Los Angeles Unified School District

1

Los Angeles Unified School District Division of
Special Education
Schools for All Children
Audiologic Resource Unit
Donnalyn Jaque-Antón Associate Superintendent
2
Overview

• Audiometry or Audiology ??
• Types of Hearing Loss
• Degrees of Hearing Acuity
• Reading the Audiogram
• Educational Implications of Hearing Loss
• The Unfair Hearing Test
• Help for Students with Hearing Loss
• ARU Services
• The ARU Referral Process
• The DHH Referral Process
• Contacts
• Acknowledgements
• Resources

3
Educational Audiology ProgramAudiologic Resource
Unit (ARU)
4
LAUSD System Audiometry and Audiology

• Audiometry
• Student Health
• Human Services
• Travels to schools
• Screens hearing
• Refers to audiology (ARU)
• as needed

• Audiology
• Division of Special Education
• Works in a permanent sound booth
• Provides comprehensive evaluation of hearing
• Refers to DHH as needed

5
LAUSD System Audiometry and Audiology

• Audiometrists go to schools and screen the
  hearing of students
• If the student fails this hearing screening
• She/he may be referred for a more comprehensive
  audiological evaluation by an Educational
  Audiologist in a sound room (at the ARU)

6
Types of Hearing Loss

• Conductive
• Usually not permanent
• Often treated medically
• Left untreated, loss may become permanent
• Affects outer and middle ear

7
Conductive loss Problem in outer and/or middle
ear
8
Types of Hearing Loss

• Sensorineural
• Permanent hearing loss
• Affects inner ear (sensory), and/or
• Auditory nerve (neural)

9
Sensorineural loss problem with inner ear
(cochlea) and/or nerve
10
Types of Hearing Loss

• Mixed Hearing Loss combination of
• sensorineural (permanent)
• AND
• conductive (usually temporary)

11
Mixed loss Problem in outer and/or middle ear
along with problem with inner ear and/or nerve
12
Degrees of Hearing Loss

• Normal Hearing 0-15 decibels
• Minimal (Borderline) 16-25 decibels
• Mild 26-40 decibels
• Moderate 41-70 decibels
• Severe 71-90 decibels
• Profound 91 decibels

13
Audiogram (graph of hearing status)

• low pitch
  high pitch
• (FREQUENCY)

soft
RIGHT EAR threshold of hearing
(DECIBELS)
LEFT EAR threshold of hearing
loud
14
Frequency (pitch)
Low pitch
High pitch
soft
Loudness (decibels)
Average conversational speech level
loud
15
RIGHT EAR (Remember red/round RIGHT)

• Student can hear sounds BELOW the line
• Student will have difficulty hearing sounds
  above the line

16
LEFT EAR

• Student can hear sounds BELOW the line
• Student will have difficulty hearing sounds
  above the line

17
RIGHT EAR
LEFT EAR
You may see both ears on the same audiogram This
audiogram indicates a mild to moderate loss in
the right ear and a moderate to profound loss in
the left ear.
18

Educational Implications of Normal Hearing

• Child detects complete speech signal even at soft
  conversational level
• Good hearing does not preclude auditory
  processing problems

19
Educational Implications of Minimal (Borderline)
Loss

• Child with a cold or the consistent mouth
  breather
• May have difficulty hearing
• Faint or distant speech
• At a distance
• If classroom is noisy
• May miss portions of fast-paced interactions
• May fatigue more easily because of listening
  effort

20
Educational Implications of Fluctuating
(conductive) Loss

• Hearing ability may change daily
• Typical of listening with fluid behind eardrum
• Can hear but misses fragments of the message
• May be accused of daydreaming or not paying
  attention
• Speech and listening/attention skills may be
  affected if child experiences chronic fluctuating
  hearing acuity before age 7 years

21
Educational Implications of Mild Loss

• Degree of difficulty experienced depends on
• Noise level in classroom
• Distance from teacher (speaker)
• Configuration of hearing loss
• May miss portions of fast-paced interactions and
  classroom discussions
• Student often accused of
• Not paying attention
• Hearing when s/he wants to
• Increased fatigue from listening effort

22
Educational Implications of Moderate Loss

• Difficulty understanding conversational speech at
  a distance of 3 feet
• Needs face to face communication
• Needs structure and vocabulary controlled
• Communication characterized by
• Delayed receptive and expressive language
• Limited vocabulary
• Articulation errors

23
Educational Implications of Moderate-Severe Loss

• Communication significantly affected
• Marked difficulty in verbal communication in both
  one to one and group situations
• Social interaction is increasingly difficult
• Communication may be characterized by
• Delayed receptive and expressive language
• Limited vocabulary
• Articulation errors
• Possible impact on self-esteem

24
Educational Implications ofSevere Loss

• May hear loud noises one foot from ear
• If loss is pre-lingual in onset, oral language
  and speech may not develop spontaneously or will
  be severely delayed
• If hearing loss is progressive or sudden, speech
  may deteriorate

25
Educational Implications of Profound Loss

• Most students cannot depend solely on listening
  for communication access
• Degree and configuration of loss will affect
  speech skills
• If loss is pre-lingual in onset, oral language
  and speech will not develop spontaneously or will
  be severely delayed
• If hearing loss is progressive or sudden, speech
  may deteriorate

26
Unfair Hearing Test
27
Children with Hearing Loss Need Our Help!

• Early intense intervention is essential for
  receptive and expressive language development
• Students need appropriate and consistent
  amplification for all their waking hours from an
  early age
• Classroom acoustics need to be arranged to the
  students advantage (think about things that
  make it easier for YOU to hear in a group
  situation)

28
Help for Students with Hearing Loss

• Flexible/preferential classroom seating
• Amplification/FM systems
• Personal hearing aids
• Personal FMs
• Classroom speaker system
• Personal speaker system
• Acoustic modifications of classroom

29
Audiologic Resource Unit (ARU) Services

• Provides audiologic evaluations for any child
  residing within the geographic boundaries of
  LAUSD, infant to age 22
• Educational Audiologists provide designated
  instruction and services (DIS) to Deaf and Hard
  of Hearing Special Day Programs to
• Ensure properly functioning amplification systems
• Support teacher in developing skills for use of
  residual hearing

30
Audiologic Resource Unit (ARU) Services

• Provides resource to DHH Itinerant Program
  regarding
• Residual hearing
• Amplification systems
• Provides counseling to parents regarding
• Hearing loss
• Amplification
• Services and resources available to the student

31
Audiologic Resource Unit (ARU) Services

• Provides professional development to District
  staff and outside agencies
• Refers for possible assistance through California
  Childrens Services (CCS) for coverage of hearing
  aids and hearing health care services

32
Referral Process For Students with Suspected
Hearing Loss

• Begins with a referral to the ARU
• If...
• Student fails hearing screening (at school, by
  Audiometry)
• OR
• Student has an audiogram from outside facility
• OR
• Student has known hearing loss
• OR
• Parent/school requests audiologic evaluation

33

• LOS ANGELES UNIFIED SCHOOL DISTRICT
• DIVISION OF SPECIAL EDUCATION
• AUDIOLOGIC RESOURCE UNIT
• (213) 241 - 8258
• REFERRAL FOR ARU SERVICES
• Student Name ____________________________________
  ___ Birth date ________________
• Address _________________________________________
  ___ Home Phone ______________
• Parent/Guardian _________________________________
  ____ Work phone ________________
• School ___________________________
  Loc.District _______ Home language
  _____________
• REASON FOR REFERRAL ? Failed hearing screening
  (Date____________)
• ? D HHitinerant assessment 3rd Year (Date
  ________________)
• ? Hearing loss suspected
• Comments___________
  ________________________________
• Student is receiving special education services ?
  No ? Yes
• If yes, please specify program ? Special Day
  Class _________________(Please attach a copy of
  current IEP)
• ? Itinerant DHH ___
  LAS ___ RSP ___ APE ___ VH ___
• Comments________________________________________
  ________________________________

• Fill in all identifying information
• Include reason for referral
• Identify special education services student is
  receiving, if any
• Include any other information to assist the
  audiologist

34

• PERTINENT HEALTH INFORMATION (per health
  office)
• MEDICAL
• chronic ear infections ? PE tubes ? Other
  _________________________________
• ? under private medical care Physician
  ________________________________________
• Comments ________________________________________
  ____________________________
• AUDIOLOGIC
• Has the student had a recent AUDIOLOGIC
  evaluation? ? No ? Yes If yes,
• Date/Location____________________________
• and please forward a copy of evaluation to
  AUDIOLOGIC RESOURCE UNIT
• AMPLIFICATION STATUS
• Does the student have hearing aids? ? No
  ? Yes, Right_______ Left________
• Dispenser______________________________
• Is the student using amplification on a
  consistent basis? ? No ? Yes
• Comments ________________________________________
  ______________________________

• Students health history has important
  implications for referral process.
  please fill this out as fully as possible
• Information from outside service providers is
  essential to appropriate diagnosis and management
  of hearing impairmentsif they have had private
  hearing tests please attach a copy!

35

• STUDENT PERFORMANCE (per classroom teacher)
• SPEECH LANGUAGE
• Is a speech/language problem suspected? ?
  No ? Yes If yes, Comments_________________
  __________________________________________________
  _
• ACADEMICS ? Above grade level ? At
  grade level ? Below grade level
• Comments__________________________________
  _______________________
• ATTENTION ? Good work habits ? Completes
  assignments ? Short attention span ?
  Easily distracted ? Follows oral
  directions
• Comments__________________________________
  _______________________
• BEHAVIOR ? Well-behaved ? Cooperative ?
  Helpful ? Easily frustrated
• ? Behaves inappropriately ?
  Relates well with peers
• ? Interacts with peers inappropriately
• Comments__________________________________
  _______________________
• Referred by ________________________________
  Date ___________________
• School Designee
• Received by ________________________________
  Date ___________________
• Audiologic Resource Unit


• Students performance provides valuable
  information for establishing testing conditions
  we may need two audiologists to test this student
  reliably
• Remember although you know the student, the
  educational audiologist has only the information
  you provide

36
Referral Process for DHH Services

• Based on the hearing evaluation, the ARU
  determines whether
• Student has normal hearing, ending DHH referral
  process
• Students hearing loss may adversely affect
  academic performance and/or access to the core
  curriculum, necessitating a referral to DHH for
  assessment to determine eligibility for DHH
  services

37
Referral Process for DHH Services

• ARU will
• Complete a report of each student tested
• Complete page 1 of Request for Special Education
  Assessment and
• ARU will mail the above to
• School
• DHH Office

38
Referral Process for DHH Services

• School will
• In order to make sure all areas of parental
  concerns are addressed the school will assist
  parent in completing page 2 of Request for
  Special Education Assessment Student
  Information Questionnaire
• The school will generate Assessment Plan within
  15 days, including all areas of suspected
  disability

39
Referral Process for DHH Services

• School will
• Check areas specific to DHH assessment
• Academic-DHH assessor
• Communication-DHH assessor and/or speech-language
  pathologist
• Health-nurse/doctor
• Send copy of signed Assessment Plan and Student
  Information Questionnaire to DHH Program,
  Beaudry-16th Floor

40
Referral Process for DHH Services

• When signed Assessment Plan is received the DHH
  Assessor will contact school to arrange DHH
  Assessment to determine if
• Hearing loss impacts access and progress in
  standards based core curriculum
• Hearing loss impacts communication skills
  adversely affecting educational performance

41
Referral Process for DHH Services

• Once all assessments are completed, school will
• Contact all committee members
• Schedule and complete IEP within 50 day time-line
• Students eligibility, determination of services
  and placement will be discussed at the IEP Team
  Meeting

42
For Assistance Please Contact

• Audiologic Resource Unit
• 333 South Beaudry Avenue-16th Floor
• Los Angeles, California 90017
• [phone]
• Marilyn Geffeney, Coordinator, ARU / DHH
• [phone]
• Roe Saxman, Senior Audiologist
• [phone]

43
Acknowledgements

• Authors
• Marilyn Geffeney, Coordinator ARU / DHH
• Roe Saxman, Senior Educational Audiologist
• Sandy Keaton, Educational Audiologist
• Patty Klein, Educational Audiologist
• With input from the
• Audiologic Resource Unit Educational Audiologists
• Technical Assistance
• Kate Brandon, Coordinator in Instructional
  Initiatives
• Daniel Gumarang,Instructional Technology Advisor

44
Resources

• American Academy of Audiology (AAA)
• audiology.org
• American Speech-Language-Hearing Association
  (ASHA) asha.org
• Educational Audiology Association (EAA)
• edaud.org
• California Academy of Audiology (CAA)
• caaud.org
• Disclaimer These sites have been chosen for
  educational and professional purposes. LAUSD does
  not endorse of guarantee any information
  contained in these sites.
• Getting Through, recording from Zenith Radio
  Corp
• Hearing Loss Simulation, Med Rx Inc.
