Marine Navigation and Naval Operations I

1
Rules of the Road 11-19
2
Steering and Sailing RulesSection II Conduct
of vessels in sight of one another

• AGENDA
• Rule 11Application
• Rule 12Sailing Vessels
• Approach Situations
• Rule 13Overtaking
• Rule 14--Head-on
• Rule 15--Crossing Situations
• Rule 16Action by the Give-way Vessel
• Rule 17Action by the Stand-on Vessel
• Rule 19Responsibilities Between Vessels
• Section III - Restricted Visibility (Rule 19)

3
Conduct of Vessels in Sight of One Another

• When one vessel can be observed visually by
  another.
• Showing up on radar is not in sight.

4
Rule 12 Sailing Vessels

• Windward side opposite of the way the sail is
  carried
• Leeward the sheltered side

5
Rule 13 Overtaking

• The overtaking vessel shall keep out of the way
  of the vessel being passed.
• An overtaking situation exists when a vessel
  approaches another vessel more than 22.5 deg
  abaft the beam.
• When a vessel is in doubt as to whether shes
  overtaking, shell assume she is, and act
  accordingly.

6
The Vessel
Head-On
Crossing
Crossing
Beam
Beam
22.5
22.5
Overtaking
7
Rule 14 Meeting (Head-on) Situation

• Rule 14 requires both power vessels to maneuver
  to starboard.
•
  An overtaking situation exists when a vessel
  approaches

• A meeting situation exists if two power vessels
  approach on reciprocal or near reciprocal courses.

8
Rule 15 Crossing Situation

• The vessel that has the other on its starboard
  side is to keep clear.
• Avoid crossing ahead of the other vessel.
• At night the stand-on vessel sees the green
  sidelight of the give-way vessel, and the
  give-way vessel sees the red sidelight of the
  stand-on vessel.

9
Rule 16 Action by the Give-way Vessel

• Take early and substantial action to stay out of
  the way of the stand-on vessel

10
Rule 17 Action by Stand-on Vessel

• Maintain course and speed
• Take action if the give-way is not taking
  substantial action to avoid collision
• If risk of collision exists and if circumstance
  admit it, avoid altering course to port.

11
Rule 18 ResponsibilitiesBetween Vessels
Whos required to keep out of the way?

• Vessel not under command
• Restricted in ability to maneuver
• Vessel constrained by draft
• Vessel engaged in fishing
• Sailing vessels
• Power driven vessels
• Seaplanes

12
Rule 19 Conduct of Vessels in Restricted
Visibility

• For vessels not in sight of one another
• Observe a safe speed and have engines ready for
  immediate maneuvering.
• Avoid altering course to port when another may
  exist forward of beam (except in overtaking
  situation)
• Avoid altering course towards a vessel abeam or
  abaft the beam.
• For fog signals heard forward of the beamgt
  reduce speed to minimum steerageway and navigate
  cautiously.

13
QUESTIONS???
14
Rules of the Road 20-30
15
Lesson 24 Lights and Dayshapes

• AGENDA
• Rule 20/21 Application and Definitions
• Rule 22 Visibility of Lights
• Rule 23 Power Driven Vessels Underway
• Rule 24 Towing and Pushing
• Rule 25 Sailing Vessels
• Rule 26 Fishing Vessels
• Rule 27 Vessels not under command / restricted
  in ability
• Rule 28 Vessels constrained by draft
• Rule 29 Pilot vessels
• Rule 30 Vessels aground/at anchor

16
Rule 20 Application of Lights and Dayshapes

• Lights shall be displayed
• From sunset to sunrise
• In conditions of restricted visibility
• In all other circumstances when deemed
  appropriate
• Purpose of Lights and Dayshapes
• Helps determine stand on/give way status.
• Indicates the occupation of certain vessels.
• Aids in the determination of target angle and
  course.

17
Rule 21DefinitionsRule 22 Visibility of Lights

• Min Ranges
• TYPE OF LIGHT COLOR ARC 50M 12-50M
• Masthead white 225 6 nm 5 nm
• Sidelight red/green 112.5 3 nm 2 nm
• Sternlight white 135 3 nm 2 nm
• Towing yellow 135 3 nm 2 nm
• All around various 360 3 nm 2 nm
• Flashing yellow/blue 360 3 nm 2 nm
• Range Light - refers to the second masthead light
  placed aft and higher than the forward masthead
  light (gt50 m)
• Flashing Light - flashes at regular intervals at
  120 hz. Found on surfaced subs and
  non-displacement craft in the non-displacement
  mode.

18
Rule 21DefinitionsRule 22 Visibility of Lights
19
Rule 23 Power-DrivenVessels

• Power Driven vessels underway
• Vessel gt 50 m
• Vessel lt 50 m
• Vessel lt 12 m
• Vessel lt 7 m

20
Rule 24 Towing and Pushing

• TOWING ASTERN Yellow light above sternlight
• Vessel lt 50 m Tow lt 200 m 2 vertical masthead
• Vessel lt 50 m Tow gt 200 m 3 vertical
  masthead/diamond shape
• Vessel gt 50 m Tow lt 200 m
• Vessel gt 50 m Tow gt 200 m
• COMPOSITE UNIT treat as a power-driven vessel
• PUSHING AHEAD/ALONGSIDE
• Vessel gt 50 m International, Inland
• Vessel lt 50 m International, Inland
• Examples pg 62-63

21
Rule 25 Sailing Vessels

• lt 20 meters
• Red over green, sailing machine
• Dayshape upside down cone

22
Rule 26 Fishing Vessels
Green over white, trawling at night
Red over white, fishing at night

• U/W side/stern lights
• Dayshape
• Note on pg 84

• gt 50 M masthead light
• U/W side/stern lights

23
Rule 27 Vessels Not Under Command

• If making way, side/stern light
• Red over red, Captain is dead

24
Rule 27 Vessels Restricted in their Ability to
Maneuver

• Dayshape ball-diamond-ball
• A for diving operations
• 3 green lights (not vertical) for mineclearance\

25
Rule 28 Vessels Constrained by Draft (Inlt
Only)
26
Rule 29 Pilot Vessel
White over red, pilot ahead
27
Rule 30 Vessels Anchoredand Vessels Aground

• Anchor all around white light, deck lights
• Dayshape 1 black ball

• Aground all around white light, red over red
• Dayshape 3 black balls

28
(No Transcript)
29
(No Transcript)
30
(No Transcript)
31
QUESTIONS?
