The Hematopoietic

1
The Hematopoietic Lymphatic Systems

• Dr. Imran Mirza
• Department of Laboratory Medicine Pathology
• University of Alberta

2
LEARNING OBJECTIVES

• Following this lecture you will be able to
• List the major constituents of blood
• Explain the principles by which anemias are
  classified
• Describe the cause and features of infectious
  mononucleosis
• List the malignancies of blood cells

3
COMPOSITION OF BLOOD

• 1. Plasma component
• 2. Cellular component

4
BLOOD PLASMA COMPONENTS

• Water
• Dissolved ions
• Proteins
• Albumin, transferrin,
• haptoglobin, transcobalamin,
• lipoproteins, coagulation proteins,
• immunoglobulins, complement,
• growth factors, hormones, cytokines.

5
(No Transcript)
6
BLOOD CELLS

• Erythrocytes (aka. red blood cells)
• Oxygenation of the tissues
• Leukocytes (aka. white blood cells)
• Granulocytes are involved in phagocytosis and
  destruction of microbial invaders
• Lymphocytes exert immunoregulatory control and
  produce immunoglobulins and cytokines
• Thrombocytes (aka. platelets)
• Essential for coagulation

7
(No Transcript)
8
HEMATOPOIETIC SYSTEM

• Primary Organs
• 1. Bone marrow
• 2. Thymus
• Secondary Organs
• 1. Spleen
• 2. Lymph nodes

9
BONE MARROW
10
(No Transcript)
11
BONE MARROW STEM CELLS
Hematopoietic Stem Cell
Self-renewal
Apoptosis
Lineage Commitment
Multilineage Early, Late Progenitor Cells
12
(No Transcript)
13
(No Transcript)
14
HEMATOPOIETIC SYSTEM

• Primary Organs
• 1. Bone marrow
• 2. Thymus
• Secondary Organs
• 1. Spleen
• 2. Lymph nodes

15
(No Transcript)
16
(No Transcript)
17
(No Transcript)
18
Simplified Approach to Blood Disorders

• Cells and proteins in blood can be
• Increased
• Decreased
• Functionally abnormal

19
RED BLOOD CELLS

• Devoid of a nucleus and intracellular organelles.
• Glycolysis is the main energy source.
• Lifespan of 120 days.
• Shape allows
• increased surface area for gas exchange
• deformability for passage through capillaries

20
RETICULOCYTES

• Stage just before full maturation.
• Polychromatophilic.
• Larger than mature RBCs.
• Retic 0.4-2.0
• Absolute 20-90 x 109/L

21
COULTER INSTRUMENT FOR Complete Blood Count (CBC)
22
x 109/L
x 1012/L
g/dL

fl
pg
g/L

x 109/L
23
HEMOGLOBIN (HGB)

• 90 of dry weight of red cells
• 2 pairs of polypeptide chains
• In adults, 2 alpha and 2 beta globin chains form
  a tetramer (?2?2).
• Each chain binds noncovalently with a single heme
  molecule which is responsible for transporting an
  oxygen molecule

24
HEMOGLOBIN
25
RBCs/HGB INCREASED (polycythemia)

• Polycythemia - increased hemoglobin and RBC mass
• Causes of Polycythemia
• 1. Primary malignant (Polycythemia vera)
• 2. Secondary
• Hypoxia (i.e. altitude, smoking, etc.)
• Increased erythropoietin secretion/renal lesions

26
RBCs/HGB DECREASED (anemia)

• Can approach in two major ways
• 1. Morphologic
• 2. Etiologic
• Morphologic approach requires
• MCV, RDW and a peripheral smear
• Etiologic approach
• Clinical history, reticulocyte count

27
MORPHOLOGIC CLASSIFICATION OF ANEMIA

• 1. Normochromic Normocytic
• N MCV MCH
• examples hemolysis, blood loss
• 2. Hypochromic Microcytic
• ? MCV MCH
• example iron deficiency
• 3. Macrocytic
• ? MCV N MCH
• examples Vitamin B12 deficiency, folate
  deficiency, liver disease

28
ETIOLOGIC CLASSIFICATION OF ANEMIA
? Reticulocytes

• 1. Increased Loss or Destruction
• A. Hemorrhage
• B. Hemolysis
• 2. Decreased Production
• A. Nutritional deficiencies (Fe, B12, Folate,
  etc.)
• B. Stem Cell Disorders
• C. Anemia of Chronic Disease
• D. Marrow Failure - due to marrow replacement or
  loss

? Reticulocytes
29
IRON METABOLISM
Circulating erythrocytes
Marrow erythroid precursors
RES stores
Liver
Plasma transferrin iron
Intestinal absorption
30
Microcytic Hypochromic Anemia
31
Koilonychia Brittle spoon shaped nails
32
Glossitis Inflammation of the tounge
33
Laboratory Evaluation of Iron Deficiency Anemia

• RBC Size and Shape/Hgb content
• Microcytic and hypochromic
• Reticulocyte Production
• Low
• Clinical Circumstances
• Chronic blood loss, poor dietary intake
• Additional Tests Useful in Diagnosis
• Low serum iron low serum ferritin

34
(No Transcript)
35
(No Transcript)
36
Macrocytic Anemia Hypersegmented Neutrophil
37
Laboratory Evaluation of Anemia from B12
Deficiency

• RBC Size/Hgb content
• Macrocytic
• Reticulocyte Production
• Low
• Clinical Circumstances
• ? absorption or intake ? degradation
• Additional Tests Useful in Diagnosis
• ? serum vitamin B12 hypersegmented
  neutrophils antiparietal cell Abs /or anti-IF
  Abs

38
Laboratory Evaluation of Folate Deficiency Anemia

• RBC Size/Hgb content
• Macrocytic
• Reticulocyte Production
• Low
• Clinical Circumstances
• ? absorption or intake ? degradation drugs
  dialysis
• Additional Tests Useful in Diagnosis
• ? RBC folate hypersegmented neutrophils

39
B12 AND FOLATE DEFICIENCY

• B12 deficiency in adults causes irreversible
  neurological damage in adults
• Folate deficiency does not result in neurological
  damage in adults.
• Folate deficiency in an expecting mom causes
  neural tube defects in the baby.

40
Neural Tube Defect Folate Deficiency
41
Iron, Vitamin B12 and Folate

• Nutrient Daily Requirement Body Reserve
• Iron 1 mg depends
• Vitamin B12 1 mg 2-5 years
• Folate 50-100 mg 2-5 months

42
HEREDITARY HEMOLYTIC ANEMIAS

• Abnormal shaped cells e.g. Hereditary
  spherocytosis
• Abnormal hemoglobin e.g. Sickle cell disease
• Defective hemoglobin synthesis e.g. thalassemia
• Enzyme deficiencies e.g. G6PD

43
HEREDITARY HEMOLYTIC ANEMIASHEREDITARY
SPHEROCYTOIS
44
HEREDITARY HEMOLYTIC ANEMIASSICKLE CELL ANEMIA
45
(No Transcript)
46
(No Transcript)
47
HEREDITARY HEMOLYTIC ANEMIASGlucose 6-phosphate
Dehydrogenase Deficiency

• ? RBC ability to reduce powerful oxidants.
• O2- and H2O2 denature Hgb, which then forms
  insoluble aggregates or Heinz bodies.
• Heinz bodies attach to RBC membrane compromising
  deformability.
• RBCs are hemolyzed by liver and spleen.

48
(No Transcript)
49
HEREDITARY HEMOLYTIC ANEMIASGlucose 6-phosphate
Dehydrogenase Deficiency

• G6PD gene is present on the X chromosome.
• Full expression of disease in males
• Partial expression in heterozygote females.
• Many drugs can cause clinically significant
  hemolytic anemia in G6PD deficiency.

50
ACQUIRED HEMOLYTIC ANEMIASDrug Induced Immune
Hemolysis

• 1. Adsorption of immune complexes to RBC membrane
• IgM and complement are involved.
• e.g. sulfonamides, quinine, rifampin.
• 2. Adsorption of drug to red cell membrane
• IgG and splenic macrophages are involved.
• e.g. penicillin and cephalosporin.
• 3. Induction of autoantibody
• e.g. methyldopa.

51
LEUKOCYTES

• Neutrophils
• Eosinophils
• Basophils
• Monocytes
• Lymphocytes

52
BAND SEGMENTED NEUTROPHILS

• Bands U-shaped or deeply indented nucleus. The
  chromatin is heavily clumped.
• Neutrophil Definite lobation with thin
  thread-like filaments of chromatin joining the
  2-5 lobes.

53
NEUTROPHILS INCREASED

• Neutrophilia is gt7.5 x 109/L neutrophils.
• Reactive Neutrophilia
• Bacterial infections
• Inflammation e.g. collagen diseases
• Trauma/surgery
• Malignancy e.g. Chronic neutrophilic leukemia

54
NEUTROPHILS DECREASED

• Neutropenia is defined as lt1.5 x 109/L
  neutrophils in the peripheral blood.
• lt1.0 x 109/L neutrophils - ?ability to fight
  infection.
• Agranulocytosis (lt 0.5 x 109 /L).
• The causes of leukopenia may be
• peripheral destruction
• shift into the storage or marginated
  compartments.
• marrow failure

55
EOSINOPHILS

• Large cells with nuclear characteristics
  identical to neutrophils
• Abundant cytoplasm filled by large uniform,
  coarse, orange-red granules.

56
EOSINOPHILS INCREASED

• Eosinophilia (gt0.6 x 109/L)
• Reactive Eosinophilia
• allergic and hypersensitivity reaction
• drug reactions
• invasive parasitic infections
• Malignancy e.g. Chronic eosinophilic leukemia

57
BASOPHILS

• Least numerous granulated cells within the
  peripheral blood.
• Dense purple specific granules, of different size
  and shapes frequently overlay and obscure the
  nucleus.

58
MONOCYTE

• The mature cell is slightly larger than the
  neutrophil.
• The nuclear chromatin is less condensed than the
  neutrophil and has a lacy appearance.
• May contain granules and vacuoles.

59
LYMPHOCYTES

• Lymphocytes differentiate and mature in thymus (T
  cells) and bone marrow (B cells).
• Lymph nodes, spleen, and RES are also involved.
• Majority of peripheral blood lymphs are T cells
  (70).

60
LYMPHOCYTES INCREASED

• Lymphocytosis (gt4.0 x 109/L)
• Reactive Lymphocytosis
• infectious mononucleosis, caused by Epstein-Barr
  Virus
• other viral infections
• drug reactions
• whooping cough
• Malignancy e.g. Chronic lymphocytic leukemia

61
Jonathan Epstein
Yvonne Barr
62
(No Transcript)
63
Oropharynx
Incoming virus
Virus egress into saliva
B-cell
Productively infected cells release virus
Crypt lumen
Infected B-cells home to tonsillar crypts
Proliferation of infected cells
Blood Stream
64
INFECTIOUS MONONUCLEOSIS
Patients,
35 Years and Younger
40 Years and Older
Feature
Lymphadenopathy
94
47
Pharyngitis
43
84
Fever
95
76
Splenomegaly
33
52
Hepatomegaly
42
12
Rash
12
10
27
Jaundice
9
65
INFECTIOUS MONONUCLEOSISCLINICAL FEATURES
66
INFECTIOUS MONONUCLEOSISATYPICAL LYMPHOCYTES
67

• LEUKEMIA
• MYELOID LYMPHOID
• Acute Chronic Acute Chronic

Pre-leukemia (myelodysplastic syndromes)
68
(No Transcript)
69
ACUTE LEUKEMIA
Blast Cells gt20 in Blood or Bone Marrow
70
ACUTE LEUKEMIAEPIDEMIOLOGY

• AML
• Age-specific incidence rate increases with age.
• 80-90 of acute leukemias in adults are AML.
• ALL
• Age-specific incidence rate peaks between ages
  2-10 years, declines, and then rises after age
  55.
• 80-85 of acute leukemias in children are ALL.

71
ACUTE LEUKEMIACLINICAL FEATURES

• 1. Bone marrow replacement
• ?RBCs - pallor, weakness, fatigue
• ?WBCs - fever, chills, infections
• ? Platelets - petechiae, bruising, bleeding
• 2. Tissue infiltration
• Enlarged liver, spleen, lymph nodes etc.

72
Severe thrombocytopenia with petechial hemorrhages
73
Staphylococcus aureus infection in AML
74
Bilateral viral pneumonia in a child with AML
75
12-year-old girl with AML
76
41-year-old man with AML
77
Leukemic cell infiltration in gums in AML
78
Mediastinal widening in a 4-year-old boy with ALL
79
CHRONIC LEUKEMIACHRONIC LYMPHOCYTIC LEUKEMIA
80
CHRONIC LEUKEMIACHRONIC MYELOID LEUKEMIA
