Title: FPGA CAD


1
FPGA CAD
10-MAR-2003
2
Content
  • FPGA CAD design flow
  • Placement
  • Routing.
  • (top ten hottest VLSI CAD problems)

3
FPGA Design Flow
  • Designing with FPGAs is much like the ASICs
    technology.
  • The Computer Aided Design (CAD) software provided
    by the FPGA vendor or third part is used to
    convert the given digital circuit (schematic or a
    high level description in VHDL or Verilog) into a
    stream of bits, which is then used to download to
    the FPGA.

4
CAD Tools
MaxPlus
5
A Typical FPGA CAD Flow
Design Entry
Logic Optimization
Synthesis
Mapping to k-LUT
Packing LUTs to CLBs
Placement
Routing
Download to FPGA
Simulation
6
Placement Find home for CLBs.
7
Problem define
  • Assign position(X, Y) to modules
  • Placement to minimize
  • total wirelength
  • critical path wirelength
  • a combination of them.
  • Estimated model
  • Circuit quality is determined by placement
    routing
  • Routing is a NP-hard problem.
  • NP-hard problem. (n!)
  • Time is a big issue.
  • Quality and time tradeoff.

8
circuit before placement
9
circuit after placement
10
Heuristic method
  • Constructive methods
  • Partitioning method min-cut
  • Clustering.
  • Iterative improvement
  • Begin with a random or constructive placement
  • Iterate to improve it
  • Force directed method
  • Simulated annealing.
  • Other method
  • Genetic algorithm

11
Min-Cut
Minimize cuts during partition
12
Force directed method
  • Classical mechanics
  • Using Hookes law
  • Force vector computed on each module
    corresponding to all nets connections
  • Solve a set of non-linear differential equations.

force
13
Simulated annealing
  • Generates best results (industry standard)
  • Run time is a issue.
  • Model a physical annealing process.
  • VPR placer (placement tools available to us,
    developed in UoT).

14
Physical Annealing
  • Take a metal and heat to high temperature until
    liquidized
  • Allow it to cool slowly, metal is annealed to a
    low temperature
  • Atoms in the metal are at transfer from high
    energy states to low energy states
  • Can accept bad moves to get global minima.
  • Avoid getting trapped in local minima.

15
Comparison
16
Routing-Find the path
  • Maze routing
  • Pathfinder.

17
Routing Resource
Connection Block
Switch Block
18
Typical Connection
19
Maze router
20
Pathfinder router
  • Based on maze router
  • Shows very high quality results
  • Negotiation-based router
  • Each net negotiates the use of shared resources
    with other nets until none of the resources are
    shared
  • Extra weights are added to shared resources.
  • VPR router

21
Comparison
22
Questions
23
Placement Routing
24
Design Entry
  • The description of a logic circuit can be entered
    by using a schematic capture program
  • VHDL and Verilog interpreter.

25
Synthesis
  • A circuit description such as VHDL, is first
    converted to a netlist of basic gates. This
    process called synthesis.

26
Logic Optimization
  • technology independent
  • Improve circuit, while keep functionality
    correct

27
Mapping to LUTs
  • The gates then are mapped into k-input lookup
    tables (LUT). (most basic brick of FPGA)
  • Chortle. (available to academic, developed in
    UoT)

28
Packing LUTs into CLBs
  • Configurable Logic Block (CLB)
  • Grouping the LUTs into CLBs
  • Simi liar to circuit clustering.
  • Vpack. (available to academic, developed in UoT)

29
Placement
  • Placement is to determining the physical location
    of each CLBs on the FPGA

30
Routing
  • Realize connections among the CLBs by selecting
    routing resource.
  • wire segments and
  • routing switches.

31
Simulation
  • After placement and routing, the implemented
    design is simulated to ensure its functioning and
    to verify the timing issues.
  • Design errors can be found and corrected at this
    stage.

32
Download bits file to FPGA
  • Once all the necessary steps are completed for
    implementing the design, the CAD system can
    download the result to the programming unit that
    is used to configure the FPGA
  • After this stage, the programmable device is
    configured and ready for use.
