Title: LDEQ


1
LDEQs RECAP
  • Domenico and Summers Models

2
DOMENICO MODEL
3
Domenico Model

  • The Domenico groundwater model is used to
    calculate a dilution and attenuation factor (DF
    or DAF) associated with SoilGW2 , SoilGW3 , GW2 ,
    and GW3 values
  • DF or DAF is the source concentration of a
    constituent divided by its down gradient
    concentration
  • DF or DAF gt 1 If DF or DAF 1 then no dilution
    and/or attenuation

4


5
MO-1 Domenico ModelSoilGW2 3 and GW2 3
  • Default assumptions
  • Equation accounts ONLY for dilution
  • Plume is allowed to expand infinitely
  • laterally in 2 directions
  • vertically in 1 direction
  • Planar plume size is based on
  • Sw is 1/2 acre site - 148 ft by 148 ft
  • Sd depths vary from 5 to 20 feet

6
MO-1 Domenico Model

  • Two pieces of data are needed to determine a DF
    from the table
  • x - shortest downgradient distance from source to
    exposure point
  • Sd - vertical depth of plume

7
  • Determination of Sd - vertical depth of plume
  • METHOD 1
  • Sd depth of plume at initial conditions
  • Sd hadv hdisp
  • advective flow dispersive flow
  • Sd can not be greater than the aquifer thickness-B



8
  • METHOD 1 cont.
  • Sd hadv hdisp
  • hadv B1-exp((-IL)/(BDv)
  • hdisp (2 ?zL)(0.5)
  • B aquifer thickness 10 ft
  • I infiltration rate 0.33 ft/yr
  • L length of source 148 ft
  • Dv groundwater transport velocity 30 ft/yr
  • ?z vertical dispersivity L/200 148/200
  • Sd 1.5 14.8 16.3 gt B Therefore, Sd 10
    ft



9
Determination of Sd - vertical depth of plume
METHOD 2

  • The thickness of the impacted permeable zone
    shall be used as the Sd if the thickness of
    groundwater plume is unknown

10
  • MO-1 DF Table
  • Values given in tables in Appendix I
  • X Sd
  • lt5 6-10 11-15
    16-20
  • 0-50 1.5 1 1 1
  • 51-100 2.6 1.5 1.2 1.1
  • 101-150 4.1 2.1 1.6 1.3
  • 151-250 8.4 4.3 3 2.3
  • 251-500 29 15 9.8 7.4
  • 501-750 63 32 21 16
  • 751-1000 111 57 37 28
  • 1001-1250 173 86 58 43
  • 1251-1500 248 124 83 62
  • 1501-1750 337 169 113 84
  • 1751-2000 440 220 147 110



11
  • MO-1 Domenico Model


  • If Sd is greater than 20 feet then a
    site-specific DAF shall be calculated under MO-2
    or MO-3
  • If the distance from the source is greater than
    2000 feet, then (1) the DF for 2000 feet may be
    used under MO-1 or (2) a site-specific DAF may
    be calculated under MO-2 or MO-3

12
MO-2 Domenico Model
  • Equation can account for dilution and attenuation
  • Attenuation must be based on site-specific data
    (NO TEXT BOOK VALUES)
  • Plume is allowed to expand infinitely in the 2
    lateral directions
  • Plume vertical depth is limited to the aquifer
    thickness and must be accounted for in the
    equation

13
  • P. WJ1-1 2



14
  • MO-2 Domenico Model cont.
  • If the POE is within the boundary of plume use
    given form of equation - Fig. J-1
  • This means the x value, the distance from the
    source to the POE, is much less than the
    groundwater transport velocity multiplied by the
    time since the spill
  • (x ltlt v t)
  • If the POE is in front of plume x gt v t then
    equation must be modified and time t adjusted to
    account for maximum COC at point x (see model
    reference)
  • This is a judgment call. Looking for maximum
    contaminant concentration at the point x.



15
Summers Model
16
SUMMERS MODEL
  • The Summers model is used under MO-2 to calculate
    a site-specific dilution factor for a COC in soil
    water as it moves from the soil column into the
    adjacent groundwater (Appendix K)
  • DFSummers chemical concentration in soil
    leachate divided by the chemical concentration in
    the adjacent groundwater Cl / Csi
  • Under MO-1 a DF of 20 is used

17


18
MO-2 Summers Model
  • DAFSummers Cl / Csi (Qp Qa) / Qp
  • (I Sw L Dv Sd Sw) / (I Sw L)
  • (0.33148148 3010148) / (0.33148148) 7
  • Qp volumetric flow of infiltration into aquifer
  • I infiltration rate
  • Sw width of impacted area perpendicular to GW
    flow direction
  • L length of impacted area parallel to GW flow
    direction
  • Qa volumetric flow rate of groundwater
  • Dv darcy GW velocity
  • Sd thickness of GW plume

19
Estimation of Sd
  • Sd Thickness of impacted groundwater within
    permeable zone

Sd 5
10
Un-impacted groundwater
Impacted groundwater
5
15
20
Estimation of Sd
  • Sd Thickness of permeable zone if thickness is
    not known or if the zone is not impacted

Sd 15
10
Un-impacted groundwater
15
