David Dunlap Observatory

1
David Dunlap Observatory
Slavek Rucinski Dept. Astronomy
Astrophysics University of Toronto
2
History of DDO (1)

• The 74 inch (1.88m) telescope, made in 1933 DDO
  dedicated on May 31, 1935.
• Classical Cassegrain design concave primary,
  convex secondary.
• Largest in Canada (next in size, DAO Victoria, 72
  inch).

3
History of DDO (2)

• Clarence Augustus Chant (1865-1956), the first
  DDO Director.
• Chant gave a lecture in 1921, David Dunlap in the
  audience. DD dies in 1924, but his widow Jessie
  allocates funds in 1926.
• Site selection 1930, purchase of land (180
  acres), the telescope the admin building for
  the total cost C200k.

4
History of DDO (3)

• Variable stars in globular clusters (Helen S.
  Hogg).
• Radial velocity studies of binary stars (1st
  known stellar black hole, Cyg X-1).
• Radio-astronomy program (46m dish in Algonquin in
  1960).
• Small telescopes (0.5m, 0.6m, 0.6m at Las
  Campanas (1971-1997).
• Planetoids named in relation to DDO/DAA (Chant,
  Fernie, Heard, Inannen, Martinduncan, Northcott,
  Sawyer-Hogg, Shelton, Tremaine, van den Bergh,
  Toronto).

5
Location

• Richmond Hill, access from Bayview Ave., N of
  16th Ave.
• 123 Hillsview Drive

6
Aerial view
7
Light pollution how serious?

• 1, 2 HgI 4047, HgI 4358
• 3, 4, 5 NaI 4665,4669, NaI 4748,4752, NaI
  4978,4983 (HPS)
• 7 NaI 5149,5153 (HPS)
• 8 HgI 5461
• 9 OI 5577 airglow
• 10 NaI 5683,5688 (HPS,LPS)
• 11 NaI 5890,5896 (HPS), wings extend 5500A -
  6500A with self-absorption
• 12 NaI 6154,6161 (HPS,LPS)
• 13 OI 6300 airglow

V-band 17.0-17.5 mag per arcsec2
8
Weather - cloudiness

• Summer months better, but more haze.
• Winter nights usually cloudy, but sometimes
  crispy clear (and long).

9
Efficiency

• Statistics for the years 1999 2004 (July-June)
• Year Nights Hours
• 1999 151/294 51 888 26
• 2000 168/315 53 986 28
• 2001 198/332 60 1121 32
• 210/332 63 1317 38
• 186/315 59 1090 32
• (Max 3459 hours 100 efficiency)

10
1.88m telescope seeing

• Median seeing (FWHM) 1.7 arcsec, but large values
  (gt3 to 5 arcsec) happen.
• Best images are about 1.0 arcsec in size, so this
  is the quality of the main mirror of the
  telescope.

11
1.88m Cassegrain
Cassegrain 1672
Gregory 1663
12
The grating spectrographs

• The 1.88m Cassegrain telescope has two
  spectrographs
• The Cassegrain medium res. (R 700 12,000),
• The Echelle high res. sp. (R 50,000).

13
Cass spectro
All reflective optics (except the corrective
plate). The blazed diffraction gratings (several
to select 100 1,800 lines/mm).
14
Blazed diffraction gratings
15
Stellar spectra

• The 2-D images are analyzed using IRAF (in UNIX)
• Image trace (2D-gt1D) background subtraction,
  wavelength calibration, rectification.

16
Possible programs

• Radial velocity measurements of stars.
• Stellar atmosphere studies
• - Atmosphere parameters (densities, pressure,
  temperature)
• - Abundances.
• Interstellar matter.

17
Radial velocities

• Doppler shift ??/? v/c (?ln ? v/c)
• Space velocities of stars galactic kinematics
  dynamics
• Pulsating stars radial and non-radial
  pulsations.
• Binary stars the only method to determine masses
• Rotating stars line broadening, surface features.

18
Broadening Function and Cross Correlation
Function (1)
q 0.091
19
BF and CCF (2)
The convolution reduces the amplitude, so that
the spectral signal (per pixel) is relatively
weaker for a given noise level. Hence a poorer
S/N.
20
BF and CCF (3)
The goal is to obtain the BF. The CCF is a poor
substitute of the BF.
21
BF and CCF (4)
Observed spectrum P ( convolution of the sharp
line spectrum S with a broadening function
B) P(x) ? B(u) S(x-u) du Computed CCF from
the observed P S C(z) ? P(x) S(xz) dx
? ? B(u) S(x-u) S(xz) du dx ? B(u) It is not a
surprise that C is a poor substitute of B CCF
is sensitive to the intrinsic broadening of lines
or insufficient resolution. (e.g, the well known
need to extricate the hydrogen lines).
22
BF and CCF (5)
We express the convolution (of the sharp line
spectrum S with the broadening function B) P(x)
? B(u) S(x-u) du A set of over-determined
linear equations, to be solveed using any LSQ
method (SVD is preferable). Typically P and S
(used to construct Des) have dimension N
1000-2000 pixels. B has dimension M 100-200
pixels.
23
DDO program

• DDO1 to 10 published in AJ (1999-2005), each
  with 10 RV orbits.
• DDO11 in preparation 100 orbits (a few
  additional publications, e.g., W Ser)
• DDO7, an explanatory paper with a discussion of
  uncertainties.
• Participants
• R.M.Blake, C.C.Capobianco, G.Conidis, H.DeBond,
  K.Gazeas, P.Ligeza, W.Lu, S.W.Mochnacki,
  W.Ogloza, T.Pribulla, W.Pych, P.Rogoziecki,
  S.M.Rucinski, G.Stachowski, J.R.Thomson

24
10 papers

• DDO papers 1 to 10, each contains 10 RV orbits.
• DDO11 in preparation.

http//www.astro.utoronto.ca/DDO/research/binaries
_prog.html
25
SX Crv
The smallest mass-ratio known q0.066 ? 0.002.
This information cannot be derived from the light
curve.
26
SW Lac
A well known W-type system q0.776 ? 0.012.
?T/T 5. The temperature excess can be
determined to ? 1.
27
TU UMi
A triple system probably intractable without the
BF technique. Individual BFs as vertical cuts in
a 2-D figure.
28
Contact binaries in triple systems
We see a very high percentage of triple systems.
A new investigation of all available evidences
of triple multiple components of contact
binaries (Pribulla Rucinski 2005). Percentage
of triples/multiples, the lower limit 56 to
68. This is high as we are blind to some types
of companions (WDs, etc.) Preferential origin in
multiples?
29
Limitations

• Magnitude limits
• Cassegrain spectrograph
• 11 mag 0.15A/pix (2160 l/mm)
• 15 mag 3.7A/pix (100 l/mm)
• Echelle
• 6 mag (0.05 A/pix)

30
Time allocation

• Faculty, graduate students and senior
  under-graduate students, visitors.
• The schedule is prepared ½ month in advance on
  the basis of Web based application form.
• Observers must be present during the observations.

31
Information contacts

• www.astro.utoronto.ca/DDO/
• rucinski_at_astro.utoronto.ca
