SCC Afferents

• Kim McArthur
• Vestibular Classics
• November 3, 2006

2
Overview

• Review SCC Mechanics
• Afferent Peripheral Morphology
• Afferent Physiology
• Proposed Mechanisms

3
ReviewSCC Mechanics
P endolymph displacement
Q head/canal displacement
Initial Position
CW moment IPaccel ? like ma
CCW moments B(Qvel-Pvel) ? viscosity
of endolymph (damping) K(QP) ? elasticity of
cupula (spring)
G. Melvill Jones (1972)
4
ReviewSCC Transfer Function

• Q-P (s) ___aT1T2s____
• Qvel (T1s1)(T2s1)
• T1gtgtT2
• T1 B/K T2 I/B T1T2 I/K

5
ReviewSCC Transfer Function

• HF range (?gt1/T2)
• ? responsive to angular position (dominated by
  inertia)
• MF range (1/T1lt?lt1/T2)
• ? responsive to angular velocity (dominated by
  endolymph viscosity)
• LF range (?lt1/T1)
• ? responsive to angular acceleration (both
  dominated by cupular elasticity)

1/T2
1/T1
G. Melvill Jones (1972)
6
Peripheral Morphology
Dickman in Fundamental Neuroscience, 2nd ed.
(2002)
7
Peripheral Morphology
Dimorphic/HC/Intermed
Dimorphic/HC/R
Calyx/HC/I
Bouton/AC/R
Dimorphic/AC/I
Baird et al 1988
8
Peripheral Morphology
Haque, Huss Dickman (2006)
9
Physiology

• Spontaneous discharge
• Spatial tuning
• Discharge regularity
• Sensitivity to galvanic stimulation
• Adaptation to constant velocity
• Dynamics (transfer function)

10
PhysiologySpontaneous Discharge
Goldberg Fernandez 1971
11
PhysiologySinusoidal Response
Goldberg Fernandez 1971
12
PhysiologySinusoidal Response
Goldberg Fernandez 1971
13
PhysiologySpatial Tuning
Haque, Angelaki Dickman 2004
14
PhysiologySpatial Tuning
Haque, Angelaki Dickman 2004
15
PhysiologyDischarge Regularity
Goldberg Fernandez 1971
16
PhysiologyDischarge Regularity
Goldberg Fernandez 1971
Baird et al 1988
17
PhysiologyCV Galvanic Sensitivity
Baird et al 1988
18
PhysiologyCV Gain/Phase
Haque, Angelaki Dickman 2004
Baird et al 1988
19
PhysiologyAdaptation
Goldberg Fernandez 1971
20
PhysiologyDynamics
Goldberg Fernandez 1971
21
PhysiologyDynamics
Goldberg Fernandez 1971
22
PhysiologyDynamics
Haque, Angelaki Dickman 2004
Baird et al 1988
23
To re-cap

• Morphology
• Type I hair cells calyx ( dimorphic) afferent
  terminals in the central zone
• Type II hair cells bouton ( dimorphic)
  afferent terminals in the peripheral zone

24
To re-cap

• Physiology
• Cosine tuning to canal planes
• Discharge regularity (CV) varies across the
  population
• Dynamics may differ from prediction based on
  torsion-pendulum model of SCC mechanics
• Adaptation ? low-frequency phase lead
• Cupular velocity sensitivity ? high-frequency
  phase lead and gain enhancement

25
MechanismsCo-variation of Properties

• Irregular afferents
• Calyx/dimorphic terminals in the central zone
• Phasic-tonic response dynamics (adaptation
  cupular velocity sensitivity)
• Large responses to efferent fiber stimulation
• Large, low threshold responses to galvanic
  stimulation

• Regular afferents
• Bouton/dimorphic terminals in the peripheral zone
• Tonic response dynamics (resemble expectation
  from canal dynamics)
• Small responses to efferent fiber stimulation
• Small, high threshold responses to galvanic
  stimulation

26
MechanismsDischarge Regularity

• Compartmental cable calculations indicate that
  electronic distance has only a small effect on
  discharge regularity
• Dimorphic units with similar terminal branching
  patterns may be regular or irregular
• ? Terminal branching pattern is not causally
  related to discharge regularity (may be causally
  related to location of the terminal within the
  neuroepithelium)

Baird et al 1988
27
MechanismsDischarge Regularity

• General Model
• Variability in the SD of ISI due to
• Synaptic noise
• Slope of the recovery function
• Galvanic sensitivity will be tied to the recovery
  function, but will be independent of synaptic
  noise

Goldberg, Smith Fernandez 1984
28
MechanismsDischarge Regularity

• Prediction If the shape of the recovery
  function is an important contributing factor in
  discharge regularity, then CV should correlate
  with galvanic sensitivity.
• ? Irregular afferents will have higher
  sensitivity to galvanic stimulation

Goldberg, Smith Fernandez 1984
29
MechanismsDischarge Regularity

• Afferent irregularity is causally related to its
  post-spike voltage recovery function
• (Irregular afferents have faster recovery, due to
  a smaller, more rapidly decaying K AHP)

Goldberg, Smith Fernandez 1984
30
Therefore
31
MechanismsResponse Dynamics

• Dynamics in response to galvanic currents are
  similar for regular and irregular afferents
  (Goldberg, Fernandez Smith 1982)
• Dynamics in response to natural stimulation
  differ (as previously shown)
• Dynamics do not arise from the same mechanism as
  discharge regularity
• Dynamics arise from transduction prior to the
  afferent spike encoder (probably during hair cell
  transduction)

32
MechanismsSynaptic Gain

• Synaptic gain system gain / encoder gain
  (galvanic sensitivity)
• Bouton and dimorphic afferents have higher
  synaptic gains than calyx units, possibly due to
  the low input impedance of type I hair cells
• ? Synaptic gain is causally linked to hair cell
  innervation (calyx units innervate type I hair
  cells lower gain)

33
Therefore
34
SUMMARY

• Afferent discharge regularity and galvanic
  sensitivity are determined by the slope of the
  recovery function (K AHP), which may be
  determined by location within the crista
• Peripheral zone slow recovery regular
• Central zone fast recovery irregular
• Synaptic gains are determined by hair cell
  innervation
• Type I HC (calyx) low synaptic gains
• Type II HC (bouton) higher synaptic gains
• Response dynamics are probably determined by hair
  cell transduction (either intrinsic to the HC or
  characteristic of the synapse)
• Regular afferents tend to have more canal-like
  dynamics
• Irregular afferents exhibit more adaptation
  (low-frequency phase lead) and more cupular
  velocity sensitivity (high-frequency phase lead
  and gain enhancement)
• HOWEVER dynamics are not determined by the
  recovery function, but by some correlated
  property prior to the spike encoder

35
Some Notes on Function

• Most secondary neurons receive mixed regular and
  irregular input
• VOR Driven by regular afferents, modified by
  irregular afferents (?)
• VCR Driven by irregular afferents (?)
