park area.

13
Fireboats 2004
14
CO2 System
Phoenix Guardian
  • Phoenix 1,000 lbs. of CO2
  • Guardian 1,000 lbs. of CO2

14
Fireboats 2004
15
Foam System
Phoenix Guardian
  • Phoenix 750 gals. of AFFF (15 mins.)
  • Guardian 1,500 gals. of AFFF (30 mins.)

15
Fireboats 2004
16
Water Tower
Phoenix Guardian
  • Phoenix tower extends
  • up to 48 feet above water line.
  • Guardian has a fixed tower
  • 40 feet over water line.
  • Pier structure fires
  • Ship fires

16
Fireboats 2004
17
Under the Pier Monitors
Phoenix Guardian
  • Straight stream
  • Fog stream
  • Very effective for pier fires
  • China Basin fire (2 passes and it was out!)

17
Fireboats 2004
18
Rescue
Engine 35 (1 Officer, 3 Firefighters)
  • Trained fire personnel operate
  • monitors and all firefighting
  • and rescue equipment.
  • Qualified swimmers
  • EMTs
  • Skiff operators
  • Deck hands / line handlers

18
Fireboats 2004
19
Rescue
Rescue Platform
  • Provides a working platform for
  • Rescue Units 1 2 and Fireboats rescue work.

19
Fireboats 2004
20
Rescue
Inflatable Life Ring, 50 ft. x 3 in. line
  • Plane down, vessel accidents
  • Many people in the water

20
Fireboats 2004
21
Rescue
Skiff Operations
  • Body retrieval and water rescue

21
Fireboats 2004
22
Rescue
Skiff Operations
  • Under pier fires
  • Fast medical response with skiff

22
Fireboats 2004
23
Rescue
Dewatering
  • Saves sinking vessels and houseboats
  • Water eductors and electrical submersible pumps

23
Fireboats 2004
24
Public Relations
Displays
  • Welcoming vessels to the Port of San Francisco
  • Military and Cruise ships
  • Leading parades
  • Opening of Yacht Season and Fleet Week, etc.

24
Fireboats 2004
25
Conclusion
SFFD Fireboats are crucial to the safety of the
Port and City of San Francisco.
25
