Taverna and BioMOBY

1
Taverna and BioMOBY

• Savita Shrivastava
• Lab presentation
• September 16th, 2005

2
A Life Science Scenario
GeneID
Over expressed genes
DNA Sequence
Microarray data
Protein Sequence

• "To answer most interesting biological problems,
  you need to combine data from many data sources,"

3
A Life Science Scenario contd.

• Repeat the discovery process
• The same chain of services to be applied to
  different data sets
• Publish the methodology
• Preserve as much information about how services
  were used
• Trace the data to support a conclusion

4
The Problem

• Finding the available resources on the web
• What and who?
• How to use it?
• What Input and output data types?
• How to create an analysis pipeline (take the
  output from one analysis and send it to another
  resource/website for further analysis)?

5
The Problem contd.

• Diversity and complexity of information
• Data-intensive
• Compute-intensive
• Diversity and autonomy of the biological
  community
• Currently 5000 public data repositories and
  applications
• Different formats, interfaces, structures, and
  coverage
• Reliability

6
The Problem contd.

• Writing scripts

Code for translation of a DNA sequence
7
The Problem contd.
Code for getting Secondary Structure
8
The Problem contd.
Code for Signal peptide and Transmembrane region
prediction
9
The Problem contd.
Code for creating analysis pipeline
10
The Solution - Workflow Techniques

• What is a workflow?
• A set of components/services and relation between
  them
• Defines a complex process from simple building
  blocks
• Transfers information from the output of one
  component to the input of another

11
Terminology

• What is a Component?
• Any command line analysis tool or
• A script written in any programming language
• Consumes an input and produce an output
• What are Services?
• All services are also Component
• Components hosted on remote machine and
  accessible through internet

12
Advantage of Workflow Technology

• Analysis processes in a structured, repeatable
  and verifiable way
• Applications are centralized to a common
  interface
• Automate the high through put data analysis to
  accelerate the pace and reduce overall costs

13
Advantage of Workflow Technology

• Users are freed from component management
• No high performance computing hardware
• Provenance
• Who, what, where, why, when, how?
• The traceability of knowledge as it is evolves
  and as it is derived.
• Implications for recording which services invoked
  on what data, when with what parameters.
• No programming and command line work, just mouse
  clicks and Drag and Drop

14
Taverna Workbench

• Designed for a biologist
• Allow users to construct complex analysis
  workflows
• Components are located in both remote and local
  machine
• Implicit iteration support

15
Taverna Workbench

• Result browsing and data encapsulation
• Provenance recording
• Fault tolerance features

16
Availability

• http//taverna.sourceforge.net/
• Available for Windows, Linux, Mac and Sun
• Download and unzip the file
• Requires Java (1.4 and above) to run
• Tutorial is available on website.

17
Workbench Window
18
Advanced Model Explorer Window
19
Available Services
20
Workflow Diagram
21
Run Workflow
22
Enactor Invocation
23
Enactor Invocation-Result
24
Enactor Invocation-Report
25
BioMOBY Services in Taverna

• http//www.biomoby.org
• gt230 services registered and growing!!!
• 70 independent service providers
• List and details of all the MOBY services on-
• http//mobycentral.icapture.ubc.ca/cgi-bin/list.se
  rvices.cgi

26
What is BioMOBY?
27

• Information discovery system
• Discovers and retrieves related piece of data
  from multiple hosts and services
• Provides a common format for the retrieved data
  representation regardless of its origin.

28
Three Components of MOBY

• MOBY-Central
• MOBY-Servers
• MOBY-Clients

29
MOBY-Central(A central registry of the services)

• Responsible for cataloguing the services provided
  by all MOBY-Servers
• Respond to queries about these services from
  MOBY-Client
• MOBY-Central stores only the information about
  the services available, and the URL of the
  service specification

30
MOBY-Servers(Provide one or more services)

• Create a service e.g. database lookup
  retrieval, sequence alignment, Blast homology
  search, etc.
• MOBY-Servers register themselves with
  MOBY-Central as providing service X using
  input(s) Y and generating output(s) Z.

31
MOBY-Clients(The end-users computer )

• Identify type of data
• Generate the query to MOBY-central
• Receives the list of potential services and
  returned data types,
• Selection of the desired service.
• Initiates contact with the service, submits a
  properly formatted query, and receives/interprets
  the service response.

32
(No Transcript)
33
MOBY uses ontology

• Object ontology types of input/output objects
• Service ontology types of services
• - Analysis
• - Parsing
• - Registration
• - Retrieval
• - Resolution
• Service relationships
• Service lt-- Analysis lt-- Alignment
  lt-- BLAST lt--

WU BLAST NCBI BLAST
34
What does MOBY provide?

• A library that makes it easy to write new web
  services
• A library of calls to discover existing services
  according to
• The name of the service
• What input is required
• What output is produced
• Keywords in the description of the service
• Who wrote the service
• Calls to register new data types, existing types
  include
• GenericSequence
• DNASequence
• Keyword
• FASTA
• Calls to register new services
• You do not need to install your own MOBY-Central

35
How the service providers register with MOBY
Central

• A service name
• Service name from service type hierarchy
• Input/Output object (s) by name from the
  Object-type hierarchy
• A URI identifying the service provider
• The URL to the service script
• A human readable description of the service
• There are many tools available on homepage of
  BioMOBY to create services

36
Summary of MOBY's capabilities

• Easy to write web services using the MOBY library

• Services can be written by anyone, anywhere
• Anyone can registers their services with MOBY
  Central
• Anyone can query MOBY Central to discover and
  learn about any service

37
MOBY clients

• Gbrowse_moby
• http//mobycentral.icapture.ubc.ca/cgi-bin/gbro
  wse_moby
• Taverna
• http//taverna.sourceforge.net/

38
A Simple Workflow
39
(No Transcript)
40
(No Transcript)
41
(No Transcript)
42
(No Transcript)
43
(No Transcript)
44
(No Transcript)
45
(No Transcript)
46
(No Transcript)
47
(No Transcript)
48
(No Transcript)
49
(No Transcript)
50
(No Transcript)
51
(No Transcript)
52
(No Transcript)
53
(No Transcript)
54
(No Transcript)
55
(No Transcript)
56
(No Transcript)
57
(No Transcript)
58
(No Transcript)
59
(No Transcript)
60
(No Transcript)
61
(No Transcript)
62

• Thanks
