Fundamentals of Naval Science
Navigation Instrument
2
Objectives
1. Know the capabilities of various instruments
used in piloting to determine direction, speed,
distance, and depth. 2. Know the capabilities
of various plotting instruments.
3
Measurement of Direction
Azimuth Circle - A ring fitted over a gyro
repeater face for measuring the bearing to an
object. The necessary sights and mirrors for
shooting celestial bodies are mounted on the
circle.
4
(No Transcript)
5
Measurement of Direction
Telescopic Alidade Identical to the az. circle,
but contains a telescopic sight for obtaining
bearings to navaids at greater distances.
6
Measurement of Distance
Radar - Distance is obtained by a radio wave
that is transmitted into the air and returns as
an echo. The time interval between
transmission and return can be converted
into a physical range.
7
Measurement of Distance
Stadimeter - Uses two logarithmic scales to
determine distance to objects of known height.
- The instrument is very accurate under 2000
yards, but gets progressively less accurate at
longer ranges.
8
Stadimeter
9
Measurement of Speed
Terms Speed over Ground - True speed, or
speed relative to the earth. Speed through
the water - Relative speed between the water
and the ship, not accounting for the effect of
current or seas.
10
Measurement of Speed
Impeller Log - Measures a vessels speed
through the water by translating the rotation of
a small propeller or paddle wheel below the
water line into a measurement of fluid
speed. Pit Log - 3-foot long tube extended
beneath the keel to measure speed. The tube
measures static and dynamic pressure, and
translates the difference in pressure into a
measurement of speed.
11
Measurement of Speed
Doppler Speed Log - Uses a transducer that
projects sonar beams to measure speed. By
measuring the Doppler shift, a measurement of
speed is determined. Shaft RPM - A graph a shaft
RPM vs. speed is produced by running a vessel
over a measured mile. This allows the
vessels speed to be estimated based on the
number of RPMs ordered.
12
Measurement of Depth
Fathometer - Uses a transducer that transmits
a sonar pulse vertically in the water. The
fathometer computes the depth by measuring
the time interval from transmission of the
sound until the return of the echo.
13
Piloting Instruments
Divider and Drawing Compass - Used to measure
distance on a nautical chart. Parallel
Ruler/Parallel Plotter/Parallel Motion Protractor
(PMP) - Used for plotting direction. Three-Arm
Protractor - Used to represent two horizontal
sextant angles on a chart.
14
(No Transcript)
15
Review Questions
NONE
16
