Title: The potentials of geostatistics in predictive modelling


1
The potentials of geostatistics in predictive
modelling
  • L.Hazelhoff
  • ExploStat Consultancy Ltd.

2
Problem Objective
  • What means spatial correlation for predictive
    modelling?
  • What size of areas to predict mean value is
    reasonable?
  • There is a lack of environmental data
  • Objective To identify potentions of geostatiscs
    in predictive modelling

3
Overview presentation
  • Introduction to geostatistics
  • Exploratory analysis of spatial data
  • Potentions for predictive modelling
  • Demonstration of mapping sediments with the
    program Explostat (if there is time left)

1 km
4
Introduction to geostatistics
  • Quantify spatial correlation with the variogram
  • Interpolation and error estimation

5
Experimental Variogram(1)
  • Define classes of distances between observations
  • Select all pairs of observations from data set
    and classify their distances
  • Square the difference of the measured values
    within each pair of observtions
  • Add up these squares within a distance class
    (lag)
  • Create a graph with distances on horizontal axis
    and mean semivariances on vertical axis

6
Experimental Variogram(2)
7
Experimental Variogram(3)
8
Fitting a Variogram
9
Interpolation with Kriging
  • Define search area
  • Minimum, maximal number of points
  • Solve Kriging Equations to calculate weighing
    factors (depending on variogram)
  • Calculate estimation error

Example of kriging equations in matrix notation
10
Exploratory Data analysis
  • Stationairy mean and variance?
  • Spatial Outliers?

How to deal with this conditions
  • Use knowledge of environment physical parameters
    like type of soil, history of sedimentation and
    land use, geomorfological position in the
    landscape, hydrological situation, etc.

11
Inspection of the spatial data
  • Visualization with Voronoi surface
  • Link histogram and variogram with the spatial
    locations of observations
  • Evaluate effect of removing outliers

12
Solutions for inhomogenious data distributions
  • Stratification based on environmental knowledge
  • Transformations with Principal Components
    (example for pollutions)

13
Example Stratification of spatial Data
14
Change of support
  • Estimation at points Point kriging
  • Estimation mean of an area Block kriging
  • Error Point kriging gt Block kriging
  • Error larger area lt error smaller area

15
Optimize Sampling Plan using Block Kriging
  • Given Error Variance
  • How many sampling locations?
  • Optimal location of samples
  • Iterative procedure

16
Interpolating more properties at the same time
  • Co-Kriging with more variables
  • Kriging of a derived variable using multivariate
    statistics. examples
  • Principal Component score
  • Factor Score
  • Discriminant score
  • Correspondence score
  • Membership value (fuzzy classification)
  • Etc.

17
Potentials for predictive modelling
  • Generate optimal sampling plans (lack of
    sufficient environmental data)
  • Optimal size of prediction area (balance between
    resolution of map and estimation error)
  • Sampling cheap co-variables that are correlated
    with more expensive attributes (To reduce costs
    of fieldwork)

18
Conclusions
  • There are potentials for using geostatistics in
    archeological predictive modelling
  • Actual use of geostatistics have to be tested
  • Collaboration between people with geostatistical
    expertise and people working in the field of
    predictive modelling should be usefull

19
THE END
  • For more information about Explostat and
  • download this presentation
  • www.explostat.nl

Thank You
