Factors that Control Texture of Sedimentary Rocks

1
(No Transcript)
2
Factors that Control Texture of Sedimentary Rocks

• Energy of Transporting agent
• Higher energy results in larger particle size and
  greater rounding of grains
• Distance of transport
• Greater distance sorts particles so that the
  coarser particles are deposited closer to the
  source and the finer particles are deposited
  farther from the source
• Rapidity of Deposition
• Rapid deposition results in less well-sorted
  sediment, while more even deposition, especially
  with reworking (as on a beach or in sand dunes),
  results in more well-sorted sediment
• Viscosity of Transporting Agent
• More viscous medium results in more poorly sorted
  angular sediment
• More fluid medium results in more well sorted,
  better rounded sediment

3
Platteville Ls and Decorah Shale, Spring Grove, MN
4
Sedimentary Environments
5
Siliciclastic Sedimentary Rocks

• Rocks made of grains of quartz, feldspar and rock
  fragments
• Particles derived by weathering of pre-existing
  rocks
• Transported from source to basin of deposition,
  either on continents or in oceans
• Classified by grain size
• Composition of grains reveals source area (rock
  type, climate, and relief)
• Texture and nature of bedding (sedimentary
  structures) reveal transport and depositional
  history
• gt2mm Conglomerate (rounded grains) and Breccia
  (angular grains) - mostly rock fragments
• 2mm - 1/16mm Sandstone - mostly quartz and
  feldspar
• lt1/16mm Shale - mostly clay

6
Conglomerate Swift Formation
7
Conglomerate - Cretaceous, Blacks Beach
8
Ripples on Bedding Surface - Sundance Fm
9
Ripple marks - Sundance Fm
10
Ripple Bedding - Franconia Fm
11
Formation of Cross Bedding
12
Cross Bedding in Jordan Formation, Homer, MN
13
Bipolar cros bedding - Franconia
14
Cross Bedding in Swift Fm.
15
Bipolar ripple bedding, Swift Fm
16
Bi-polar cross bedding - San Diego
17
Pebbly Cross-bedded Sandstone, Mt. Davis, PA
18
Intraclasts - Franconia Fm
19
Sedimentary rocks - Blacks Beach
20
Submarine Fan Channel Fill - Blacks Beach
21
Turbidites - Point Loma, San Diego
22
Turbidity Current Deposits, Point Loma, CA
23
Graded Bedding
24
Submarine Turbidity Current
25
Burrows, St. Lawrence Fm., Homer, MN
26
Great Sand Dunes, Colorado
27
Braided River Deposition
28
River and Floodplain
29
Mississippi River Delta
30
Nile River Delta
31
Outer Banks, North Carolina
32
Nags Head, Outer Banks, North Carolina
33
Barrier Island and Lagoon, Galveston, Texas
34
Lagoon at Low Tide
35
South Padre Island, Texas
36
Carbonate Rocks

• Classified by minerals present
• Calcite Ca(CO3) - Limestone
• Dolomite CaMg(CO3)2 - Dolostone
• Dolostones have crystalline textures (crystals
  interlock as in a mosaic)
• Limestones have either crystalline or clastic
  textures
• Clastic limestones are named according to grains
• Fossil fragments - Fossiliferous limestones
• Oolites (spherical sand sized grains of calcite
  with concentric laminations around a nucleus -
  oolitic limestones
• Intraclasts (fragments of limey sediment ripped
  from bed while still semi-soft) - Intraclastic
  limestones

37
Oneota Dolomite, Homer, Minnesota
38
Carbonate Sedimentation - Great Bahama Bank
39
Coral Reefs and Lagoon, Bora Bora, South Pacific
40
Carbonate Environments, Florida Keys
41
Fossils - Decorah Limestone
42
Oolites in thin section
43
Stromatolites, Willow River Dolomite, Chatfield,
MN
44
Facies and Stratigraphy
45
Transgression, Regression, and Stratigraphy
46
Stratigraphy in Southeastern Minnesota
47
Minnesota Paleogeography
48
Cross Section of Cambrian Strata
